- Page 1 KLEENMAID TECHNICAL & SPARE PARTS MANUAL OVENS TO80S, TO81W, TO82B TO90S, TO91W, TO92B August, 2000...
- Page 2 TABLE OF CONTENTS TITLE PAGE Wiring Diagram TO80S, TO81W & TO82B……………………………………….. Wiring Diagram TO90S, TO91W & TO92B……………………………………….. TO80’S & TO90’S Exploded view & Spare Parts - Internal……………………. TO80’S & TO90’s Exploded view & Spare Parts - Body……………………….. TO80’S & TO90’S Exploded view - Front…………………………………………...
- Page 3 TO80 NORMAS DE APLICACION CARACTERISTICAS SIGNIFICATIVAS Valor Descripcion obtener 1a - 7a-8a 10a-11a 12a-13a 14a-15a POSITIONS 9 10 FUNCTIONS 1. LIGHT CIRCUIT 2. THERMOSTAT 3. SWITCH = GREEN-YELLOW COLOUR 4. SWITCH = RED COLOUR 5. THERMOSTAT = BLUE COLOUR 6. OVEN LIGHT 7.
- Page 4 TO90 NORMAS DE APLICACION CARACTERISTICAS SIGNIFICATIVAS Valor Descripcion obtener POSITIONS FUNCTIONS 1a-2A-3A-4A-5A 7a-8A-9A-10A = GREEN-YELLOW COLOUR = RED COLOUR = BLUE COLOUR TERMINAL WITH COVER 1. LIGHT CIRCUIT 2. LIGHT CIRCUIT 3. THERMOSTAT 4. SWITCH 5. SWITCH 6. THERMOSTAT 7. OVEN LIGHT 8.
- Page 5 EXPLODED VIEW & TO80S, TO81W, TO82B SPARE PARTS LIST - TO90S, TO91W, TO92B INTERNAL ITEM PART NOS DESCRIPTION Fan cover (roast probe) FC91A009C4 Fan cover FCC3B00019 Panel FCC3B001B5 Self cleaning panel...
- Page 6 TO80S, TO81W, TO82B EXPLODED VIEW & TO90S, TO91W, TO92B SPARE PARTS LIST BODY ITEM PART NOS DESCRIPTION FCA6A000B2 Frame – 22.05.00 FCA8C00110 Frame – 23.05.00 FCA7A001A2 Oven seal door FC90A002A9 Rack spit roast FCB8B001A2 Wire shelf – grill FCB8C002A6 Oven shelf...
-
Page 7: Exploded View Front
EXPLODED TO80S, TO81W, TO82B VIEW TO90S, TO91W, TO92B FRONT... - Page 8 TO80S, TO81W, TO82B SPARE PARTS LIST TO90S, TO91W, TO92B FRONT ITEM PART NOS DESCRIPTION FC23F003S4 Panel rear control FCL9A08214 Control panel – s/steel – Prior to June 2000 FCL9A03622 Control panel – s/steel FCL9A08312 Control panel – white – Prior to June 2000 FCL9A03720 Control panel –...
-
Page 9: Exploded View Internal
EXPLODED TO80S, TO81W, TO82B VIEW INTERNAL... - Page 10 SPARE TO80S, TO81W, TO82B PARTS LIST INTERNAL ITEM PART NOS DESCRIPTION FC11P000A2 Main switch FC43G000A3 Timer electronic FC18R003A3 Timer knob – black FC18R003B9 Timer knob – white FCA5A007A3 Element top FCL1A006A8 Thermostat over temperature FC46A008C6 Fan motor FC97A002A4 Spit motor...
- Page 11 EXPLODED TO90S, TO91W, TO92B VIEW INTERNAL...
- Page 12 TO90S, TO91W, TO92B SPARE PARTS LIST INTERNAL ITEM PART NOS DESCRIPTION FC07H001A5 Lamp lens red – Prior to June 2000 FC07H000B3 Lamp lens red – Tear drop shape FC11P003A6 Main switch FC09C003A8 Timer alarm clock FCA5A007A3 Element top FCL1A006A8 Thermostat over temperature FC46A008C6 Fan motor FC07H002A3 Lens orange –...
- Page 13 TO90S, TO91W, TO92B - KNOBS ITEM NO PART NUMBER DESCRIPTION DETAILS FC18Q000S7 TIMER KNOB & BEZEL BLACK KEY SHAFT TO90 TO92 PRE 06/00 FC18P013A7 KNOB BLACK KEY SHAFT TO90 TO92 PRE 06/00 FC20J004B3 TEMPERATURE BEZEL BLACK KEY SHAFT TO90 TO92 PRE 06/00 FC20J002B7 FUNCTION BEZEL BLACK KEY SHAFT TO90 TO92 PRE 06/00...
