- Page 1 To register your warranty or make a warranty claim, scan this QR code: kitchen collection Instructions for use and warranty details Fully Integrated Dishwasher Model No.: DW6031...
- Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.
-
Page 3: Table Of Contents
CONTENTS This manual is in two parts:- Part 1 General Care and Installation Part 2 Detailed Operating Instructions PART 1 General Care and Installation QUICK USER GUIDE SAFETY INFORMATION PRODUCT OVERVIEW USING YOUR DISHWASHER Basket Use Tips Tips for using Cutlery Tray MAINTENANCE AND CLEANING External Care Internal Care... - Page 4 PART 2 Detailed Operating Instructions USING YOUR DISHWASHER Control Panel Preparing And Loading Dishes Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir Filling The Detergent Dispenser PROGRAMMING THE DISHWASHER Wash Cycle Table Starting A Cycle Wash Changing The Program Mid-cycle Forget To Add A Dish? ERROR CODES...
-
Page 5: Quick User Guide
PART 1 General Care and Installation 01 QUICK USER GUIDE Please see the corresponding sections of the instruction manual for operating details. Install the dishwasher Please check PART 1 section 05 “INSTALLATION INSTRUCTIONS ” Inside Outside Loading the baskets Removing the larger residue on the dishes and cutlery Fill the dispenser with detergent Selecting a program and... -
Page 6: Safety Information
SAFETY INFORMATION WARNING When using your dishwasher, observe the precautions listed below: • This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments; -bed and breakfast type environments. - Page 7 • Do not place any heavy objects on or stand on the door when it is open. The appliance could tip forward. • When loading items to be washed locate sharp items so that they are not likely to damage the door seal. •...
-
Page 8: Earthing Instructions
Earthing Instructions • This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of an electric shock by providing a path of least resistance for electric current. This appliance is equipped with an earthing conductor plug. •... -
Page 9: Unpacking The Dishwasher
Disposal • To dispose of packaging and the appliance please go to a recycling centre. For safety, cut off the appliance power supply cable and disable the door closing device. • Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling. •... -
Page 10: Product Overview
02 PRODUCT OVERVIEW IMPORTANT: To get the best performance from your dishwasher, read all operating instructions (Part 1 and Part 2) before using it for the first time. Top spray arm Inner pipe Lower spray arm Filter assembly Dispenser Cup rack Upper spray arm Cutlery rack Upper basket... -
Page 11: Using Your Dishwasher
03 USING YOUR DISHWASHER Before using your dishwasher : Inside Outside 1. Loading the basket 2. Fill the rinse aid dispenser (Please check Part 2 Section 1) 3. Pour in detergent (Please check Part 2 Section 1) Basket Use Tips Adjusting the upper basket The height of the upper basket can be easily adjusted to accommodate taller dishes in either the upper or lower basket. - Page 12 Folding back the rack shelves The spikes are used for holding plates. They can be lowered to make more room for large items. raise upwards fold backwards Tips for use of Cutlery Rack Lift the right basket up, both left and right baskets are flat.
-
Page 13: Maintenance And Cleaning
04 MAINTENANCE AND CLEANING Your Kleenmaid appliance has been engineered and constructed to provide you with years of reliable service by way of its sophisticated components and quality finishes. In return, regular maintenance, in accordance with the following instructions, is required in order to allow it to continue serving you with its appearance and performance as well as it did on the day it was first installed. - Page 14 Coarse filter Coarse filter Main filter Main filter Fine filter Open Open Hold the coarse filter and rotate it The fine filter can be pulled off the anticlockwise to unlock the filter. bottom of the filter assembly. Lift the filter upwards and out of The coarse filter can be detached the dishwasher.
-
Page 15: Spray Arms
Spray arms It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arms, follow the instructions below: To remove the upper spray arm, To remove the lower spray arm, pull hold the nut in the centre still and out the spray arm upward. -
Page 16: Caring For The Dishwasher
Caring For The Dishwasher Frost precaution Please take frost protection precautions for the dishwasher in winter, especially if the ambient temperature is likely to be below 0'C. After every washing cycle, please operate as follows: 1. Cut off the electrical power to the dishwasher at the supply source. 2. -
Page 17: Installation Instruction
05 INSTALLATION INSTRUCTION NOTE: Before making preparations for commencing installation, the installer should refer to the current online version of the User Manual, which is available on the Kleenmaid website (see back cover for details). WARNING Electrical Shock Hazard Disconnect electrical power before installing dishwasher. -
Page 18: Water Supply And Drainage
Water Supply and Drainage Cold water connection Connect the cold water supply hose to a threaded 3/4 (inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear. -
Page 19: Connection Of Drain Hoses
Connection Of Drain Hoses Insert the drain hose into a drain pipe with a minimum diameter of 40mm, or let it run into the sink, making sure to avoid bending or crimping it. The height of the drain pipe must be less than 1000mm. The free end of the hose must not be immersed in water to avoid back flow. -
Page 20: Position The Appliance
Position The Appliance Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can be positioned either to the right or the left sides to facilitate proper installation. -
Page 21: Step 3. Tension Adjustment Of The Door Spring
Step 2. Decor panel dimensions and installation The decor panel dimensions should be in accordance with the template provided with the appliance. NOTE: The maximum allowable weight of the decor panel is 8kg. Install the hooks on the decor panel and put the hooks into the slot of the outer door of dishwasher (see figure A). - Page 22 Step 4. Dishwasher Placement 1. Affix the condensation strip under the work surface of cabinet. Please ensure the condensation strip is flush with edge of work surface. 2. Connect the inlet hose to the cold water supply. 3. Connect the drain hose. 4.
-
Page 23: Step 5. Levelling The Dishwasher
Step 5. Levelling the dishwasher The dishwasher must be level for proper dish rack operation and wash performance. Place a spirit level on door and rack track inside the tub as shown to check that the dishwasher is level. Level the dishwasher by adjusting the three levelling legs individually. When levelling the dishwasher, please be careful not to let the dishwasher tip over. -
Page 24: Troubleshooting Tips
O6 TROUBLESHOOTING TIPS Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Replace fuse or reset circuit breaker. Fuse blown, or the start Remove any other appliances sharing circuit breaker tripped. - Page 25 Problem Possible Causes What To Do Spilled rinse-aid. Always wipe up rinse-aid spills immediately. Stained tub interior Detergent with Make sure that the detergent has no colourant may colourant. have been used. White film on Hard water minerals To clean the interior, use a damp sponge with dishwasher detergent inside surface and wear rubber gloves.
- Page 26 Problem Possible Causes What To Do The dishes Not enough detergent Use more detergent, or change are not clean. was dispensed. your detergent. Items are blocking Rearrange the items so that the spray the movement of arms can rotate freely. the spray arms.
- Page 27 Problem Possible Causes What To Do With a short program, the washing The dishes are Wrong program has temperature is lower, decreasing cleaning not drying been selected. performance. Choose a program with a longer washing time. You may also use the Extra Drying function with selected programs - see Part 2 page 4.
-
Page 28: Loading The Baskets According To As/Nzs 2007.1
07 LOADING THE BASKETS ACCORDING TO AS/NZS 2007.1: 1.Upper basket: Item Number Cups Saucers Glasses Item Number Dinner plates Soup plates Dessert dishes... -
Page 29: Cutlery Basket
3.Cutlery basket: Item Number Forks Soup spoons Dessert spoons 4 4 4 Teaspoons Knives Information for comparability tests in accordance with (*AS/NZS 2007.1 ) Capacity: 15 place settings Position of the upper basket: lower position Program: ECO Rinse aid setting: 6 Detergent(Pre/main): 5g/28.75g Door is opened 50mm at the end of the drying cycle for the drying performance test. - Page 30 CONTENTS PART 2 Detailed Operating Instruction USING YOUR DISHWASHER Control Panel Preparing And Loading Dishes Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir Filling The Detergent Dispenser PROGRAMMING THE DISHWASHER Wash Cycle Table Starting A Cycle Wash Changing The Program Mid-cycle Forget To Add A Dish? ERROR CODES...
-
Page 31: Using Your Dishwasher
01 USING YOUR DISHWASHER Control Panel 10 11 Operation (Button) Press this button to turn on your dishwasher. The screen lights up. Power Press this button to select the appropriate washing program. Program The selected program indicator will light up. Press this button to set the delayed hours for washing. - Page 32 Display Auto Auto sensing wash, lightly, or heavily soiled crockery, with or with out dried-on food Intensive For heaviest soiled crockery, such as pots, pans, casserole dishes and dishes that have been sitting with dried food on them for a while. Heavy For heavily soiled loads, such as pots, plates, glasses and lightly soiled pans.
- Page 33 Display Power wash To wash very dirty, hard to clean dishes. (It can only be used with Intensive, Heavy, ECO, Glass, 90min.) Extra drying To dry dishes more completely. (It can only be used Function with Intensive, Heavy, ECO, Glass, 90min.) indicator Express Reduce the program time.
-
Page 34: Preparing And Loading Dishes
Preparing And Loading Dishes Consider buying utensils which are identified as dishwasher-proof. For particular items, select a program with the lowest possible temperature. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended. For washing the following cutlery/dishes dishwashers Are not suitable: Cutlery with wooden, horn, china or mother-of-pearl handles... -
Page 35: Removing The Dishes
Place objects in the dishwasher in the following way: Items such as cups, glasses, pots/pans, etc. should face downwards. Curved items, or ones with recesses, should be loaded aslant so that water can run off. All utensils are stacked securely and cannot tip over. All utensils are placed so that the spray arms can rotate freely during washing. -
Page 36: Loading The Upper Basket
Loading the upper basket The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans, as long as they are not too dirty. Position the dishes and cookware so that they will not be moved by the spray of water. -
Page 37: Function Of The Rinse Aid And Detergent
Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids. WARNING Only use branded rinse aid for dishwasher. - Page 38 aid reservoir cap Press gently on reservoir to close. To achieve a better drying performance with limited rinse aid, the dishwasher is designed to adjust the consumption by user. Follow the steps below: 1. Open the door, switch on the appliance. 2.
-
Page 39: Filling The Detergent Dispenser
Filling The Detergent Dispenser Open the cap by pressing down the release latch. Add detergent into the larger cavity (A) for the main wash. For a better cleaning result, especially if you have very dirty items, pour a small amount of detergent onto the door. The additional detergent will activate during the pre-wash phase. -
Page 40: Programming The Dishwasher
02 PROGRAMMING THE DISHWASHER Wash Cycle Table The table below shows which programs are best for the levels of food residue on dishes and how much detergent is needed. It also show information about the programs. )Means: need to fill the Rinse-Aid Dispenser. Description Energy Water... -
Page 41: Saving Energy
Description Energy Water Running Detergent Rinse Program Of Cycle (Kwh) Time(min) Pre/Main Wash(45℃) Rinse(55℃) 0.71 Rapid Rinse(55℃) Prewash 0.02 Soak NOTE: *AS/NZS 2007.1: This program is the test cycle. The parameters for the comparability test are in accordance with *AS/NZS 2007.1 Saving Energy 1. -
Page 42: Forget To Add A Dish
1. Open the door a little to stop the dishwasher, then after the spray arm stops working you can open the door completely. 2. Press Program button for more than three seconds so the machine will be in stand by state. 3. -
Page 43: Error Codes
03 ERROR CODES If there is a malfunction, the dishwasher will display an error code. The following table shows possible error codes and their causes. Meanings Codes Possible Causes Tap is not opened, or water intake is Longer inlet time. restricted, or water pressure is too low. -
Page 44: Technical Information
TECHNICAL INFORMATION 815mm (See Part 1 page 17) Height (H) 598mm Width (W) 550mm (with the door closed) Depth (D1) 1150mm (with the door opened 90°) Depth (D2) - Page 45 Product Data Manufacturer Kleenmaid Type / Description DW6031 Standard place settings Energy efficiency class Water consumption class Standard cleaning cycle Energy consumption of the standard cleaning cycle 0.62 kWh Water consumption of the standard cleaning cycle 12 litres Program duration of the standard cleaning cycle...
- Page 46 Kleenmaid Warranty, however, if repair is needed because of Product failure during normal Domestic Use, Kleenmaid has the option to repair or replace the defective Product or part of the Product with a product or part of like kind and quality.
- Page 47 Service under this warranty may be limited by the area in which you live. Service to remote and regional areas may incur additional travel costs which will be payable by you. You will be advised of this at the time you make a claim and Kleenmaid arranges to attend your premises.
- Page 48 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
