Page 1: Installation Instructions
Installation Instructions 27" and 30" Warming Drawers Models: ZKD910 ZTD910 31-10700-1 10-08 JR... -
Page 2: Before You Begin
Read these instructions completely and carefully. This appliance must be properly grounded. See “Grounding the Appliance.” IMPORTANT • Save these instructions — For Monogram local service in your area, for local inspector’s use. 1.800.444.1845. IMPORTANT • Observe all governing —... -
Page 3: Table Of Contents
The warming drawers may be installed directly into a wall or wall oven cabinetry, or below ZTD910 a countertop. 27" Wide Model: ZKD910 FRONT PANEL ACCESSORIES ZXD27B, ZXD30B: JXPN2: This kit provides for the installation of a custom Warming drawer pan kit. This kit includes supports front panel on 27"... -
Page 4: Product Dimensions
ZTD910 22" 26" 30" ZTD910 w/ZXD30P 23-1/4" 27-1/2" 30" ZKD910 22" 26" 26-3/4" ADVANCE PLANNING • Electrical power cord is located on the right side • The drawer may be installed below a countertop, of the warming oven. Locate the outlet within reach a cooktop, a single or double oven and side by side of the 56"... -
Page 5: Grounding The Appliance
Design Information GROUNDING THE APPLIANCE Please read carefully. FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE PROPERLY GROUNDED. Do not use an extension cord or adapter plug with this appliance. Follow National electrical codes or prevailing local codes and ordinances. Recessed Receptacle 7"... -
Page 6: Installation Preparation
Installation Preparation TOOLS REQUIRED MATERIALS REQUIRED (provided) 4 Wood Screws Safety Glasses Hand Saw MATERIALS REQUIRED (not provided) Drill and Measuring Tape 1/16" Bit 2x2 or 2x4 Level 2x2 or 2x4 Lumber for Phillips Screwdriver Wood Block Runners for Anti-Tip Security Adhesive or other hardware for installing runners or shelf to support warmer drawer... -
Page 7: Installation Options
ZTD910 28-1/2" 30" above the Warming Drawer location does not obstruct above the Warming Drawer location does not obstruct ZKD910 25-1/2" 26-3/4" the required interior 23-1/2" depth and 9-1/4" height. the required interior 23-1/2" depth and 9-1/4" height. When installed under a wall oven: The rough opening for the drawer must be: –... -
Page 8: Installation Below A Countertop
Dimensions 1/4" Air ZTD910 28-1/2" ZKD910 25-1/2" 23-1/2" Min. *NOTE: When installing the warming drawer below a cooktop, a solid barrier must be installed at least 1" from the lowest point of the bottom of cooktop burner box to the top Install a Solid Barrier and of cutout. -
Page 9: Provide Cabinet Support
Installation PROVIDE CABINET SUPPORT 2"x4" or 2"x4" or Equivalent Runners Equivalent Runners 23-1/2" 23-1/2" 22" 25" 27" 30" IMPORTANT: When installed below a single or double oven, check to be sure •The support must be level and rigidly mounted, that any oven supports above the cutout do not obstruct the 23-1/2" required depth flush with the bottom edge of the cutout. -
Page 10: Custom Panel Accessory Kit Installation
WARMING DRAWER CUSTOM Installation PANEL ACCESSORY KIT ZXD27B AND ZXD30B Instructions For installation of 27" and 30" wide warming drawer custom panel and custom handle. BEFORE YOU BEGIN STEP 1 PREPARE DRAWER Read these instructions completely and carefully. FOR PANEL INSTALLATION IMPORTANT •... -
Page 11: Zkd910
Installation STEP 4 STEP 6 INSTALL LAMP JEWEL SECURE CUSTOM PANEL TO METAL MOUNTING PANEL Turn the assembly appearance side up. • Use plastic to wood adhesive to secure the lamp • Lay the custom panel, appearance side down, jewel to the front of the wood panel. On the side on a clean surface. -
Page 12: This Zxd30P Accessory Is Designed To Fit 30" Warming Drawers Manufactured After February
Installation PROFESSIONAL STYLE PANEL ACCESSORY KIT Instructions ZXD30P BEFORE YOU BEGIN STEP 2 REMOVE ORIGINAL Read these instructions completely and carefully. DRAWER FRONT IMPORTANT Save these instructions • Remove the three screws from the bottom • – of the drawer edge. for local inspector’s use. -
Page 13: Zkd910
Notes... -
Page 14: Zkd910
Notes... -
Page 15: Zkd910
Notes... -
Page 16: Zkd910
NOTE: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram ® local service in your area, call 1.800.444.1845. NOTE: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice.
