Kitchen collection dishwasher fully integrated
Hide thumbs Also See for DW6011:

Advertisement

Quick Links

See also: Service Manual
kitchen collection
Instructions for use and warranty details
Dishwasher (Fully Integrated)
Model No.: DW6011

Advertisement

loading
Need help?

Need help?

Do you have a question about the DW6011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kleenmaid DW6011

Summary of Contents for Kleenmaid DW6011

  • Page 1 Instructions for use and warranty details Dishwasher (Fully Integrated) Model No.: DW6011...
  • Page 2 Congratulations on the purchase of your new Kleenmaid appliance. Your new Kleenmaid appliance has been designed and manufactured to give you years of reliable performance. For best results, carefully read the instructions on how to install your new appliance. Correct installation will avoid delays and unnecessary service call costs.

  • Page 3: Table Of Contents

    Contents Safety and operating instructions ___________________________ 2 Installation and hook-up __________________________________ 5 Description of the controls ________________________________ 8 Operating instructions ___________________________________ 16 Cleaning and maintenance _______________________________ 25 Troubleshooting _______________________________________ 29 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need about the right conditions for the proper, safe use of your dishwasher.

  • Page 4: Safety And Operating Instructions

    Safety instructions 1. Safety and operating instructions THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS CONTAINED IN THIS MANUAL. INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN COMPLIANCE WITH THE REGULATIONS IN FORCE.

  • Page 5: Safety Instructions

    Safety instructions WARNING: SOME DISHWASHER DETERGENTS ARE STRONGLY ALKALINE. THEY CAN BE EXTREMELY DANGEROUS IF SWALLOWED. AVOID CONTACT WITH THE SKIN AND EYES AND KEEP CHILDREN AWAY FROM THE DISHWASHER WHEN THE DOOR IS OPEN. CHECK THAT THE DETERGENT RECEPTACLE IS EMPTY AFTER COMPLETION OF THE WASH CYCLE.
  • Page 6 Safety instructions DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM AND BEFORE THE DRYING CYCLE. LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY CAUSE THE APPLIANCE TO OVERTURN, PUTING PEOPLE AT RISK. NEVER LEAVE THE DISHWASHER DOOR OPEN;...

  • Page 7: Installation And Hook-Up

    User instructions 2. Installation and hook-up Remove the polystyrene basket retainers. Position the appliance in the desired place of installation. The back or sides of the dishwasher may be placed up against walls or other furniture units. If the dishwasher is installed near a heat source, fit the special insulating panel to prevent overheating and malfunction of the appliance.
  • Page 8 User instructions CONNECTING TO THE WATER SUPPLY Connect the intake hose to a cold water supply with ¾” gas thread, inserting the filter A supplied with the dishwasher. Take care to screw the hose firmly into place with your hands and then complete by tightening about ¼...
  • Page 9 User instructions Electrical connection and precautions CHECK THAT THE VOLTAGE AND THE FREQUENCY OF THE MAINS MATCH THE RATINGS ON THE NAME PLATE OF THE APPLIANCE POSITIONED ON THE INNER EDGE OF THE DOOR. THE PLUG ON THE SUPPLY CORD AND THE CORRESPONDING SOCKET OUTLET MUST BE OF THE SAME TYPE AND MEET THE REGULATIONS IN FORCE.

  • Page 10: Description Of The Controls

    User instructions 3. Description of the controls Upper panel All the dishwasher controls are grouped on the upper panel. Switch-on, programming, switch-off etc. procedures are only possible when the door is open. ON/OFF BUTTON Pressing this button energises the appliance. SELECTED PROGRAM INDICATOR LIGHTS Illumination of this light denotes the program selected and the occurrence of a fault (troubleshooting).
  • Page 11 User instructions HALF LOAD BUTTON Press this button to activate the half load wash option. HALF LOAD LIGHT Illuminates to indicate that the function is activated. "3/1" OPTION (EXTRA OPTION) LIGHT Illuminates to indicate that the function is activated. PROGRAM DELAY BUTTON Press this button to delay the start of the program.
  • Page 12 User instructions DURATION CONSUMPTION PROGRAMME, LOAD CROCKERY AND PROGRAM NUMBER & CUTLERY PROGRESS MINUTES WATER POWER SYMBOL LITRES KWh (1) SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load. Cold prewash NORMAL ECO (*) Wash at 49°C 11,3 0,63 Delicate dishes with light dirt.
  • Page 13 User instructions SPEED WASH PROGRAMS (see relevant section for explanation of functioning modes) DURATION CONSUMPTION PROGRAMME PROGRAM LOAD CROCKERY AND NUMBER E PROGRESS MINUTI WATER POWER CUTLERY SYMBOL LITRES KWh (1) DELICATE Cold prewash SPEED Delicate dishes, with light Wash at 50°C 1,00 dirt.
  • Page 14 User instructions Washing programs Before starting a washing program make sure that: • The water supply tap is open. • The correct amount of detergent has been added to the dispenser. • The baskets have been correctly loaded. • The spray arms are able to rotate freely and without obstruction.
  • Page 15 User instructions EXTRA OPTIONS - “3/1” BUTTON (available in all programs except the soak program) Press buttons (SPEED PROGRAMS button + HYGIENE option button) simultaneously to activate the "3/1" option; the respective light comes on to confirm the selection. The option is designed for use of detergents which are complete with rinse aid, known on the market as "3 in 1", "triple action", etc.
  • Page 16 User instructions CANCELLING THE CURRENT PROGRAM • To cancel the currently selected program, open the door and hold down the PROGRAM SELECTION (3) button for a few seconds until the indicator lights for programs 4 and 5 illuminate simultaneously (the word "end" is displayed on the window). •...
  • Page 17 User instructions TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT • Always try to run the dishwasher fully loaded. • Do not rinse the dishes in running water. • Use the washing program that is most appropriate for each type of load.

  • Page 18: Operating Instructions

    User instructions 4. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows: • Add the rinse aid and detergent. Using the rinse aid and detergent dispensers detergent rinse dispensers are situated on the inner part of the door: the detergent dispenser is on the left, and the rinse aid dispenser is on the right.
  • Page 19 User instructions ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness. However it possible to change the setting by turning the dispenser’s selector to the desired position: the amount of rinse aid dispensed is proportional to the selector position.
  • Page 20 User instructions • When a program with hot prewash is selected (see program table), extra detergent must be placed in the cavity H. • Use only detergents specially formulated for dishwashers. For optimal washing results it is important to use a good quality detergent. •...
  • Page 21 User instructions General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading. There are generally no constraints on the washing of domestic dishes, but in certain cases it is necessary to take their characteristics into account.
  • Page 22 User instructions WARNING! • Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the washing cycle. • Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.
  • Page 23 User instructions Using the baskets The dishwasher has a capacity of 14 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling.
  • Page 24 User instructions LOADING THE LOWER BASKET Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples: CUTLERY BASKET The basket has removable top grids into which items of cutlery should...
  • Page 25 User instructions The cutlery basket slides across the dishwasher and can be placed in any position to allow optimal use of the space in the bottom basket. UPPER BASKET It is recommended to load the upper basket with small- or medium-sized items such as glasses, small plates, tea or coffee cups, shallow bowls and light objects made from heat resistant plastic.
  • Page 26 User instructions The dishwasher upper basket is equipped with the following accessories: Long-stemmed glass holder, on the left; to use, simply lift and fix onto the hooks provided. Cutlery racks, on the right, designed for knives and teaspoons; for teaspoons, pull out the sliding support. The racks can be tipped to the vertical position when not in use.

  • Page 27: Cleaning And Maintenance

    User instructions 5. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces.
  • Page 28 User instructions CLEANING THE FILTER UNIT • It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn them anticlockwise and lift upwards; • push the centre filter D from the underside to remove it from the micro-filter: •...
  • Page 29 User instructions BEFORE STARTING THE DISHWASHER AFTER PROLONGED NON USE: • Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. •...
  • Page 30 User instructions If the dishes fail to dry or remain dull, check that: • there is rinse aid inside the special container; • the rinse aid dispenser setting is correct; • the detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open).

  • Page 31: Troubleshooting

    User instructions 6. Troubleshooting The dishwasher is able to indicate a series of malfunctions by illuminating a number of lights simultaneously (see key below); “Err” also appears on the display in the event of a malfunction. FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only).
  • Page 32 User instructions FAULT DESCRIPTION Turbine flow-regulator malfunction (for the relevant models only) The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle.
  • Page 33 User instructions TECHNICAL DATA 597 ÷ 599 mm Width Depth measured flush with the 550 mm outer edge of the control panel Height from 820 mm to 890 mm Capacity 14 Standard place settings Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Electrical characteristics See rating plate...
  • Page 34 Notes:...

  • Page 35: Warranty And Service

    Purchase even though this warranty is in place will not bind Compass Capital Services trading as Kleenmaid to repair the appliance at no charge under this warranty and will require the Purchaser to pay for the service costs in full.
  • Page 36 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ranges Sinks Taps Compass Capital Services Pty Limited trading as Kleenmaid ABN 96138214525...
