Masterbuilt 20041411 Assembly, Care & Use Manual Warning & Safety Information page 7

HOW TO USE QUICK START IGNITION SYSTEM
Read all instructions and warnings on charcoal bag and in manual before using.
1. Load three crumpled sheets of newspaper on top of grate inside ash can. Place ash can
in position below grill.
2. Pile charcoal directly above ash can on charcoal grate. Open holes in bottom air damper,
and ignite paper in ash can.
3. Spread charcoal out on grate and cook in as little as 20 minutes.
• NEVER USE GASOLINE TO LIGHT CHARCOAL.
• OVERFILLING CHARCOAL GRATE CAN CAUSE SERIOUS INJURY AND DAMAGE THE
UNIT.
• NEVER ADD ADDITIONAL LIGHTER FLUID ONCE CHARCOAL HAS IGNITED.
• HOT COALS SHOULD NOT BE LEFT UNATTENDED.
• GRILL IS HOT. USE PROTECTIVE GLOVES AND LONG, STURDY COOKING
UTENSILS.
WARNING
To ensure that it is safe to eat, food must be cooked to the minimum internal
temperatures listed in the table below.
USDA* Safe Minimum Internal Temperatures
Fish
Pork
Egg Dishes
Steaks and Roasts of Beef, Veal or Lamb
Ground Beef, Veal or Lamb
Whole Poultry (Turkey, Chicken, Duck, etc.)
Ground or Pieces Poultry (Chicken Breast, etc.) 165° F
* United States Department of Agriculture
9
145° F
160° F
160° F
145° F
160° F
165° F
ASSEMBLY INSTRUCTIONS
11
8
F
REAR
3
D
I
17
STEP 4b.
On front of grill overlap last skirt panel (17)
so it overlaps front edges of panels on left
and right.
Secure all panels to front legs (4) with screws
(I) and serrated flange nuts (D).
Tighten all leg screws and nuts at this
time.
Carefully reposition grill as shown.
19
Be careful not to chip/scratch porcelain.
E
STEP 3.
Note: Shelf may require tilting to place in
position. Legs may need to be spread apart
to place shelf in position.
Insert storage shelf (8) into holes in grill legs
as shown. Secure storage shelf to long legs
using aluminum flat washer (F) and crown
nut (K).
Attach one wheel (11), indented side out, to
each short leg. Then secure wheels and
storage shelf to legs using nylon hex lock
K
nuts (E).
Snap hubcaps (19) in place as shown.
Do not tighten skirt panel bolts until
full panel attachment is complete.
STEP 4a.
Align holes in skirt panel (17) with holes in
short leg (3) on right side. Insert screws (I)
through holes in skirt panel (17) into short leg
(3) as shown. Attach nuts (D). Do not tighten.
Repeat on left side for remaining short leg.
I
FRONT
4
17
I
D
I
6
