ASSEMBLY, CARE & USE MANUAL
WARNING & SAFETY INFORMATION
MODEL 20040712 SMALL BARREL GRILL WITH FIREBOX
THIS PRODUCT IS FOR OUTDOOR USE ONLY
Tools required for assembly: Adjustable Wrench, Phillips Head Screwdriver.
CARBON MONOXIDE HAZARD
WARNING
Burning charcoal gives off carbon
This manual contains important
monoxide, which has no odor and can
information necessary for the proper and
cause death.
safe use of this grill.
DO NOT burn charcoal inside homes,
Read and follow all warnings and
vehicles, tents, garages or any enclosed
instructions before using grill and
areas.
during use.
Masterbuilt Manufacturing, Inc.
1 Masterbuilt Court
Use only outdoors where it is well
Keep it for future reference.
Columbus, Georgia 31907
ventilated.
Customer Service 1-800-489-1581
Failure to follow these warnings and instructions properly could result in fire or explosion, which could cause
property damage, personal injury, or death.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20040712 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Masterbuilt 20040712

Summary of Contents for Masterbuilt 20040712

  • Page 1 ASSEMBLY, CARE & USE MANUAL WARNING & SAFETY INFORMATION MODEL 20040712 SMALL BARREL GRILL WITH FIREBOX THIS PRODUCT IS FOR OUTDOOR USE ONLY Tools required for assembly: Adjustable Wrench, Phillips Head Screwdriver. CARBON MONOXIDE HAZARD WARNING Burning charcoal gives off carbon...
