HAMPTON BAY ALTURA 52356 Use And Care Manual

60-inch ceiling fan
Hide thumbs Also See for ALTURA 52356:

Advertisement

Item # XXX-XXX
Model # 52356
UL Model # 60-ATO
USE AND CARE GUIDE
ALTURA 60-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday.
1-877-527-0313
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
