- Page 1 Service Manual No-Frost Combi-Refrigerator Models: ERF-364MBB, ERF-364MBW, ERF-364MBI, ERF-364MBT ERF-384MBB, ERF-384MBW, ERF-384MBI, ERF-384MBT DAEWOO ELECTRONICS MANUFACTURING ESPAÑA, S.A.
-
Page 2: Table Of Contents
. CONTENTS 1. SPECIFICATIONS 2. EXTERNAL DRAWINGS 3. MACHINE ROOM VIEW 4. REFRIGERANT CYCLE 5. WIRING DIAGRAM 6. COMPONENTS DISASSEMBLY PICTURES 7. DOOR POSITION CHANGE PROCESS 8. EXPLODE DRAWING 9. PARTS LIST... -
Page 3: Specifications
1. SPECIFICATIONS Model name 366MNL 386MNL 396MNL 416MNL Division MECHANIC TYPE Refrigerant type R-134A Refrigerant Q´ty 100 grs Blowing agent C-PENTANE Cooling system Fan cooling system Defrost system Automatic start & Automatic stop system Compressor KPC CBE-140L5Z Rated voltage AC220~240V / 50Hz Rated input (W) Lamp rated input (W) Freezer... -
Page 4: External Drawings
2. EXTERNAL DRAWINGS MODEL 1722 862.5 621.5 1765 ERF-366M 621.5 1098 993.5 ERF-396M 1896 1853 638.5 ERF-386M 710.5 1854 1811 862.5 1098 993.5 710.5 1985 1942 ERF-416M 32.5 595.2... -
Page 5: Machine Room View
4. MACHINE ROOM VIEW SCREW MACHINE... -
Page 6: Refrigerant Cycle
5. REFRIGERANT CYCLE CAPILLARY TUBE... -
Page 7: Wiring Diagram
6. WIRING DIAGRAM... -
Page 8: Components Disassembly Pictures
7. COMPONENTS DISASSEMBLY PICTURES - 1 SWITCH DOOR - Force switch door to the left side and input a thin driver in the rigth part as picture shows. After this operation, lift switch up. * Remark: Input driver carefully in order to lift up easily and avoid paint damages and scratches. - Page 9 - 2 MULTI DUCT - Unscrew all fixed screws. - Remove insulator multi-duct. - Unscrew defrost timer and thermostat. - Take out temperature control knob by a minus driver carefully.
- Page 10 3- GASKET. 3.1- Take out the gasket as shown. 3.2- Fix the new one. 4- FREEZER COMPARTMENT. 4.1- Remove 3 fixing screws. 4.2- To prevent damage, remove louver using method as illustrated.
- Page 11 4.3- Remove 2 fixing screws of louver FB. 4.4- Take out louver FB by hand, and disconnect fan motor housing. 4.5- Disconnect all housing conectors. 4.6- Unscrew evaporator and move it carefully to prevent excessive bending of gas pipes.
-
Page 12: Door Position Change Process
8. DOOR POSITION CHANGE PROCESS STEP 1 : Remove door Follow to remove 1. Remove“ COVER HINGE” and “ HINGE T” 2. Remove“ R” door. 3. Remove “ HINGE M” 4. Remove“ F” door 5. Remove“COVER BRACKET” 6. Remove“ HINGE U” STEP 2 : Change door handle 7. - Page 13 door open side STEP 3 : Change the position of door 11. Attach the“ HINGE U” on the left. 12. Attach the“ F DOOR” 13. Reverse the position of “ HINGE M” and “ CAP SCREW HOLE” 1. Attach the“ R DOOR” 15.
- Page 15 CODE Nº 3017839400 GLASS SHELF (INSERT TYPE) '04 4,54 3001402200 COVER GLASS V/CASE (INSERT TYPE) ERF**4 3,10 DMS1181980 CASE VEGETABLE *L '04 TRANSPARENT DAEWOO 2006 4,70 DMS1182080 CASE VEGETABLE *R '04 TRANSPARENT DAEWOO 2006 4,70 3011163200 CASE ICING 0,51 DMS1115950 CASE FD (WITHOUT PRINTING)
- Page 16 DMS1A00100 SWITCH OL 4TM232RHBYY-53 (KPC) 1,75 3817923600 SWITCH OL 4TN 129NHBYY (DAEWOO) 1,68 DMS1C00100 SWITCH PTC PTH7M330MD2 (KPC) 1,52 3817915400 SWITCH PTC (FROM DONG CHANG) (DAEWOO) 1,39 DMS1200100 CLAMP CORD A (KPC) 0,11 3810506400 RELAY BOX (DAEWOO) 0,65 DMS1200200 CLAMP CORD B (KPC)
- Page 17 3014003400 PACKING BAR HANDLE SUPPORT ASSY 16,55 3016032500 SCREW MACHINE FLT 4X8 STS 0,10 DMS6006000 SPECIAL SCREW G 0,10 DMS6032400 WRENCH ALLEN 3mm 0,50 DMS0A00100 COMPRESSOR C-BE 140L5Z (KPC) 53,05 3956158K50 COMPRESSOR DAEWOO YX58LHP5 58,64 3013595400 EMBLEM DAEWOO LETTERS '04 (CHROME) 1,87...
- Page 18 DAEWOO ELECTRONICS MANUFACTURING ESPAÑA S.A Polígono industrial de Júndiz C/Zurrupitieta 27, 01015 Vitoria, Spain Tel: 00 34 945292292 Fax:00 34 945290965...
