Page 1: Ceiling Fan
110 083 Rapallo Ceiling Fan Owner’s Manual Rapallo Ventilador de Techo de 1,32 Manual del Propietario... -
Page 2: Table Of Contents
52” Rapallo Thank you for purchasing our ceiling fan. This product has been manufactured with the highest standards of safety and quality. Ceiling Fan by Hampton Bay Date Purchased Table of Contents Store Purchased Safety Rules ....1 110-083 UL Model No. -
Page 3: Safety Rules
Safety Rules - Read and Save These Instructions To reduce the risk of electric shock, insure electricity has been turned off After making electrical connections, spliced conductors should be turned at the circuit breaker or fuse box before beginning. upward and pushed carefully up into outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding All wiring must be in accordance with the National Electrical Code conductor on one side of the outlet box and ungrounded conductor on the... -
Page 4: Unpacking Your Fan
Unpacking Your Fan Unpack your fan and check the contents. You should have the following items: Set of blades (3) Mounting plate Blade Attachment Hardware (10 Screws with Fiber Washers) Mounting bracket Light kit assembly Fan motor assembly Glass shade Electrical Hardware (3 Plastic Wire Nuts) Motor housing... -
Page 5: Installing Your Fan
Installing Your Fan Tools Required Figures 1 and 2 are examples of different ways to mount the outlet box. Phillips screwdriver, straight slot screwdriver, adjustable wrench, step ladder, and wire cutters. Outlet Box Mounting Options Outlet Box If there isn't an existing UL listed mounting box, then read the following instructions. -
Page 6: Hanging The Fan
Hanging the Fan Connect the ground conductor of the 120V supply (this may be a bare wire or a wire with green colored insulation) to the green ground REMEMBER to turn off the power. Follow the lead(s) of the fan (Figure 6). steps below to hang your fan properly. - Page 7 Finishing the Fan SUPPLY CIRCUIT Installation Ground Studs Conductor Move fan into position over the four mounting studs and secure with the provided washers and nuts (Fig. 7). Outlet Box Green Ground Raise the motor housing up against the Lead mounting bracket, the four supports inside the housing should be placed against the four studs Ground to...
-
Page 8: Attaching The Fan Blades
Attaching the Fan Blades Screws with Fiber Washers Attach blades to blade arms using three screws Motor with fiber washers. (Fig. 9) Start a screw into Blades the blade arm, do not tighten. Repeat for the 2 remaining screws and washers. Blade Arms Blade arm Slot... -
Page 9: Blade Balancing
Blade Balancing Attaching the Mounting Plate The following procedure should correct most fan Touching Ceiling wobble. Check after each step. Remove the 1 of 3 screws from the mounting Check that all blade and blade bracket screws ring and loosen the other 2 screws. (Do not are secure. -
Page 10: Installing The Light Kit
Installing the NOTE NOTE MAKE SURE TO LEAVE ENOUGH SPACE LIGHT BULBS HAVE NO WARRANTY; CAN BE Light Kit BETWEEN THE FAN PULL CHAIN AND THE PURCHASED AT ANY HOME DEPOT STORE. BULBS SO THE CHAIN DOESN'T RUB AGAINST ANY OF THE BULBS. Fan without Light Kit CAUTION (Optional) -
Page 11: Operating Your Fan
Operating Your Fan NOTE Warm weather - (Counter-Clockwise direction) A downward air flow creates a cooling effect as WAIT FOR FAN TO STOP BEFORE REVERSING THE DIRECTION OF THE BLADE ROTATION. shown in Figure 15. This allows you to set your air conditioner on a higher setting without affecting your comfort. -
Page 12: Care Of Your Fan
Care of Your Fan Troubleshooting PROBLEM SOLUTION Here are some suggestions to help you maintain your fan. Fan will not start Check main and branch circuit fuses or breakers. Because of the fan's natural movement, some Check line wire connections to the fan and switch wire connections may become loose. -
Page 13: Specifications
Specifications FAN SIZE SPEED VOLTS AMPS WATTS N.W. G.W. C.F. 0.21 1507 7.3 kgs 8.2 kgs 52” MED. 0.37 3207 1.49’ (16.6 Ibs) (18.1 Ibs) HIGH 0.47 4144 These are approximate measures. They do not include Amps and Wattage used by the light kit . -
Page 14: Warranty Information
Lifetime Limited Warranty (lifetime warranty on motor) The Hampton Bay warrants the fan motor to be free from defects in workmanship and material present at time You must present a copy of the original purchase receipt to obtain warranty of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser.
