Golden Blount SUPER-FIRE SF3624-TV Installation And Operating Instructions Manual

Top-vent fireplace
Hide thumbs

Advertisement

Table of Contents

INSTALLER/CONSUMER RETAIN THIS APPLIANCE
MANUAL WITH THE INSTALLED APPLIANCE

INSTALLATION AND OPERATING INSTRUCTIONS

MODEL SF3624-TV TOP-VENT FIREPLACE
IMPORTANT! Read all instructions carefully before starting
installation. Failure to follow these instructions may result in
property damage, personal injury or possible loss of life.
WARNING: If the information in these
instructions is not followed exactly, a
fire or explosion may result causing
property damage, personal injury or
death.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL
GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your
building;
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas
supplier, call the fire department.
– Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
MANUFACTURED BY:
4301 WESTGROVE DRIVE
ADDISON TX. 75001
GOLDEN BLOUNT
SUPER-FIRE
CSA APPROVED FOR NATURAL GAS OR PROPANE GAS
■ The Flue Damper must be in the
full open position when burning the
gas logs.
■ This fireplace is to be burned only
with the gas log set supplied with the
fireplace. Burning other items could
cause a fire hazard or injury.
■ For best results, Natural Gas pressure
should be 7" to 12" W.C. and 11" W.C.
for Propane Gas.
■ To simulate real wood burning, the gas
burner is designed to burn a yellow
flame. It is normal for the logs to soot-
up. The soot can be easily removed
with a vacuum cleaner or soft brush.
■ Check the label on the firebox to
assure the proper gas type. Never
use anything but the correct gas type
for your fireplace.
This appliance complies with National
Safety and is tested and listed to ANSI
Z21.50b - 2009 as Vented Gas fireplaces.
Installation must conform to local codes.
In the absence of local codes, installation
must conform with the current National
Fuel Gas Code, ANSI Z223.1.
Massachusetts State Code requires
damper to be welded open or removed.
2/05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPER-FIRE SF3624-TV and is the answer not in the manual?

Questions and answers

John Horton
May 5, 2025

I have two of the SF3624-TV gas fireplaces in my home. Over the 13 years since the home was built we have used each unit 10-15 times. I recently was wanting to use them - followed the normal steps and got the pilot lights lit but in turning the control knobs to On, it seems no gas is feeding through to start the main burners. I have opened the damper and nothing happens. What have I forgotten to do? What should I check? Thank you for any help. John Horton 864 423 5268

0
1 comments:
Mr. Anderson
May 17, 2025

If the main burners of the Golden Blount SF3624-TV gas fireplace do not ignite after lighting the pilot lights, check the following:

1. Ensure the pilot flame is steady and properly engulfing the top 1/4 inch of the flame sensor.
2. Make sure there are no obstructions to the flow of combustion and ventilation air.
3. Verify the area around the appliance is clear of combustible materials and obstacles.
4. Confirm all components are approved and properly installed.
5. If issues persist, contact a qualified service technician.

This answer is automatically generated

0

Related Manuals for Golden Blount SUPER-FIRE SF3624-TV

Summary of Contents for Golden Blount SUPER-FIRE SF3624-TV

  • Page 1: Installation And Operating Instructions

    MANUAL WITH THE INSTALLED APPLIANCE INSTALLATION AND OPERATING INSTRUCTIONS GOLDEN BLOUNT SUPER-FIRE MODEL SF3624-TV TOP-VENT FIREPLACE CSA APPROVED FOR NATURAL GAS OR PROPANE GAS IMPORTANT! Read all instructions carefully before starting installation. Failure to follow these instructions may result in property damage, personal injury or possible loss of life.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION Layout Options ......................2 Identification of Parts ..................... 3 Building Codes and Safety Standards ................4 Piping and Gas Pressure Requirements ................ 5 Installation Instructions ....................6 Brick Panels, Exhaust and Downdraft Diverter Instructions (Refractory Models) ..9 Log Placement .......................11 Operating Guidelines (Millivolt Models) ................
  • Page 3 SF3624-TV TOP-VENT FIREPLACE Damper Control Lever Stand Offs Valve Access Panel Outside Air Port INTERIOR VIEW Damper Control Lever Pan Burner Pilot Light Outside Air On/Off Switch Control Knob...

  • Page 4: Building Codes And Safety Standards

    Institute National Fuel Gas Code Z223.1 latest edition. GENERAL INFORMATION MODEL SF3624-TV IS A TOP-VENTED DECORATIVE GAS APPLIANCE. IT IS DESIGNED TO BURN BY DRAWING COMBUSTION AIR FROM THE OUTSIDE AIR KIT THAT ATTACHES TO THE LEFT SIDE OF THE FIREPLACE.

  • Page 5: Piping And Gas Pressure Requirements

    GAS PIPING AND GAS PRESSURE REQUIREMENTS All gas piping must be installed to comply with local codes, or, in the absence of local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1. Unions in gas lines shall be of ground joint type. Compounds used on threaded joints of gas piping must be resistant to the action of liquefied petroleum gas.

  • Page 6: Installation Instructions

    Model SF3624-TV (with the use of the Outside Air Kit) can be installed in a bedroom (in the United States) which has a total volume of unconfined space appropriate to the particular installation.
  • Page 7 10' Rule of Thumb indicates a shorter chimney height. Note: Installations which will not allow the 10' rule to be followed must be submitted to Golden Blount Inc. for approval. 1-800-833-1139.

  • Page 8: Hearth Extension

    Installing Outside Air Kit Model SF3624-TV is supplied with the component parts for outside combustion with the exception of the 4" flex duct. It is recommended that the outside air system be used whenever possible. Connect 4" Class-1 Flex duct or Metal Vent to duct collar on side of firebox, run duct to fresh air source and terminate using duct termination cap.
  • Page 9 AND EXHAUST DIVERTER SF3624 SUPERFIRE FIREPLACE This model Golden Blount top vent fireplace is supplied with high quality realistic Refractory Brick Panels. These panels are massive and must be field-installed to prevent damage to panels or fireplace during shipping. The field installation of panels also requires the Downdraft Diverter, and Exhaust Diverter to be installed in the field as well.
  • Page 10 EXHAUST DIVERTER INSTALLATION The Exhaust Diverter prevents exhaust gasses from entering the room. 1. Locate screws attached to front side top of interior firebox and remove. (Figure 3). 2. Position Exhaust Diverter into fireplace and attach Diverter using screws removed earlier.

  • Page 11: Log Placement

    LOG PLACEMENT FOR MODEL# SF3624TBF LOG SET NOTE: FOR SF3624 STACK LOG PLACEMENT, SEE SHEET IN LOG CTN. Placement Instructions • Place the back bottom log (log #1) as shown in the Illustration above. It should be positioned on the back of the grate.

  • Page 12: Operating Guidelines (Millivolt Models)

    OPTIONAL GLASS DOOR INSTALLATION 1. INSTALL GB DOOR TRACKS AND HINGE SPRINGS AS ILLUSTRATED IN FIGURE 1 USING 6 SCREWS IN KIT. 2. SCREW HANDLES ON TO DOORS. DOOR TRACK 3. INSTALL DOORS AS SHOWN IN FIGURE 2. (TOP) NOTE! HINGE SPRING BRIDGE ❒...
  • Page 13 OPERATING GUIDELINES (CONT’D) Figure 11 When lit for the first time, the appliance will emit a slight odor for an hour or two. This is due to paint and lubricants used in the manufacturing process. The main burner flame characteristics are steady, not lifting or floating.

  • Page 14: Lighting Instructions (Millivolt Models)

    FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. C. Use only your hand to push in or turn the gas A.
  • Page 15 TO TURN OFF GAS TO APPLIANCE TO TURN OFF GAS TO APPLIANCE 1. Open valve access door panel 2. Turn knob clockwise to pilot position then depress and continue turning to “OFF” 3. Close access door panel LPG (PROPANE) WARNING THE FOLLOWING WARNING APPLIES TO INSTALLATIONS USING L.P.

  • Page 16: Trouble Shooting (Millivolt Models)

    TROUBLE SHOOTING (MILLIVOLT MODEL) With proper installation and maintenance, your new Gas Fireplace should provide years of trouble-free service. If you do experience a problem, refer to the trouble shooting guide shown below. This guide will assist a qualified service person in the diagnosis of problems and the corrective action to be taken.

  • Page 17: Lighting Instructions (Spark To Pilot Models)

    TROUBLE SHOOTING (CONT’D) SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION 2. Pilot will not stay lit A. Defective pilot 1. Check pilot, flame must after carefully following generator impinge on pilot generator. lighting instructions. Clean and or adjust pilot for maximum flame impingement on generator.
  • Page 18 TROUBLE SHOOTING (CONT’D) SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION 3. Pilot burning, no A. Damper control lever in 1. Set damper control lever gas burner, valve knob closed position to open position. “ON”, “ON/OFF” switch “ON”. B. “ON/OFF” switch or 1. Check ON/OFF switch wires defective and wires for proper connections.
  • Page 19 TO TURN OFF GAS TO APPLIANCE OPERATING GUIDELINES (STP-SPARK TO PILOT MODEL) Upon completing the gas line connection, a small amount of air will be in the lines. When first lighting the pilot light, it will take a few minutes for the lines to purge themselves of this air.
  • Page 20 WIRING DIAGRAM (STP-SPARK TO PILOT MODEL) remote/wall Switch connection FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. This appliance is equipped with an ignition device which automatically lights the pilot.
  • Page 21 LIGHTING INSTRUCTIONS ELEC. SPARK TO PILOT 1. “STOP” Read the safety information on 5. Wait (5) minutes to clear out any gas. Then page 11. smell for gas, including near rgw floor. If you smell gas, STOP! Follow “B” in the safety 2.
  • Page 22 LPG (PROPANE) WARNING (CONT’D) IMPORTANT: Always keep the appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Never obstruct the flow of combustion and ventilation air. Keep the front of the appliance clear of all obstacles and materials. To obtain proper operation, it is imperative that the pilot and main burner flame characteristics are steady, not lifting or floating.
  • Page 23 TROUBLE SHOOTING (CONT’D) SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Pilot will not stay lit 1. Loose wiring on ignitor 1. Check wiring connection. wire to ignition module Refer to wiring diagram (see and/or poor ground to Wiring Diagram, page 20) ignition module 2.

  • Page 24: Replacement Parts

    REPLACEMENT PARTS ITEM PArT # DESCRIPTION ITEM PArT # DESCRIPTION TV-101 Gas Valve - N/G TV-117 Middle Left Log TV-102 Gas Valve - LP TV-118 Middle Right Log TV-103 “1/4" Pilot Line” TV-119 Top Left Log TV-104 “3/8" Burner Line” TV-120 Top Right Log TV-105...
  • Page 25 OPERATING INSTRUCTIONS, GOLDEN BLOUNT WILL TAKE THE FOLLOWING ACTIONS: 1. WITHIN THE FIRST YEAR FROM THE DATE OF INSTALLATION, GOLDEN BLOUNT SHALL, AT ITS OPTION REPLACE OR REPAIR ANY SUCH DEFECT IN MATERIAL OR WORKMANSHIP, AT GOLDEN BLOUNT’S EXPENSE, INCLUDING A REASONABLE LABOR ALLOWANCE AS DETERMINED BY GOLDEN BLOUNT.
