OPERATOR'S MANUAL
SPECIFICATIONS, SERVICE KITS, GENERAL INFORMATION, TROUBLESHOOTING
INCLUDE MANUALS: 6695X--X LOWER PUMP END (PN 97999--002) &
S--632 GENERAL INFORMATION MANUAL (PN 97999--624)
6" AIR MOTOR
4:1 RATIO
6" STROKE
SERVICE KITS
• Use only genuine ARO
R
pressure rating and longest service life.
• 61355 for repair of Air Motor section.
Service Note: The Air Motor Service/Parts Manual is not shipped
with the pump but it is included with each Service Kit. If this Service/
Parts Information is needed, request the Air Motor Operator's Manu-
al from ARO. (Manual 6564X--X, PN 97999--174).
•
637230- X43 for repair of Lower Pump section.
Refer to the chart on page 2 for description of --X43 options.

SPECIFICATIONS

Model Series
(Refer to option chart)
Type . . . . . . . . . . . . . . . . . . . .
Ratio . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
Air Motor
Motor Repair Kit . . . . . . . . . .
Motor Diameter . . . . . . . . . . .
Stroke . . . . . . . . . . . . . . . . . .
Air Inlet . . . . . . . . . . . . . . . . .
Air Exhaust . . . . . . . . . . . . . .
. . . . .
Lower Pump End Series
Lower Pump Repair Kit . . . . .
Material Outlet . . . . . . . . . . .
PERFORMANCE
. . . . .
Air Inlet Pressure Range
Fluid Pressure Range . . . . . . .
Max. Rec'd Cycles / Minute
3
Displacement In Per Cycle
. . . . . . . . . . . . .
Volume/Cycle
Cycles Per Gallon . . . . . . . . . .
Flow @ 60 Cycles / Minute . . . .
Noise Level @ 60 Psi - 40 Cpm 84.8 db(A) *
* The pump sound pressure level has been updated to an Equivalent Continuous Sound
Level (L ) to meet the intent of ANSI S1. 13--1971, CAGI--PNEUROP S5.1 using four
Aeq
microphone locations.
INGERSOLL RAND COMPANY LTD
209 NORTH MAIN STREET – BRYAN, OHIO 43506
(800) 495-0276 FAX(800) 892-6276
www.ingersollrandproducts.com
FOUR BALL PUMP SERIES
CARBON STEEL, ELECTROLESS NICKEL PLATED
READ THIS MANUAL CAREFULLY BEFORE INSTALLING,
OPERATING OR SERVICING THIS EQUIPMENT.
replacement parts to assure compatible
. . 650632--X43--C
Air Operated, Four Ball
4:1
65665--B
61355
6" (15.2 cm)
6''
1/2'' -- 14 NPTF--1(f)
1--1/4'', 11--1/2 NPTF--1(f)
66953--X43
637230--X43
3/4" NPTF--1(f)
30 -- 150 PSI (2 -- 10.3 bar)
120 -- 600 PSI (8.3 -- 41.4 bar)
. . . 70
. . . 82
45.4 oz. (1343 ml)
2.8
21.3 GPM (80.6 lpm)
© 2010
CCN 99711836
650632- -X43- -C
MODEL 650632- X43- C
38- 5/8
(981 mm)
17- 25/32
(452 mm)
14- 21/32
(372 mm)
Accessories Available: 91790 Silencer, 66101 Wall Bracket.
This is one of the four documents which support the pump.
Replacement copies of these forms are available upon request.
= 650632--X--C MODEL OPERATOR'S MANUAL
- GENERAL INFORMATION -- INDUSTRIAL PISTON PUMPS
- 6695X--X LOWER PUMP END OPERATOR'S MANUAL
- 6564X--X AIR MOTOR OPERATOR'S MANUAL
650632- -X- -C
RELEASED: 11- -15- -96
REVISED:
PUMP DATA
Air Inlet
1/2- -14 NPTF- -1(f)
(Not Shown)
Air Motor
65665- -B
(See Manual 6564X--X)
Spacer Section
NUT Y85--29--N (3)
WASHER Y14--625 (3)
CONNECTOR
See Figure 2
SPRING 94457
SPACER ROD 93233--2
SPACER ROD 93233--1 (2)
Material Outlet
3/4'' NPTF- -1(f)
75_ FROM AIR EXHAUST
Lower Pump
66953- -X43
(See Manual 6695X--X)
FIGURE 1
IMPORTANT
6- -4- -10
(REV. 02)
