Specifications

8
STOP
8.1
Specifications
Dimensions
Weight
Autom. sheet feeder
Positioning tolerances
Line positioning
Line parallelity
Begin of print
Paper capacity
of each bin
Capacity of paper depot
Autom. sheet feeder
Surrounding temperature
range
Operation temp.
Storing temp.
Relative humidity
Operation
Storing

Sheet Feeder Mechanic

This chapter provides the necessary information on disassembly of the different
sheet feeder components and elements.
Note:
ASF will not fit on 2T model.
height of printer with sheet feeder installed: 350 mm
1.80 kg
Beginning of page, first line + − 1,0 mm
first line + − 1,0 mm at 210 mm paper width
left margin, first character + − 1,0 mm
2
190 sheets at 80 g/m
2
80 sheets at 80 g/m paper weight
+ 15 °C to + 40 °C
- 40 °C to + 60 °C
30% to 60%
5% to 95%
paper weight
Sheet Feeder Mechanic
8-1
