Summary of Contents for Kleenmaid FEG 600 X
Page 1
DUAL FUEL COOKER Instructions for Use and Warranty Details Model FEG 600 X THE WORLD’S BEST...
Page 2
Kleenmaid appliance. This appliance has been designed and manufactured to give you years of reliable performance. For best results, carefully read the instructions on how to install your new appliance. Correct installation will avoid delays and unnecessary service calls.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS After having unpacked the appliance, check to ensure that it is not damaged. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as these may cause serious injures.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR USE OF ELECTRICAL APPLIANCES Use of any electrical appliance implies the necessity to follow a series of fundamental rules. In particular: Never touch the appliance with wet hands or feet. Do not operate the appliance barefooted. Do not allow children or other incapable people to use the appliance without your supervision.
If when lighting any of the burners an abnormal flame appears, switch that the burner off and relight using the minimum setting. If the flame is still different from normal, turn the burner off and consult your Kleenmaid service agent.
CHOICE OF THE BURNER The burner must be chosen according to the diameter of the pans and energy required. Burners Pot diameter Auxiliary 16 cm Semi-rapid 16 to 22 cm Fig. 4 Double-ring up to 30 cm max 36 cm Saucepans with handles which are excessively heavy, in relationship to the weight of the pan, are safer as they are less likely to tip.
MULTIFUNCTION OVEN GENERAL FEATURES This oven features 7 different programs to satisfy every cooking need. The 7 positions, thermostatically controlled, are obtained by 4 heating elements. OPERATING PRINCIPLES Heating and cooking in the MULTI-FUNCTION oven are obtained in the following ways: by normal convection The heat is produced by the upper and lower heating elements.
Fig. 7 FUNCTION SELECTOR KNOB THERMOSTAT KNOB Rotate the knob clockwise to set the oven This only sets the cooking temperature and for one of the following functions. does not switch the oven on. Rotate clockwise until the required temperature is reached (from 50 to 250°C). OVEN LIGHT By setting the knob to this position, only the oven light comes on (15 W).
GRILLING The infrared grill element at the top of the oven comes on. The heat is dispersed by radiation. Use with the function knob set to , the thermostat knob from 50 to 200°C and with the oven door closed. For cooking hints, see the chapter “USE OF THE GRILL”.
MAINTAINING TEMPERATURE AFTER COOKING OR SLOWLY HEATING FOODS The upper element, the circular element and the fan come on. The heat is circulated by forced convection with greater intensity in the upper part. The temperature can be set to between 50° and 150°C via the thermostat knob. Recommended for: Keeping food warm after any type of cooking.
SIMULTANEOUS COOKING OF DIFFERENT FOODS The oven set on position can cook several different foods together. Foods as diverse as fish and cakes can be cooked together without the cross transference of flavours. This is because the fats and cooking smell that would normally be deposited on the different foods are oxidised and are not absorbed by the foods.
RECOMMENDED COOKING TEMPERATURES Food °C °F Shelf Cooking Mark Position * Time (approx) CAKES Victoria sandwich 2 or 3 20-25 mins Small cakes/buns 1 and 2 15-20 mins Maidera cake 2 or 3 20 mins Fruit cake 1 ¾ hours Rich fruit cake 3 or 4 2 ½...
ELECTRONIC CLOCK/END COOKING TIMER The electronic clock / end cooking timer is a device with the following functions: > 24 hours clock with illuminated display; > Timing of oven cooking with automatic switch-off (max. 99 minutes). ELECTRONIC CLOCK Upon immediate connection of the cooker or after a mains failure, three zeros will flash on the programmer panel.
USE AND CARE CAUTION This appliance must be used only for task it has explicitly been designed for, that is for cooking foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous. Do NOT place combustible materials or products on this appliance at any time. Do NOT spray aerosols in the vicinity of this appliance while it is in use.
GREASE FILTER A special screen is provided at the back of the oven to catch grease particles, mainly when meat is being roasted (fig. 10). When baking pastry etc. this filter should be removed. Always clean the filter after cooking as any solid residues on it might adversely affect the oven performance.
Spillage on the hob can usually be removed by a damp soapy cloth. More obstinate stains can be removed by rubbing gently with a soapy scouring pad or mild household cleaner. GAS TAPS If a tap becomes stiff, do not force; contact your local Kleenmaid Service Agent.
Page 18
BURNERS These can be removed and washed only with soapy water. Detergents can be used but they must not be abrasive or corrosive. Do not use abrasive sponges or pads. Do not put in dishwasher. After each cleaning, make sure that the burner-caps, as well as the burners, have been well wiped off and CORRECTLY POSITIONED.
Advice for use and maintenance of catalytic panels. The catalytic panels are covered with special microporous enamel which absorbs and does away with oil and fat splashes during normal baking over 200°C. If, after cooking very fatty foods, the panels remain dirty, operate the oven “idling” on max temperature for about 30 minutes.
O V E N D O O R A N D Fig. 16A DRAWER The internal glass of the oven door can be easily removed for cleaning by unscrewing the two lateral fixing screws (fig. 13). The drawer (fig. 14) comes out like a normal drawer.
INSTALLATION CAUTION: In order to avoid a hazard this appliance must be installed according to these instructions for installation. The appliance should be installed and serviced by a registered technician in compliance with AG 601 or NZS 5261. Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury or damage.
Page 22
CLEARANCES Installation clearances and protection of combustible surfaces shall comply with NZS 5261 Appendix F1.2 or section S 12 of AG 601. Installation shall comply with the Dimension in fig. 17 bearing in mind: Overhead Clearances In no case shall clearances between the highest part of the cooker be less than 600mm or for an overhead exhaust fan 750mm.
ASSEMBLING THE BACKGUARD Before assembling remove any protective film/adhesive tape. The backguard B and the side supports S and D can be found packed in the drawer. Insert the side supports S and D into the backguard B (see fig. 18). Insert the backguard group into the support guides in the cooker.
GAS SUPPLY: The connection must be executed by an authorised person according to the relevant standards. This appliance is suitable for use with Natural Gas or LPG (Check the “gas type” sticker attached to the appliance). For Natural Gas models the gas supply is connected to the pressure regulator which is supplied with the appliance.
LEVELLING The cooker is equipped with 4 levelling feet which must be fitted to the base of the cooker in the following manner: Place the cooker on its back as shown in the figure 22. Screw the 4 levelling feet to the cooker. Stand the cooker and level it by screwing or unscrewing the feet with a spanner.
INJECTORS REPLACEMENT This appliance is suitable for use with Natural Gas or LPG (check the “gas type” sticker attached to the appliance). The nominal gas consumption and injector size details are provided in table at page 28. To replace the injectors it is necessary to lift the cooktop and proceed as follows: Remove the backguard “G”...
Page 27
PRIMARY AIR ADJUSTMENT OF THE BURNERS By operating the screw “M”, reset the air adjuster “A” according to the instructions (see “Table for the choice of the injectors”), where the distance between injector and air adjuster is recommended (in mm). Before refixing the hob top, replace the burners on their sites and light them in order to check whether the flames are correct, as per the specifications given below.
TABLE FOR THE CHOICE OF THE INJECTORS Natural gas Propane Test Point Pressure (kPa) 2,75 Primary air Primary air Nominal Reduced Injector Injector shutter shutter Power Power Orifice Dia. Orifice Dia. BURNER opening opening [mm] [mm] [kW] [kW] [mm] [mm] Auxiliary (A) 0,25 0,83...
Consumer, have under the relevant laws in respect of this appliance, during your first one year of ownership as the original purchaser of the Kleenmaid appliance, we guarantee that any fault caused by faulty material or workmanship becoming apparent, will be rectified free of charge for parts and labour, provided that all service is performed during normal working hours by Kleenmaid or their designated Agents.
Page 32
Descriptions and illustrations in this booklet are given simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without notice, to make eventual necessary modifications for their construction or for commercial needs. Other products in Kleenmaid’s range of world’s best appliances: Washers...
