Williams Sound CHG 3512 Instructions For Use And Care

Multiple battery charger 12 unit charger. for use with williams sound’s ppa r35 and ppa r35-8 fm receivers.
Hide thumbs Also See for CHG 3512:
1
2
3
4

Advertisement

Table of Contents

CHG 3512
12 Unit Charger. For use with Williams Sound's PPA R35 and PPA R35-8 FM Receivers.
PPA R35 or R35-8
Receiver
Charging LED
Indicator
Instructions for Use and Care
WARNING: DO NOT ATTEMPT TO CHARGE NON-RECHARGEABLE BATTERIES!
Non-rechargeable batteries, such as alkaline and carbon zinc, may heat up and
burst, causing possible injury and damage to the equipment.
Before inserting the PPA R35 or PPA R35-8 receiver into the charger, be sure that each
receiver has NiMH batteries installed. Also, check to make sure the switch setting in the
PPA R35 or PPA R35-8 battery compartment indicates the "NiMH" setting.
1.) Plug the TFP 035 power supply into the AC wall outlet. Plug the power connector into
the rear of the CHG 3512 unit (Figure B).
2.) Insert the PPA R35 or PPA R35-8 receiver into the charging slot as illustrated in Figure A
above. The receiver(s) must be placed in the charger facing forward to make contact with
charger contacts. A red LED indicator will illuminate when charging has started (Figure A).
The red LED will blink when the receiver batteries are fully charged (indicates the charger is
in trickle charge mode).
• You may charge up to 12 receiver units per CHG 3512 charger.
• It will take approximately 4 hours to fully charge the batteries.
Note: It is safe to leave the receivers in the charger, even after the batteries are fully
charged. The charger will switch to trickle charge to maintain full battery potential.
®
Williams Sound
Helping People Hear
Multiple Battery Charger
CHG 3512
Front-Top View
CHG 3512
Rear View
TFP 035
AC Power Connection
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHG 3512 and is the answer not in the manual?

Questions and answers

Related Manuals for Williams Sound CHG 3512

Summary of Contents for Williams Sound CHG 3512

  • Page 1 CHG 3512 Multiple Battery Charger 12 Unit Charger. For use with Williams Sound’s PPA R35 and PPA R35-8 FM Receivers. CHG 3512 CHG 3512 Front-Top View Rear View PPA R35 or R35-8 Receiver Charging LED Indicator TFP 035 AC Power Connection...

  • Page 2: Troubleshooting

    Product Recycling for Customers in the European Union: Please do NOT dispose of your Williams Sound equipment in the household trash. Please take the equipment to an electronics recycling center; OR, return the product to the factory for proper disposal.

  • Page 3: Limited Warranty

    Williams Sound products are engineered, designed and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the CHG 3512 Multiple Battery Charger against defects in materials and workmanship for ONE (1) year. During the first year from the purchase date, we will promptly repair or replace the CHG 3512 Charger.
  • Page 4 Williams Sound Corp. 10321 West 70th St., Eden Prairie, MN 55344-3446 U.S.A. 800-328-6190 / 952-943-2252 / FAX: 952-943-2174 www.williamssound.com ® 2005, Williams Sound Corp. MAN 116B...
