Before you start check the parts list to insure all of the parts shown are included.
Parts List
Description
A
projector mount assembly
B
4 mm security allen wrench
C
#10-32 x 3/8" serrated socket pin screw
D
#10-32 x 1/4" socket pin screw
E
1/4" flat washer
F
#14 x 2.5 phillips hex head wood screw
G
concrete anchor
H
M4 x 16 mm serrated socket pin screw
I
M4 x 12 mm serrated socket pin screw
J
.198 x .313 x .375 retaining spacer
K
.198 x .313 x .187 retaining spacer
L
.25" ID x .56" OD x .26" spacer
M
M5 x 10 mm socket pin screw
N
#10-32 x 3/16" slotted set screw
O
M6 x 12 mm serrated socket pin screw
P
M4 x 6 mm serrated socket pin screw
Q
ceiling plate
R
adapter plate
S
extension bracket
A
R
Q
Note: Actual parts may appear slightly different than illustrated.
Visit the InFocus Web Site at www.infocus.com
Qty.
1
1
2
1
2
2
2
3
1
3
1
6
1
1
4
2
1
1
2
B
G
J
S
M
FASTENERS
2 of 11
Part Number
055-0420
560-9646
520-1151
520-1196
540-9440
5S1-015-C03
590-0097
510-1087
510-1079
590-2020
590-1030
590-1050
520-1164
520-1187
510-1050
510-1059
580-1042
055-1539
055-1540
D
C
H
I
L
K
N
O
ISSUED: 10-22-04 SHEET #: 055-9236-5 01-10-06
E
F
P
