- Page 1 High-Performance Subwoofer Model HPS-250 Owner’s Manual Part #333762-001 ® Reference Standard (RS 4, RS 5) – Owner’ s Manual 1...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 2 High-Performance Subwoofer (HPS) – Owner’ s Manual Caution...3 Important Safety Instructions...4 Introduction...5 About This Product...5 Unpacking the Subwoofer...5 A Few Suggestions ...5 Volume Control ...5 Positioning...6–7 Identification of Front Panel Control ...8 Controls...8 Connecting Your Subwoofer ...9–10 Operation ...11 Set Controls ...11 Power On ...11... -
Page 3: Important Safety Instructions
DO NOT REMOVE COVER (0R BACK) NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED PERSONNEL THIS INFINITY PRODUCT IS DESIGNED FOR 120-VOLT USE ONLY! FOR DETAILED SAFETY PRECAUTIONS, PLEASE SEE FOLLOWING PAGE IN THIS OWNER ’ S MANUAL FOR “IMPORTANT SAFETY INSTRUCTIONS.”... -
Page 4: Important Safety Instructions
For products intended to operate from battery power, or other sources, refer to the oper- ating instructions. 4 HPS-250 – Owner’ s Manual IMPORTANT SAFETY INSTRUCTIONS 12) Grounding or Polarization – Figure A. -
Page 5: Introduction
MPORTANT NTRODUCTION Infinity’ s HPS-250 subwoofer has been designed to enhance the bass frequencies of any audio system. The subwoofer may be used with speakers of any size. Obviously, the greatest bass enhancement will be achieved when the subwoofer is connected to speakers that do not have the capability to create deep bass. -
Page 6: Positioning
We recommend placing the HPS-250 subwoofer at least 2 to 3 feet away from a television or a computer’ s disc-drive system to prevent smearing the colors of the TV picture or erasing of the magnetic drive. - Page 7 As a starting point, initially place the subwoofer behind your right-channel satellite speaker, six inches from the wall. We suggest trying this location first because, in an orchestra, the bass instruments are usually located in the back and to the right (see Figure 1).
-
Page 8: Identification Of Front Panel Control
ONTROLS Figure 2. 8 HPS-250 – Owner’ s Manual DENTIFICATION OF (Refer to Figure 2.) 1. Crossover: Controls the upper roll-off point. 2. Phase: Reverse/normal switch changes audio-signal polarity. 3. Gain: Controls subwoofer volume level. RONT ANEL CROSSOVER GAIN PHASE... -
Page 9: Connecting Your Subwoofer
ONNECTING UBWOOFER If your receiver/processor does not have subwoofer outputs for the left and right channels: HPS-250 – Owner’ s Manual 9... - Page 10 (mono) subwoofer output. In that case, it is recommended that you use a “Y” connector (not included) to maximize performance. 10 HPS-250 – Owner’ s Manual ONNECTING If your receiver/processor has subwoofer outputs for the left and right channels: UBWOOFER...
-
Page 11: Operation
It will be worth the effort involved to fully “tweak” your system. (Figure 2) up to the “5” position (half way). If no sound (Figure 2) until you obtain a pleasing blend of bass. Bass response HPS-250 – Owner’ s Manual 11... -
Page 12: A Word Of Advice
This may indicate an unbalanced condition in your system (too much bass), that the system is in an especially large room, or that speaker placement may be incorrect. Try several other locations before concluding that the Volume control must be set at maximum. -
Page 13: Care Of Your Subwoofer
If everything seems to be in good working order and the subwoofer still malfunctions, DO NOT ATTEMPT ANY REPAIRS! Contact your Infinity dealer and get the name of the authorized Infinity service center near you. If there is no facility near you, contact Infinity’ s Customer Service Department at (800) 553-3332, or write: Infinity Systems, Inc. -
Page 14: Specifications
PECIFICATIONS ERFORMANCE RIVE INISH IMENSIONS 14 HPS-250 – Owner’ s Manual HPS-250 Frequency Response: 28 ~ 120Hz Amplifier Power: 250W 12" Downfiring woofer Dark-bronze laminate Height, Width, Depth: 16 x 15 x 18" (406 x 381 x 457mm) - Page 15 Notes High-Performance Subwoofer (HPS) – Owner’ s Manual 15...
- Page 16 Infinity constantly strives to update and improve existing products, as well as create new ones. Therefore, the specifications and construction details in this and related Infinity publications are subject to change without notice. © 1998 Infinity Systems, Inc., 250 Crossways Park Drive, Woodbury, NY 11797 USA (516) 496-3400 •...
