CHG 518

5 Unit Charger. For use with Williams Sound's WIR RX18 Receiver.

WIR RX18

Receiver

Charging LED

Indicators

WARNING: DO NOT ATTEMPT TO CHARGE NON-RECHARGEABLE BATTERIES!

Before inserting the WIR RX18 receiver into the charger, check to make sure that each

receiver has BAT AP07D NiMH batteries installed! Refer to the WIR RX18 user manual.

Instructions:

1.) Plug the power supply into the AC wall outlet. Plug the power connector into the rear

of the CHG 518 unit (Figure B).

2.) Insert the WIR RX18 receiver into the charging slot as illustrated in Figure A above. The

receiver(s) must be placed in the charger facing forward to make contact with charger

contacts. A red LED indicator will illuminate when charging and turn green when charging

is complete

• You may charge up to 5 receiver units per CHG 518 charger.

• It will take approximately 6 hours to fully charge new batteries.

Note: It is safe to leave the receivers in the charger, even after the batteries are fully charged.

The charger will monitor the batteries and recharge if needed.

3.) Piggy-back cable is provided. 3 CHG 518 receivers can be powered from one power

supply TFP 043.

Multiple Battery Charger

CHG 518 Front-Top View

CHG 518 Rear View

AC Power Connection

TFP 043

Table of Contents

Do you have a question about the CHG 518 and is the answer not in the manual?

Page 1 Note: It is safe to leave the receivers in the charger, even after the batteries are fully charged. The charger will monitor the batteries and recharge if needed. 3.) Piggy-back cable is provided. 3 CHG 518 receivers can be powered from one power supply TFP 043.
Page 2: Troubleshooting
Product Recycling for Customers in the European Union: Please do NOT dispose of your Williams Sound equipment in the household trash. Please take the equip- ment to an electronics recycling center; OR, return the product to the factory for proper disposal.
Page 3: Limited Warranty
Williams Sound products are engineered, designed and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the CHG 518 Multiple Battery Charger against defects in materials and workmanship for ONE (1) year. During the first year from the purchase date, we will promptly repair or replace the CHG 518 Charger.
