kitchen collection
Instructions for use and warranty details
To register your warranty or make a
warranty claim, scan this QR code:
Dishwasher
Model No.: DW6020X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW6020X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kleenmaid DW6020X

Summary of Contents for Kleenmaid DW6020X

  • Page 1 Instructions for use and warranty details To register your warranty or make a warranty claim, scan this QR code: Dishwasher Model No.: DW6020X...
  • Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.

  • Page 3: Table Of Contents

    CONTENTS This manual is in two parts:- Part 1 General Care and Installation Part 2 Detailed Operating Instructions PART 1 General Care and Installation QUICK USER GUIDE SAFETY INFORMATION PRODUCT OVERVIEW USING YOUR DISHWASHER Basket Use Tips MAINTENANCE AND CLEANING External Care Internal Care Caring For The Dishwasher...
  • Page 4 PART 2 Detailed Operating Instructions USING YOUR DISHWASHER Control Panel Preparing And Loading Dishes Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir Filling The Detergent Dispenser PROGRAMMING THE DISHWASHER Wash Cycle Table Starting A Cycle Wash Changing The Program Mid-cycle Forget To Add A Dish? ERROR CODES...

  • Page 5: Quick User Guide

    01 QUICK USER GUIDE Please see the corresponding sections of the instruction manual for operating details. Install the dishwasher Please check PART 1 section 05 “INSTALLATION INSTRUCTIONS ” Inside Outside Loading the baskets Removing the larger residue on the dishes and cutlery Selecting a program and Filling the dispenser running the dishwasher...

  • Page 6: Safety Information

    SAFETY INFORMATION WARNING When using your dishwasher, observe the precautions listed below: This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments;...
  • Page 7 Packaging material could be dangerous for children! This appliance is for indoor household use only. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid. Please unplug before cleaning and performing maintenance on the appliance.
  • Page 8 Do not modify the plug provided with the appliance. If it does not fit the outlet have a proper outlet installed by a qualified electrician. Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. Do not operate your dishwasher unless all enclosure panels are properly in place.
  • Page 9 Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent. For unmarked plastic items not so marked, check the manufacturer's recommendations. Use only detergent and rinse agents recommended for use in an automatic dishwasher. Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
  • Page 10 Disposal To dispose of packaging and the appliance please go to a recycling centre. For safety, cut off the appliance power supply cable and disable the door closing device. Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling.

  • Page 11: Product Overview

    IMPORTANT: To get the best performance from your dishwasher, read all operating instructions (Part 1 and Part 2) before using it for the first time. NOTE: Pictures are only for reference. Please check Part 2 for information specific to DW6020X.

  • Page 12: Using Your Dishwasher

    03 USING YOUR DISHWASHER Before using your dishwasher : Inside Outside 1. Loading the basket 2. Fill the rinse aid dispenser (Please check Part 2 Section 1) 3. Fill detergent dispenser (Please check Part 2 Section 1) Basket Use Tips Adjusting the upper basket The height of the upper basket can be easily adjusted to accommodate taller dishes in either the upper or lower basket.
  • Page 13 Folding back the cup shelves To make room for taller items in the dishwasher basket, raise the cup rack upwards. You can then lean the tall glasses against it. You can also remove it when it is not required for use. Folding back the rack shelves The spikes are used for holding plates.

  • Page 14: Maintenance And Cleaning

    04 MAINTENANCE AND CLEANING External Care The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door.These surfaces are outside the wash cabinet and are not accessed by water from the spray arms.
  • Page 15 Coarse filter Coarse filter Main filter Main filter Fine filter Open Open Hold the coarse filter and rotate it The fine filter can be pulled off the anticlockwise to unlock the filter. bottom of the filter assembly. Lift the filter upwards and out of The coarse filter can be detached the dishwasher.
  • Page 16 Spray arms It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arms, follow the instructions below: To remove the upper spray arm, To remove the lower spray arm, pull hold the nut in the centre still and out the spray arm upward.

  • Page 17: Caring For The Dishwasher

    Caring For The Dishwasher Frost precaution Please take frost protection precautions for the dishwasher in winter, especially if the ambient temperature is likely to be below 0'C. After every washing cycle, please operate as follows: 1. Cut off the electrical power to the dishwasher at the supply source. 2.

  • Page 18: Installation Instruction

    05 INSTALLATION INSTRUCTION NOTE: Before making preparations for commencing installation, the installer should refer to the current online version of the User Manual, which is available on the Kleenmaid website (see back cover for details). WARNING Electrical Shock Hazard Disconnect electrical power before installing dishwasher.

  • Page 19: Water Supply And Drain

    Water Supply And Drain Cold water connection Connect the cold water supply hose to a threaded 3/4 (inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear.

  • Page 20: Connection Of Drain Hoses

    Connection Of Drain Hoses Insert the drain hose into a drain pipe with a minimum diameter of 40mm, or let it run into the sink, making sure to avoid bending or crimping it. The height of the drain pipe must be less than 1000mm. The free end of the hose must not be immersed in water to avoid back flow.

  • Page 21: Position The Appliance

    Position The Appliance Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can be positioned either to the right or the left sides to facilitate proper installation.
  • Page 22 Attention 1. The height of the dishwasher under the benchtop may also be adjusted by screwing the adjustable feet in either direction. 2. The maximum adjustable leg extension height used for determining the maximum height of free-standing/built-under models is 25mm. See height range in the table below.
  • Page 23 O6 TROUBLESHOOTING TIPS Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Replace fuse or reset circuit breaker. Fuse blown, or the start circuit breaker tripped.
  • Page 24 Problem Possible Causes What To Do Spilled rinse-aid. Always wipe up rinse-aid spills immediately. Stained tub interior Detergent with Make sure that the detergent has no colourant may colourant. have been used. White film on Hard water minerals To clean the interior, use a damp inside surface sponge with dishwasher detergent and wear rubber gloves.
  • Page 25 Problem Possible Causes What To Do The dishes Not enough detergent Use more detergent, or change are not clean. was dispensed. your detergent. Items are blocking Rearrange the items so that the spray arms can rotate freely. the movement of the spray arms.
  • Page 26 Problem Possible Causes What To Do The dishes are Wrong program has With a short programme, the not drying been selected. washing temperature is lower, decreasing cleaning performance. Choose a programme with a longer washing time. Use of cutlery with a Water drainage is more difficult with low-quality coating.
  • Page 27 07 LOADING THE BASKETS ACCORDING TO AS/NZS 2007.1:...
  • Page 28 3.Cutlery basket: Item Number Forks Soup spoons Dessert spoons 4 4 4 Teaspoons Knives Information for comparability tests in accordance with (*AS/NZS 2007.1 ) Capacity: place settings Position of the upper basket: lower position Program: ECO Rinse aid setting: 6 Detergent(Pre/main): 5g/25g Door is open at the end of the drying cycle for the drying performance test (Door position: Open 50 mm)
  • Page 29 PART 2 Detailed Operating Instructions USING YOUR DISHWASHER Control Panel Preparing And Loading Dishes Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir Filling The Detergent Dispenser PROGRAMMING THE DISHWASHER Wash Cycle Table Starting A Cycle Wash Changing The Program Mid-cycle Forget To Add A Dish? ERROR CODES...
  • Page 30 For better drying results. (It can only be used with Extra Drying Intensive, Heavy, ECO, Glass and 90 min.)
  • Page 31 light up...
  • Page 32 Preparing And Loading Dishes Consider buying utensils which are identified as dishwasher-proof. For particular items, select a program with the lowest possible temperature. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended. dishwashers:- For washing the following cutlery/dishes Are not suitable:...
  • Page 33 Place objects in the dishwasher in the following way: Curved items, or ones with recesses, should be loaded aslant so that water can run off. All utensils are stacked securely and cannot tip over. All utensils are placed so that the spray arms can rotate freely during washing. Check before starting dishwasher.
  • Page 34 Loading the upper basket The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty). Position the dishes and cookware so that they will not be moved by the spray of water.
  • Page 35 Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids. WARNING Only use branded rinse aid for dishwasher.
  • Page 36 Remove the rinse aid reservoir Pour the rinse aid into the dispenser, being careful not to cap by turning it to Open icon (anticlockwise, see arrow). overfill. Open icon rotating it clockwise right arrow). The recommended setting, as set by the factory, is "4". If the dishes are not drying properly or are spotted, adjust the dial to the next highest number until your dishes are spot free.
  • Page 37 Please be aware that the amount of detergent required may vary according to the level of soiling and the specific hardness of the water.
  • Page 38 dishes...
  • Page 39 parameters For power supply information refer to ”Product data” on the last page. Make sure that the water supply is turned on to full pressure. then should have...
  • Page 41 ashes flash ashes...
  • Page 43 data standby under?
  • Page 44 This page is intentionally left blank.
  • Page 45 This page intentionally left blank.
  • Page 46 Kleenmaid Warranty, however, if repair is needed because of Product failure during normal Domestic Use, Kleenmaid has the option to repair or replace the defective Product or part of the Product with a product or part of like kind and quality.
  • Page 47 Service under this warranty may be limited by the area in which you live. Service to remote and regional areas may incur additional travel costs which will be payable by you. You will be advised of this at the time you make a claim and Kleenmaid arranges to attend your premises.
  • Page 48 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
