INSTALLATION AND OPERATING INSTRUCTIONS
MODELS SF3624-TV / SF4224-TV TOP-VENT FIREPLACE
IMPORTANT! Read all instructions carefully before starting
installation. Failure to follow these instructions may result in
property damage, personal injury or possible loss of life.
WARNING: If the information in these
instructions is not followed exactly, a
fire or explosion may result causing
property damage, personal injury or
death.
f i r e - p a r t s . c o m
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL
GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your
building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas
supplier, call the fire department.
– Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
MANUFACTURED BY:
4301 WESTGROVE DRIVE
ADDISON TX. 75001
GOLDEN BLOUNT
SUPER-FIRE
PFS APPROVED FOR NATURAL GAS OR PROPANE GAS
■ The Flue Damper must be in the
full open position when burning the
gas logs.
■ This fireplace is to be burned only
with the gas log set supplied with the
fireplace. Burning other items could
cause a fire hazard or injury.
■ For best results, Natural Gas pressure
should be 7" to 12" W.C. and 11" W.C.
for Propane Gas.
■ To simulate real wood burning, the gas
burner is designed to burn a yellow
flame. It is normal for the logs to soot
up. The soot can be easily removed
with a vacuum cleaner or soft brush.
■ Check the label on the firebox to
assure the proper gas type. Never
use anything but the correct gas type
for your fireplace.
This appliance complies with National
Safety and is tested and listed to ANSI
Z21.50 - 2014 as Vented Gas fireplaces.
Installation must conform to local codes.
In the absence of local codes, installation
must conform with the current National
Fuel Gas Code, ANSI Z223.1.
6/16 REV
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Golden Blount SF3624-TV
Summary of Contents for Golden Blount SF3624-TV
- Page 1 MANUAL WITH THE INSTALLED APPLIANCE INSTALLATION AND OPERATING INSTRUCTIONS GOLDEN BLOUNT SUPER-FIRE MODELS SF3624-TV / SF4224-TV TOP-VENT FIREPLACE PFS APPROVED FOR NATURAL GAS OR PROPANE GAS IMPORTANT! Read all instructions carefully before starting installation. Failure to follow these instructions may result in property damage, personal injury or possible loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION Layout Options ......................2 Identification of Parts ..................... 3 Building Codes and Safety Standards ................4 Piping and Gas Pressure Requirements ................ 5 Installation Instructions ....................6 Brick Panels, Exhaust and Downdraft Diverter Instructions (Refractory Models) ..9 Log Placement .......................11 Operating Guidelines (Millivolt Models) ................ -
Page 3: Identification Of Parts
SUPERFIRE TV TOP-VENT FIREPLACE Damper Control Lever Stand Offs Valve Access Panel (Side Steel Model) Valve Access Panel (Refractory/ STP Models) Outside Air Port f i r e - p a r t s . c o m INTERIOR VIEW Damper Control Lever Pan Burner... -
Page 4: Building Codes And Safety Standards
BUILDING CODES AND SAFETY STANDARDS The design of this FIREPLACE ACCESSORY has been tested and is listed with PFS CORPORATION in accordance with THE AMERICAN NATIONAL STANDARDS INSTITUTE - ANSI Z21.50, PFS File Number F15-047. This manual serves only as a basic guideline for installation and use of this firebox and gas piping. -
Page 5: Piping And Gas Pressure Requirements
GAS PIPING AND GAS PRESSURE REQUIREMENTS All gas piping must be installed to comply with local codes, or, in the absence of local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1. Unions in gas lines shall be of ground joint type. Compounds used on threaded joints of gas piping must be resistant to the action of liquefied petroleum gas. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS In planning the installation for the fireplace it is necessary to determine where the unit is to be installed, the routing of the B-type vent system, and whether optional accessories are to be used gas supply piping should also be planned. Models SF3624/4224-TV (with the use of the Outside Air Kit) can be installed in a bedroom (in the United States) which has a total volume of unconfined space appropriate to the particular installation. - Page 7 10' Rule of Thumb indicates a shorter chimney height. Note: Installations which will not allow the 10' rule to be followed must be submitted to Golden Blount Inc. for approval. 1-800-833-1139.
- Page 8 NFPA 54/ANSI Z223.1 Nation Fuel Gas Code. Please check with the local authority having jurisdiction in your area. The engineers at ENERVEX are familiar with Golden Blount fireplaces and their systems will allow you to minimize the amount of vent pipe exposed outside of your home.
-
Page 9: Brick Panels, Exhaust And Downdraft Diverter Instructions (Refractory Models)
Some Golden Blount Top Vent Fireplace models are supplied with high quality realistic Refractory Brick Panels. These panels are massive and must be field-installed to prevent damage to panels or fireplace during shipping. The field installation of panels also requires the Downdraft Diverter, and Exhaust Diverter to be installed in the field as well. - Page 10 EXHAUST DIVERTER INSTALLATION The Exhaust Diverter prevents exhaust gasses from entering the room. 1. Locate screws attached to front side top of interior firebox and remove. (Figure 3). 2. Position Exhaust Diverter into fireplace and attach Diverter using screws removed earlier.
-
Page 11: Log Placement
LOG PLACEMENT FOR MODEL# SF3624/4224TBF LOG SET NOTE: STACK/HICKORY LOG PLACEMENT, SEE SHEET IN LOG CTN. f i r e - p a r t s . c o m Placement Instructions • Place the back bottom log (log #1) as shown in the Illustration above. -
Page 12: Operating Guidelines (Millivolt Models)
OPERATING GUIDELINES (MILLIVOLT MODEL) WARNING: CHILDREN AND ADULTS Upon completing the gas line connection,a small amount of air will be in the lines. When first SHOULD BE ALERTED TO THE HAZARDS lighting the pilot light, it will take a few minutes OF HIGH SURFACE TEMPERATURE AND SHOULD STAY AWAY TO AVOID BURNS OR for the lines to purge themselves of this air. -
Page 13: Lighting Instructions (Millivolt Models)
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. C. Use only your hand to push in or turn the gas A. - Page 14 TO TURN OFF GAS TO APPLIANCE TO TURN OFF GAS TO APPLIANCE 1. Open valve access door panel 2. Turn knob clockwise to pilot position then depress and continue turning to “OFF” 3. Close access door panel LPG (PROPANE) WARNING THE FOLLOWING WARNING APPLIES TO INSTALLATIONS USING LP (PROPANE GAS): WARNING: To avoid possible injury, fire and explosion, please read and follow these precautions and all instructions of this appliance before lighting the pilot.
-
Page 15: Trouble Shooting (Millivolt Models)
TROUBLESHOOTING ( MILLIVOLT MODEL) With proper installation and maintenance, your new Gas Fireplace should provide years of trouble-free service. If you do experience a problem, refer to the trouble shooting guide shown below. This guide will assist a qualified service person in the diagnosis of problems and the corrective action to be taken. - Page 16 TROUBLESHOOTING (CONT’D) SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION 2. Pilot will not stay lit A. Defective pilot 1. Check pilot, flame must after carefully following generator impinge on pilot generator. lighting instructions. Clean and or adjust pilot for maximum flame impingement on generator.
- Page 17 TROUBLESHOOTING (CONT’D) SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION 3. Pilot burning, no gas to A. Damper control lever is in 1. Set damper control lever burner, valve knob closed position to open position. “ON”, “ON/OFF” switch “ON”. B. “ON/OFF” switch or 1.
-
Page 18: Operating Guidelines (Spark To Pilot Models)
TO TURN OFF GAS TO APPLIANCE OPERATING GUIDELINES (STP-SPARK TO PILOT MODEL) Upon completing the gas line connection, a small amount of air will be in the lines. When first lighting the pilot light, it will take a few minutes for the lines to purge themselves of this air. - Page 19 WIRING DIAGRAM (STP-SPARK TO PILOT MODEL) f i r e - p a r t s . c o m REMOTE/WALL SWITCH CONNECTION FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
-
Page 20: Lighting Instructions (Spark To Pilot Models)
LIGHTING INSTRUCTIONS ELEC. SPARK TO PILOT 1. “STOP” Read the safety information on 5. Wait (5) minutes to clear out any gas. Then page 20. smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the safety 2. -
Page 21: Trouble Shooting (Spark To Pilot Models)
LPG (PROPANE) WARNING (CONT’D) IMPORTANT: Always keep the appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Never obstruct the flow of combustion and ventilation air. Keep the front of the appliance clear of all obstacles and materials. To obtain proper operation, it is imperative that the pilot and main burner flame characteristics are steady, not lifting or floating. - Page 22 TROUBLESHOOTING (CONT’D) SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Pilot will not stay lit 1. Loose wiring on ignitor 1. Check wiring connection. wire to ignition module Refer to wiring diagram (see and/or poor ground to Wiring Diagram, page 20). ignition module 2.
-
Page 23: Replacement Parts
SF3624-TV REPLACEMENT PARTS ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION TV-101 Gas Valve - N/G TV-117 Middle Left Log TV-102 Gas Valve - LP TV-118 Middle Right Log TV-103 “1/4" Pilot Line” TV-119 Top Left Log TV-104 “3/8" Burner Line”... - Page 24 SF4224-TV REPLACEMENT PARTS ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION TV-101 Gas Valve - N/G TV-117-42 Middle Left Log TV-102 Gas Valve - LP TV-118-42 Middle Right Log TV-103 “1/4" Pilot Line” TV-119-42 Top Left Log TV-104 “3/8" Burner Line” TV-120-42 Top Right Log TV-105 Piezo Ignitor...
- Page 25 AND OPERATING INSTRUCTIONS, GOLDEN BLOUNT WILL TAKE THE FOLLOWING ACTIONS: 1. WITHIN THE FIRST YEAR FROM THE DATE OF INSTALLATION, GOLDEN BLOUNT SHALL, AT ITS OPTION REPLACE OR REPAIR ANY SUCH DEFECT IN MATERIAL OR WORKMANSHIP, AT GOLDEN BLOUNT’S EXPENSE, INCLUDING A REASONABLE LABOR ALLOWANCE AS DETERMINED BY GOLDEN BLOUNT.
