F. WINTERIZATION PROCEDURE
Tools/Supplies Required
For all Systems you will need:
Cap Wrench
Adjustable wrench
Nut driver
3 US gallons (12 litres) plumbers antifreeze that is
propylene glycol based and rated for -58
1- ¾" MNPT PVC plug
1 - ½" MNPT PVC plug
WARNING!
Never use AUTOMOTIVE type antifreezes when
winterizing the System. This may result in serious
injury or death.
Only plumbing antifreeze, consisting primarily of
propylene glycol with no ethanol or other alcohols,
rated for -58 F (-50 C), may be used to winterize
o o
the System. The use of less-expensive 'non-
propylene glycol based' plumbing or RV antifreezes
may damage the System's internal components
voiding all warranties. This may also result in
serious injury or death.
Plumbing antifreeze containing propylene glycol
will provide protection of the System against
freezing to -40 F (-40
o
of antifreeze to water is correct. This procedure
only protects the System from freezing and does
not protect the rest of the household water
distribution system.
Propylene glycol based antifreeze is available at
most hardware stores.
1 1 1 1 1
Close the Inlet Valve. Completely drain the System
and household piping. To drain the System, refer to the
Controller Functions section under D. OPERATIONS on
how to perform a Manual Flush. To drain the household
pipes, open a cold water tap (on the lowest level of the
home) and leave until the tap only drips. Turn off the tap
when the pipes are drained.
o F (-50 o C).
C) as long as the proportion
o
All valves
closed
FIGURE 9
2 2 2 2 2
Remove the drain hose and Nylon Elbow from the
Drain Solenoid Valve and install a ½" MNPT or ¾" MNPT
PVC plug (depending on the size of the port) into the
Drain Solenoid Valve.
3 3 3 3 3
Drain the filtered water from the System by
disconnecting the Outlet Stainless Steel Flex Hose where
it connects to the home plumbing, and drain into a large
bucket. Plug the Flex Hose and System by installing a ¾"
MNPT PVC plug.
Disconnect and
Plug here
Outlet Fitting Assembly installed in standard
configuration shown. Systems equipped with the
Surface Water Option Kit have different Outlet
Fitting Assemblies.
4 4 4 4 4
If an External Prefilter has been installed, open the
Mini Ball Valve on the bottom of the housing and allow to
drain. Press the red button on the External Prefilter head
to speed up draining. Unscrew the housing from the
head and remove the External Prefilter cartridge from the
housing, and discard. Do not install a new filter cartridge.
Re-attach the filter housing to the head.
5 5 5 5 5
Remove the System Cap and remove the Prefilter.
If the System is equipped with the Carbon Prefilter,
discard the Carbon Prefilter. If the System is equipped
with the Stainless Steel Prefilter, clean and set aside the
Stainless Steel Prefilter temporarily. The Stainless Steel
Prefilter can be stored in the System for the winter in
Step 7.
FIGURE 10
FIGURE 11
Open
FIGURE 12
