NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
MP-3500
Retain This
Manual for
Reference
11-14-07
OWNER'S
MANUAL
MARCY PLATINUM
MP-3500 HOME GYM
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
®
IMPEX
INC.

Advertisement

Table of Contents
loading

Related Manuals for Impex MARCY PLATINUM MP-3500

Summary of Contents for Impex MARCY PLATINUM MP-3500

  • Page 1 NOTE: Please read all instructions carefully before using this product MARCY PLATINUM Table of Contents Safety Notice MP-3500 HOME GYM Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model MP-3500 Retain This Manual for Reference 11-14-07 OWNER'S MANUAL ®...

  • Page 2: Table Of Contents

    WEIGHT RESISTANCE CHART............... PARTS LIST………………………………………………………………………….. WARRANTY....................… ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the MARCY PLATINUM MP-3500 HOME GYM by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.

  • Page 4: Warning Label Replacement

    WARNING LABEL REPLACEMENT The warning labels shown here have been placed on the Rear Stabilizer and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in location shown.

  • Page 5: Hardware Pack

    HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 7 HARDWARE PACK...

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches NOTE: It is strongly recommended this machine be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Place a Weight Stack Cover Base (#68) onto the Rear Stabilizer (#16). Secure it to the Rear Stabilizer with two M8 x 5/8”...
  • Page 9 DIAGRAM 1...
  • Page 10 STEP 2 (See Diagram 2) A.) Attach the Upper Frame (#1) onto the two Guide Rods (#17). Secure it with two M10 x ¾” Allen Bolts (#103) and ¾” Washers (#111). DO NOT tighten the Bolts yet. B.) Place the Upper Frame onto the Vertical Frame (#4). Secure it with two M10 x 2 5/8” Carriage Bolts (#106), one 4 ¾”...
  • Page 11 STEP 3 (See Diagram 3) A.) Attach the Front Press Base (#2) to the Upper Frame (#1). Secure it with one 6 ¾” Front Press Base Axle (#29), two Ø 1 ¼” Washers (#70), and two M10 Aircraft Nuts (#109). B.) Attach the Front Press (#3) to the Front Press Base.
  • Page 12 DIAGRAM 3...
  • Page 13 STEP 4 (See Diagram 4) A.) Attach the Seat Pad (#88) to the Seat Post (#6). Secure it with two M8 x 1 5/8” Allen Bolts (#113) and Ø 5/8” Washers (#112). B.) Insert the Seat Post into the opening on the Seat Support Frame (#7). Thread the 3 3/8”...
  • Page 14 DIAGRAM 4...
  • Page 15 STEP 5 (See Diagram 5) A.) Slide the Right Butterfly (#10) onto the right axle on the Butterfly Base (#13). B.) Insert the Butterfly Handle (#9) into the pivot on the Right Butterfly. Secure it with one M10 x ¾” Allen Bolt (#103) and 1 ¼”...
  • Page 16 STEP 6 (See Diagram 6 & Upper Cable Loop Diagram) A.) Attach the 167” Upper Cable (#42) to the opening on the front of Upper Frame (#1). Make sure the ball stopper is underneath the Frame. Attach a Pulley (#44) to the Cable. B.) Secure the Pulley to the opening with one M10 x 3 3/8”...
  • Page 17 DIAGRAM 6...
  • Page 18 Upper Cable Loop Diagram...
  • Page 19 STEP 7 (See Diagram 7 & Lower Cable Loop Diagram) A.) Attach the 217” Lower Cable (#40) to the opening on the Leg Developer (#8). Attach a Pulley (#44) to the opening. Secure it with one M10 x 2 ½” Allen Bolt (#98), two 7/8”...
  • Page 20 DIAGRAM 7...
  • Page 21 Lower Cable Loop Diagram...
  • Page 22 STEP 8 (See Diagram 8 & Butterfly Cable Loop Diagram) A.) Clip one end of the 83” Butterfly Cable (#41) to the open slot on the Right Butterfly (#10). B.) Draw the Cable to the open bracket on the right side of the Vertical Frame (#4). Attach a Small Pulley (#45) to the bracket C.) Secure it with one M10 x 1 ¾”...
  • Page 24 Butterfly Cable Loop Diagram...
  • Page 25 STEP 9 (See Diagram 9) A.) Connect the Lat Bar (#24) to the 167” Upper Cable (#42) with two Hooks (#90) and one Short Chain (#75). B.) Attach the Abdominal Strap (#85) to the U-shaped Cable Connector (#48) on the 217” Lower Cable (#40) with a Hook (#90).
  • Page 26 STEP 10 (See Diagram 10) A.) Attach one end of 75” Hip-Thigh Cable (#39) to the bracket on the Rotating Cam Plate (#32). Secure it with one M10 x 1” Allen Bolt (#102), two Ø ¾” Washers (#111), and one M10 Aircraft Nut (#109).
  • Page 27 Hip-Thigh Cable Loop Diagram...
  • Page 28 STEP 11 (See Diagram 11) A.) Snap the bottom of the two Weight Stack Covers (#46) onto the Weight Stack Cover Base (#68) previously installed in Step-1. B.) Cover the top of the two Covers by another Weight Stack Cover Base. Make sure the top and bottom of the two Covers are inside the Covers.

  • Page 29: Weight Resistance Chart

    WEIGHT RESISTANCE CHART WEIGHT PLATE Station Low Pulley Lat Pull Butterfly Front Press AB Crunch Leg Developer Hip/Thigh WEIGHT PLATE Station Low Pulley Lat Pull Butterfly Front Press AB Crunch Leg Developer Hip/Thigh *Numbers are approximate. Actual weight may vary. *Numbers are approximate.

  • Page 30: Parts List

    PARTS LIST KEY NO. DESCRIPTION Q’ty Upper Frame 5 3/8” Grip Front Press Base Ø 1” End Cap Front Press 2” x 2” End Cap Vertical Frame 1” x 2” End Cap Backrest Support Frame 1” x 2 ¾” End Cap Seat Post 2”...

  • Page 31: Warranty

    ® IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser.
