INSTALLER/CONSUMER RETAIN THIS APPLIANCE
INSTALLATION AND OPERATING INSTRUCTIONS
GOLDEN BLOUNT TOP-VENT FIREPLACES
PFS
*
IF MODEL HD4240-TV IS USED WITH PROPANE GAS A POWER VENT FAN
MUST BE USED. CONTACT GOLDEN BLOUNT FOR INFO. 1-800-833-1139
IMPORTANT! Read all instructions carefully before starting
installation. Failure to follow these instructions may result in
property damage, personal injury or possible loss of life.
WARNING: If the information in these
instructions is not followed exactly, a
fire or explosion may result causing
property damage, personal injury or
death.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your
building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas
supplier, call the fire department.
– Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
MANUFACTURED BY:
4301 WESTGROVE DRIVE
ADDISON, TX 75001
MANUAL WITH THE INSTALLED APPLIANCE
MODEL HD5030-TV "EL GRANDE"
*
HD4240-TV "SKYSCRAPER"
APPROVED FOR NATURAL GAS OR PROPANE GAS
*
■ The Flue Damper must be in the full
open position when burning the gas
logs.
■ This fireplace is to be burned only
with the gas log set supplied with the
fireplace. Burning other items could
cause a fire hazard or injury.
■ For best results, Natural Gas pressure
should be 7" to 12" W.C. and 11" W.C.
for Propane Gas.
■ To simulate real wood burning, the gas
burner is designed to burn a yellow
flame. It is normal for the logs to soot-
up. The soot can be easily removed
with a vacuum cleaner or soft brush.
■ Check the label on the firebox to as-
sure the proper gas type. Never use
anything but the correct gas type for
your fireplace.
This appliance complies with National
Safety and is tested and listed to ANSI
Z 21.50b - 2007 as Vented Gas fireplaces.
Z 21.50 - 2014
Z 21.50 -2014
Installation must conform to local codes.
In the absence of local codes, installation
must conform with the current National
Fuel Gas Code, ANSI Z223.1.
04/20
