NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Resistance Chart
Warranty
Ordering Parts
Model
MP-4500
Retain This
Manual for
Reference
10-25-06
OWNER'S
MANUAL
MARCY
CORNER GYM
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
®
PLATINUM
MP-4500
®
IMPEX
INC.
Advertisement
Table of Contents
Related Manuals for Impex Marcy Platinum MP-4500
Summary of Contents for Impex Marcy Platinum MP-4500
- Page 1 Resistance Chart Warranty Ordering Parts Model MP-4500 Retain This Manual for Reference 10-25-06 OWNER'S MANUAL ® MARCY CORNER GYM MP-4500 IMPEX 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com PLATINUM ® INC.
-
Page 2: Table Of Contents
BEFORE YOU BEGIN Thank you for selecting the MARCY PLATINUM MP-4500 CORNER GYM by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory. -
Page 3: Important Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS. IMPORTANT SAFETY NOTICE FITNESS EQUIPMENT. IMPEX INC. ASSUMES... - Page 4 WARNING LABEL REPLACEMENT The warning labels shown here have been placed on the Left Base Frame and Left Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in location shown.
-
Page 5: Hardware Pack
HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size. - Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size.
- Page 7 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size.
-
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended two or people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Place the Right Base Frame (#31) on a flat surface. Make sure there is enough space around to assemble the machine. - Page 9 DIAGRAM 1...
- Page 10 STEP 2 (See Diagram 2) A.) Attach the Right Upper Frame (#1) onto the Right Vertical Frame (#4). Secure it with two M10 x 2 ¾” Carriage Bolts (#98), one 4 ¾” x 2 ¾” Bracket (#25), two Ø ¾” Washers (#100), and two M10 Aircraft Nuts (#102).
- Page 11 STEP 3 (See Diagram 3) A.) Attach the Front Press Base (#2) to the Right Upper Frame (#1). Secure it with one 6 ¾” Front Press Base Axle (#29), two Ø 1 ¼” x Ø 3/8” Washers (#70), and two M10 Aircraft Nuts (#102).
- Page 12 DIAGRAM 3...
- Page 13 STEP 4 (See Diagram 4) A.) Attach the Seat Pad (#42) to the Seat Post (#6). Secure it with two M8 x 1 5/8” Allen Bolts (#85) and Ø 5/8” Washers (#101). B.) Insert the Seat Post into the opening on the Right Seat Support (#7). Secure it with a Lock Knob (#73) to lock the Seat Post at desired height.
- Page 14 STEP 5 (See Diagram 5) A.) Attach the Right Butterfly (#10) onto the axle on the Butterfly Base (#13). B.) Insert the Butterfly Handle (#9) into the pivot on the Right Butterfly. Secure it with one M10 x ¾” Allen Bolt (#95) and Ø 1 ¼” x Ø 3/8” Washer (#70) from the bottom. Do not over tighten the Bolt;...
- Page 15 STEP 6 (See Diagram 6) A.) Do not tighten all Nuts and Bolts in this Step until instructed to do so. B.) Attach the Left Vertical Frame (#33) onto the Left Base Frame (#32). Secure it with two M10 x 2 ¾” Carriage Bolts (#98), one 4 ¾” x 2 ¾” Bracket (#25), two Ø ¾” Washers (#100), and two M10 Aircraft Nuts (#102).
- Page 16 STEP 7 (See Diagram 7) A.) Attach the Left Upper Frame (#34) onto the Left Vertical Frame (33). Secure it with two M10 x 2 ¾” Carriage Bolts (#98), one 4 ¾” x 2 ¾” Bracket (#25), two Ø ¾” Washers (#100), and two M10 Aircraft Nuts (#102).
- Page 17 STEP 8 (See Diagram 8) A.) Attach the Left Seat Support (#35) onto the Left Base Frame (#32). Secure it with one M10 x 3 ½” Carriage Bolt (#99), Ø ¾” Washer (#100), and M10 Aircraft Nut (#102). B.) Attach the Left Seat Support to the Left Vertical Frame (#33). Secure it with two M10 x 2 ¾” Carriage Bolts (#98), one 4 ¾”...
- Page 18 STEP 9 (See Diagram 9) A.) Attach the Leg Press Frame (#36) to the bracket on the Left Base Frame (#32). Secure it with an Axle (#15), two M10 x ¾” Allen Bolts (#95), and two Ø ¾” Washers (#100). B.) Insert the Leg Press Adjustment Frame (#40) into the Leg Press Frame.
- Page 19 STEP 10 (See Diagram 10 & Front Press Cable Loop Diagram) A.) Attach one end of the 140” Front Press Cable (#48) to the bracket underneath the Right Upper Frame (#1). Secure it with one M10 x 1” Allen Bolt (#94), two Ø ¾” Washers (#100), and one M10 Aircraft Nut (#102).
- Page 20 DIAGRAM 10...
- Page 21 Front Press Cable Loop Diagram...
- Page 22 STEP 11 (See Diagram 11 & Lower Cable Loop Diagram) A.) Attach the 157” Lower Cable (#46) to the lower opening on the Leg Developer (#8). Attach a Pulley (#67) to the opening. Secure it with one M10 x 2 5/8” Allen Bolt (#92), two Ø...
- Page 23 DIAGRAM 11...
- Page 24 Lower Cable Loop Diagram...
- Page 25 STEP 12 (See Diagram 12 & Butterfly Cable Loop Diagram) A.) Clip one end of the 96” Butterfly Cable (#45) to the open slot on the Right Butterfly (#10). B.) Draw the Cable to the open bracket on the right side of the Right Vertical Frame (#4). Attach a Small Pulley (#68) to the bracket.
- Page 27 Butterfly Cable Loop Diagram...
- Page 28 STEP 13 (See Diagram 13 and Upper Cable Loop Diagram) A.) Attach the 130’” Upper Cable (#44) to the front opening on the Left Upper Frame (#34). Attach a Pulley (#67) to the opening. Secure it with one M10 x 3 ½” Allen Bolt (#90), two Ø...
- Page 29 DIAGRAM 13...
- Page 30 Upper Cable Loop Diagram...
- Page 31 STEP 14 (See Diagram 14) A.) Attach the end of the 103” Leg Press Cable (#47) to the bracket on the Leg Press Frame (#36). Secure it with a M10 x 1 ¾” Allen Bolt (#94), two Ø ¾” Washers (#100), and one M10 Aircraft Nut (#102).
- Page 32 DIAGRAM 14...
- Page 33 Leg Press Cable Loop Diagram...
- Page 34 STEP 15 (See Diagram 15) A.) Attach four Weight Stack Covers (#41) to the Right Upper Frame (#1) and Right Base Frame (#31). B.) Secure each Weight Stack Cover with two M10 x 5/8” Allen Bolts (#96) and Ø ¾” Washers (#100). DIAGRAM 15...
-
Page 35: Parts List
PARTS LIST KEY NO. DESCRIPTION Right Upper Frame Front Press Base Front Press Right Vertical Frame Backrest Support Fame Seat Post Right Seat Support Leg Developer Butterfly Handle Right Butterfly Left Butterfly Front Base Frame Butterfly Base Single Floating Pulley Bracket Axle Guide Rod Foot Plate... -
Page 36: Resistance Chart
MP-4500 WEIGHT RESISTANCE CHART Station Low Pulley Lat Pull Leg Developer Leg Press Front Press Butterfly Station Low Pulley Lat Pull 100 110 120 130 140 150 160 Butterfly 110 122 134 146 158 170 182 Leg Press 204 228 252 276 300 324 348 Front Press 118 132 146 160 174 188 202 Butterfly... -
Page 37: Warranty
IMPEX Customer Service Department at 1-800-999-8899. All freights on products returned to IMPEX must be prepaid by the customer. This warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse, misuse, improper or abnormal usage or repairs not provided by an IMPEX authorized service center or for products used for commercial or rental purposes.
