INSTALLATION / OWNER'S MANUAL
Read and understand this installation and operation manual thoroughly prior to assembly,
installation, operation or service to this appliance.
FOR YOUR SAFETY:
This heater must only be serviced by a trained gas service technician. Failure to comply
could result in personal injury, death, fire and/or property damage.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance
IF YOU SMELL GAS:
FIELD CONVERTIBILITY:
conversion shall be carried out in accordance with the requirements of the authorities having jurisdiction
and in accordance with the requirements of the B149.1 ( latest edition) INSTALLATION CODE in Canada,
and the ANSI Z223.1 (latest edition) in the U.S.A.
4SN5 4SL5
4BN6 4BL6
WARNING
.
Extinguish any open flame
Don't touch any electrical switch, or telephone
Go to a neighbor and call your gas supplier immediately
Follow any and all instruction from your gas supplier
If your gas supplier is not available, call the fire department
Gas conversion must only be done by a trained gas service technician. The
Keep this manual in a secure place .
Record the following information for future reference:
NG
Model #:
4SN5
4BN6
Serial #:
(located on heater rating label)
MODELS
LP
4SL5
4BL6
4SN/L5,4BN/L6 Manua l
RD: JUNE 2008
RL: 1A
BA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schwank InfraSave 4SN5
Summary of Contents for Schwank InfraSave 4SN5
- Page 1 MODELS 4SN5 4SL5 4BN6 4BL6 INSTALLATION / OWNER’S MANUAL WARNING Read and understand this installation and operation manual thoroughly prior to assembly, installation, operation or service to this appliance. FOR YOUR SAFETY: This heater must only be serviced by a trained gas service technician. Failure to comply could result in personal injury, death, fire and/or property damage.
- Page 2 This publication, or parts thereof, may not be reproduced in any form without prior written consent from the manufacturer. Unauthorized use or distribution of this publication is strictly prohibited. Schwank Group / InfraSave 5285 Bradco Boulevard Mississauga, Ontario, Canada L4W 2A6...
-
Page 3: Table Of Contents
SERIES: 4SN/L5, 4BN/L6 INFRARED POST MOUNTED PATIO HEATER TABLE OF CONTENTS TOPIC PAGE NUMBER TOPIC PAGE NUMBER 1. GENERAL ........1 7. SAFE LOCATION FOR HEATER ..9 2. INSTALLATION REQUIREMENTS.. 1 7.1 CLEARANCE FROM COMBUSTI- 3. GAS SUPPLY ........1 BLES........... -
Page 4: General
CAN/ post patio, deck and garden heater for opera- CGA-B149.1-00 (latest edition) installation tion with Natural Gas (4SN5 and 4BN6) or Pro- code and the ANSI Z223.1 (latest edition) for pane (4SL5 and 4BL6). the U.S.A. for gas burning appliances and equipment. -
Page 5: 4N51/62 Specifications
Heater manifold pressure required to maintain correct burner input is 5” w.c. · The installation must conform with local codes, or in the absence of local codes, with Na- tional Fuel Gas Code. 3.1 Series 4SN5/4BN6 specifications: · Manifold pressure 5” w.c. maximum / 2” w.c. minimum ·... -
Page 6: 4L51/62 Specifications
PROPANE: NEVER CONNECT AN UNREGULATED GAS SUPPLY TO THE HEATER. PRECAUTIONS: · Periodically check the whole system for leaks or if the smell of gas is detected. · Extinguish all open flames. Perform ALL leak testing outdoors. · Never leak test while smoking. ·... -
Page 7: Assembly
4. TOOLS REQUIRED FOR ASSEMBLY Tools Needed: (not supplied) Adjustable Wrench, Slip Joint Pliers, Phillips Screwdriver-Medium Blade (#2 or #3 blade), Ham- mer, 3/8” Masonry Drill Bit (if mounting on concrete patio), Teflon Plumbing Tape for Joints, Spray Bottle of Soapy Water or Paint Brush and soapy water (to check leaks) Note: Gas Pressure Regulators are required (not supplied ) (see Connection and Testing) -
Page 8: Assembly Instructions
6. ASSEMBLY INSTRUCTIONS Using screws, place L-shaped stabilizers to bottom base. Secure with nut on inside of bottom base. Place post on the bottom of the base in up- ward position. Secure using screws. Feed the gas hose provided either down from the top of the post, or up through the side opening at the bottom of the post. - Page 9 ASSEMBLY..CONTINUED Connect gas hose to burner valve and tighten with a wrench. Temporarily secure the top burner assembly to center post with screws (already affixed to the burner assembly). HAND TIGHTEN the fastening screws at this time. When the heater is connected to the gas supply, the burner head will need to be lifted to leak test the hose connection to the burner valve.
- Page 10 ASSEMBLY..CONTINUED If placing on concrete patio only: Drill 3 holes 1 3/4” deep using the 3/8” ma- sonry drill bit (not supplied). Insert the 3 x 3/8” lag bolts provided, tapping them in using the hammer shaft until the washer stops it at the floor.
-
Page 11: Connection And Testing
CONNECTION AND TESTING: NATURAL GAS CONNECTION: Connect the natural gas supply line to the flexible hose at the base of the post as per local or national gas code. A 5”w.c. gas pressure regulator is required (not supplied) after the shut off valve to each heater or zone. -
Page 12: Safe Location For Heater
7. A SAFE LOCATION FOR THE HEATER: Caution: The main application of this heater is to pro- If objects are left under a heater in operation, vide radiant heat comfort in the outdoors, at such objects will be subject to radiant heat. poolside, spa areas, terraces, patios and work Always maintain at least the minimum certi- areas, etc. -
Page 13: Lighting Instructions
8. OPERATION AND LIGHTING INSTRUCTIONS: Install ‘AAA” Battery into electronic igniter ‘AAA’ Battery (as illustrated) by unscrewing cap counterclockwise, insert battery with positive terminal facing “in”. Replace cap. TO TURN ON: 1. From ‘OFF’ position, turn knob 90° counter-clockwise push and hold in. 2. -
Page 14: Troubleshooting
9. TROUBLE SHOOTING This heater must only be serviced by a trained gas service technician. Failure to comply could result in personal injury, death, fire and/or property damage. PROBLEM PROBABLE CAUSE SOLUTION Burner will not light Gas valve may be in OFF position Turn the gas valve ON Clean or Pilot Orifice blocked replace orifice... -
Page 15: Storage
9.1 STORAGE When heater is not in use for a prolonged period of time verify that the gas valve is fully and tightly closed. To avoid damage, the reflector may be removed and stored separately in a secure location. 9.2 PREVENTATIVE CARE AND MAINTENANCE The burner area is likely to attract spiders, especially inside the gas orifice. -
Page 16: Limited Warranty
LIMITED WARRANTY CERTIFICATE 4SN/L5, 4BN/L6 SERIES FOR GAS-FIRED INFRA-RED PATIO HEATERS : The Manufacturer warrants that this product is free from defects in material or workmanship under normal use and service subject to the terms of this document. COMPONENT PARTS - ONE YEAR WARRANTY Subject to the conditions and limitations stated herein, during the term of this limited warranty, we will supply any component part (at our option a new or repaired component part) of the heater, as defined below, excluding any labor, which the Manufacturer’s examination determines to be defective in workmanship or material for a period of one year (1 year) from the date of installation,...
