POST MOUNTED INFRARED PATIO HEATER
INSTALLATION / OWNER'S MANUAL
This Operation & Instruction manual is not to be removed from the site.
Consumer: Become acquainted with all safety procedures in the manual and re-
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury, or death. This heater must only be serviced by a qualified gas
service technician. Read and understand this installation, operating and maintenance instruc-
tions thoroughly before installation, operation, or service to this appliance.
WARNING: Do not store or use gasoline or other flammable vapours and liquids in the
vicinity of this or any other appliance.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. Don't touch any electrical switch or telephone
4. Go to a neighbour and call you gas supplier immediately
5. Follow any and all instructions from your gas supplier
6. If your gas supplier is not available call the fire department
FIELD CONVERTIBILITY: This appliance is NOT field convertible between natural gas and propane gas
Keep this manual in a secure place for future reference.
Record the following information :
Model #:
Serial #:
(located on heater rating label)
4BN6-CB
4BL6-CB 4SL5-CB
FOR OUTDOOR USE ONLY
tain the manual in a secure location for future reference.
4BN6-CB
Natural Gas
4BL6-CB
Propane Gas
4SN5-CB
Natural Gas
4SL5-CB
Propane Gas
4SN5-CB
4BN/L6,4SN/L5 Manual
IM100310
RD: DEC 2013
RL: 1B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schwank infrasave 4BN6-CB
Summary of Contents for Schwank infrasave 4BN6-CB
- Page 1 4BN6-CB 4SN5-CB 4BL6-CB 4SL5-CB POST MOUNTED INFRARED PATIO HEATER FOR OUTDOOR USE ONLY INSTALLATION / OWNER’S MANUAL This Operation & Instruction manual is not to be removed from the site. Consumer: Become acquainted with all safety procedures in the manual and re- tain the manual in a secure location for future reference.
- Page 2 This publication, or parts thereof, may not be reproduced in any form, without prior written consent from the manufacturer. Unauthorized use or distribution of this publication is strictly prohibited. Schwank / InfraSave 5285 Bradco Boulevard Mississauga, Ontario, L4W 2A6...
-
Page 3: Table Of Contents
4BN6-CB 4SN5-CB 4BL6-CB 4SL5-CB POST MOUNTED INFRARED PATIO HEATER FOR OUTDOOR USE ONLY TABLE OF CONTENTS IMPORTANT INFORMATION - READ FIRST IMPORTANT SAFETY WARNINGS ..4, 5 NOTICE TO INSTALLERS ......4 CLEARANCE TO COMBUSTIBLES....4 TOPIC PAGE NUMBER TOPIC PAGE NUMBER 1. -
Page 4: Important Information - Read First Important Safety Warnings
IMPORTANT SAFETY NOTICES AND WARNINGS: Important Notice to Installer: Service and repairs must be done by a trained gas service technician. This Operation & Instruction manual is not to be removed from the site. This manual MUST be given in its entirety to the consumer and retained for future reference. Ac- quaint all users with Important Information throughout the manual. - Page 5 kler heads and locate heaters at a safe distance - in some instances the sprinkler heads may need to be replaced by higher temperature rated heads. Check with the local Fire Marshall and your insurance carrier. CLEARANCES TO COMBUSTIBLES Fig. 1 MUST BE MAINTAINED OR EXCEEDED 18”...
-
Page 6: General
1. GENERAL These installation and operating instructions are intended for Series 4SN/L5 and 4BN/L6 Heaters. This appliance is an fixed post gas-fired infrared patio, deck and garden heater for operation with Natural Gas (4SN5 and 4BN6) or Propane (4SL5 and 4BL6). The burner is controlled and adjusted by the gas control knob at the top of the heater, and the gas supply is routed through the inside of the pole using flexible gas hose. -
Page 7: Gas Supply
4. GAS SUPPLY: NATURAL GAS or PROPANE Gas supply to this heater requires a gas pressure regulator (not supplied). The heater comes with a flexible hose assembly inside the post with 3/8” male flared fitting for hook-up to a minimum 5” w.c. Natural Gas supply (7” w.c. maximum), OR minimum 11” w.c. LP Gas (14”... -
Page 8: Main Components & Dimensions
5. MAIN COMPONENTS AND DIMENSIONS Models 4SN/L5 include stainless post and base: N = natural gas, L = propane. Models 4BN/L6 has black powder coated post and base: N = natural gas, L = propane. Gas valve and orifice are specific to gas type, all other components are common for all models. Note: One or more gas pressure regulator is required (not supplied ) to regulate gas supply pres- sure. - Page 9 6. HEATER ASSEMBLY & INSTALLATION Tools Needed: (not supplied) Adjustable Wrench or wrench set, Slip Joint Pliers, Phillips Screwdriver-Medium Blade (#2 or #3 blade), Sheet Metal Snips, Drill and Masonry Bit for lag anchors (if mounting on concrete patio), Plumbing Seal/Tape for Joints, Soapy Water: Spray Bottle or Paint Brush for leak testing. NOTE: The top surface of the heater base is 3 1/2”...
-
Page 10: Assembly / Installation Instruc
ASSEMBLY / INSTALLATION ..CONTINUED 5. Feed gas hose from burner down the post and out through the oval port at bottom of post. Temporarily secure the burner assembly to post with screws sup- plied. HAND TIGHTEN the burner fastening screws at this time. -
Page 11: Tions
7. GAS CONNECTION AND LEAK TESTING: Locate the gas hose and piping out of pathways where people may trip over them, or in areas where the hose/piping may be subject to accidental damage. NATURAL GAS CONNECTION: Connect the natural gas supply line to the flexible hose at the base of the post as per local or national gas code. -
Page 12: Safe Location Of Heater
8. SAFE LOCATION OF HEATER: CAUTION: THIS HEATER IS FOR OUTDOOR USE ONLY See also “Installation Requirements”, section 2, page 6 Locate the heater out of pathways where people may come into contact with it, or in areas where the heater may be subject to accidental damage. This heater can be used to provide radiant heat comfort outdoors, at poolside, spa areas, ter- races, patios and work areas, etc. -
Page 13: Lighting, Operation, And Shutdown Instructions
9. LIGHTING, OPERATION, AND SHUTDOWN INSTRUCTIONS 2. If the heater will not be used for a longer time period, or requires service, shut off the gas supply to isolate the heater. 4BN/L6,4SN/L5 Manual IM100310 RD: DEC 2013 RL: 1B... -
Page 14: Maintenance
10. MAINTENANCE 1. Prior to each use, inspect the heater for damage - a qualified gas service person must repair or replace any damaged or malfunctioning components as supplied by the manufacturer. 2. Periodically (monthly) perform a leak test of all visible gas connections to ensure safe opera- tion - see page 11 for leak test procedures 3. - Page 15 person Refer to trouble shooting guide next page Periodically clean the heater with a mild detergent solution and rinse with clear wa- ter, or use a commercially available specialty cleaner. In particular keep the surface clean and clear at the base of the burner where air is taken in for combustion. A complete replacement parts list is on page 17.
-
Page 16: Troubleshooting
11. TROUBLE SHOOTING PROCEDURES IN THIS SECTION IS FOR QUALIFIED GAS SERVICE PERSON ONLY WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. This heater must be installed and serviced only by a qualified gas service technician. PROBLEM PROBABLE CAUSE SOLUTION... -
Page 17: Exploded View
12. REPLACEMENT PARTS: EXPLODED VIEW PROPANE MODELS: 4SL5-CB & 4BL6-CB NAT. GAS MODELS: 4SN5-CB & 4BN6-CB 4BN/L6,4SN/L5 Manual IM100310 RD: DEC 2013 RL: 1B... -
Page 18: Limited Warranty
This warranty gives you specific legal rights. You may also have other rights which vary by each jurisdiction. SCHWANK & INFRASAVE 5285 BRADCO BLVD. MISSISSAUGA, ON, L4W 2A6 GP-M400-CX-01A 2 SCHWANK WAY, WAYNESBORO, GEORGIA. 30830-8336 4BN/L6,4SN/L5 Series WARRANTY 1-877-446-3727 Fax: 1-866-361-0523 APRIL, 2005 csr@schwankgroup.com www.schwankgroup.com...
