Operator's Manual
120V
INFLATOR
Model No. 75118
Safety Guidelines
Assembly
Operation
Maintenance
Troubleshooting
CAUTION: Read the Safety Guidelines
and All Instructions Carefully Before Operating.
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
Visit our Craftsman website: www.craftsman.com
Advertisement
Table of Contents
Related Manuals for Craftsman 75118
Summary of Contents for Craftsman 75118
- Page 1 Operator’s Manual 120V INFLATOR Model No. 75118 Safety Guidelines Assembly Operation Maintenance Troubleshooting CAUTION: Read the Safety Guidelines and All Instructions Carefully Before Operating. Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A. Visit our Craftsman website: www.craftsman.com...
-
Page 2: Table Of Contents
TROUBLESHOOTING GUIDE ..........13 SPECIFICATIONS..............13 WARRANTY CRAFTSMAN ONE YEAR FULL WARRANTY FOR ONE YEAR from the date of purchase, this product is warranted against any defects in material or workmanship. Defective product will be replaced free of charge. For warranty coverage details to obtain free replacement, visit the web site: www.craftsman.com... -
Page 3: Safety Guidelines-Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections. DANGER: Indicates an imminently CAUTION:... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Save these instructions Improper operation or maintenance of this product could result in serious injury and property damage. Read and understand all warnings and operation instructions before using this equipment. To reduce risk of electric shock, do not expose to rain. Store indoors. Household use only. - Page 5 HAZARD WARNING: Risk of Bursting What Could Happen How To Prevent It ATTACHMENTS & ACCESSORIES: Follow the equipment manufacturer’s recommendation and never exceed the Exceeding the pressure rating of air maximum allowable pressure rating of operated accessories, tires, inflatable attachments or inflatable items. balls, and other inflatables item can cause them to explode or fly apart, and could result in serious injury.
- Page 6 HAZARD WARNING: Risk of Electrical Shock What Could Happen How To Prevent It Your inflator is powered by electricity. Never operate the inflator outdoors when it Like any other electrically powered is raining or in wet conditions. device, If it is not used properly it may Never operate inflator with protective cause electric shock.
- Page 7 HAZARD WARNING: Risk of Burns What Could Happen How To Prevent It Touching exposed metal such as the Never touch any exposed metal parts on inflator head or outlet tubes, can result in inflator during or immediately after operation. serious burns. Inflator will remain hot for several minutes after operation.
-
Page 8: Glossary
HAZARD WARNING: Risk of Unsafe Operation What Could Happen How To Prevent It Unsafe operation of your inflator could Review and understand all instructions and lead to serious injury or death to you warnings in this manual. or others. Become familiar with the operation and controls of the inflator. -
Page 9: Accessories
ACCESSORIES This unit is capable of powering the following Accessories. Accessories included with your Inflator: Air Needle: Used to inflate sports balls. High Flow Inflator/Deflator Adaptor with three nozzles and seal ring: Used to inflate Presta Valve Adaptor: Used to inflate or deflate air mattresses, small boats, high performance bike tires. -
Page 10: Installation
INSTALLATION HOW TO SET UP YOUR UNIT 2. Make sure the outlet being used has the same configuration as the Location of the Inflator grounded plug. DO NOT USE AN Locate the Inflator in a clean, dry and ADAPTOR. See illustration well ventilated area. -
Page 11: Operation
OPERATION Know your Inflator READ THIS OWNER’S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR UNIT. Compare the illustration with your unit to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. Description of Operation On/Off Switch: Used to turn Inflator on High Flow Inflator/Deflator Adaptor: and off. -
Page 12: Operation
OPERATION To inflate vehicle and bicycle tires: To inflate sports ball, air mattress, rubber raft, etc. Place 120 Volt Inflator evenly on flat surface. Place 120 Volt Inflator evenly on flat surface. Connect the Quick-Connect Universal Valve Adaptor to tire air valve and Select the appropriate inflation push down the Valve Lock Lever to accessory and insert into the Quick-... - Page 13 High Flow Inflator/Deflator Deflation Position Adaptor For larger inflatable items, you may wish to use the High Flow Inflator/Deflator Adaptor as follows: 1. Connect the Quick-Connect Universal Valve Adaptor to high flow inflator/deflator adaptor as shown. 4. Insert nozzle into inflatable and start inflator.
-
Page 14: Maintenance
Extension cord is wrong Check the extension cord length or gauge Faulty motor Contact 1-800-874-5771 SPECIFICATIONS Model No. 75118 120V AC. 60Hz. 6.0 A 1.70 SCFM @ 30 PSI... - Page 15 Get it fixed, at your home or ours! add new step Your Home For troubleshooting, product manuals and expert advice: www.managemylife.com For repair – in your home – of all major brand appliances, lawn and garden equipment, or heating and cooling systems, no matter who made it, no matter who sold it ! For the replacement parts, accessories and owner’s manuals that you need to do-it-yourself.
