NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
MCB-5693
Retain This
Manual for
Reference
07-23-08
OWNER'S
MANUAL
MARCY CLASSIC
WEIGHT BENCH
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
MCB-5693
®
IMPEX
INC.
Advertisement
Table of Contents
Related Manuals for Impex Marcy Classic MCB-5693
Summary of Contents for Impex Marcy Classic MCB-5693
- Page 1 Parts List Warranty Ordering Parts Model MCB-5693 Retain This Manual for Reference 07-23-08 OWNER'S MANUAL MARCY CLASSIC WEIGHT BENCH MCB-5693 IMPEX 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com ® INC.
-
Page 2: Table Of Contents
BEFORE YOU BEGIN Thank you for selecting the MARCY CLASSIC WEIGHT BENCH MCB- 5693 by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. If you have any questions, or find there are missing or damaged parts, we guarantee you complete satisfaction through direct assistance from our factory. -
Page 3: Important Safety Notice
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. - Page 4 WARNING LABEL REPLACEMENT The Warning Label shown here has been placed on the Cross Brace. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown...
-
Page 5: Hardware Pack
HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size. - Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Plug four 2 ¾” x 2” End Cap (#21) onto the Left and Right Upright Beams (#1) & (#2). B.) Connect the Left and Right Upright Beams with a Cross Brace (#3) in the mid-span. - Page 8 STEP 2 (See Diagram 2) A.) Attach the Main Seat Support (#4) to the Leg Developer Holder (#5). Secure it with two M10 x 2 ½” Carriage Bolts (#41), two Ø ¾” Washers (#39), and two M10 Aircraft Nuts (#50). Do not tighten the Nuts and Bolts yet. B.) Attach the Main Seat Support to the Cross Brace (#3).
- Page 9 STEP 3 (See Diagram 3) A.) Attach the side-holes on the end of the Backrest Supports (#11) to the pivot on the Main Seat Support (#4). Secure them together with one M12 x 7 ¼” Hex Bolt (#43), two Washers (#40) and one M12 Aircraft Nut (#51). B.) Attach the Backrest Board (#13) to the Backrest Supports.
- Page 10 STEP 4 (See Diagram 4) A.) Attach the Leg Developer (#9) to the Leg Developer Holder (#5). Secure it with one Axle (#54), two M10 x 5/8” Allen Bolts (#45), and two B.) Insert two Foam Tubes (#12) halfway through the holes on the Leg Developer. Push four Foam Rolls (#19) onto the Tubes from both ends.
-
Page 12: Parts List
PARTS LIST KEY NO. DESCRIPTION Left Upright Beam Right Upright Beam Cross Brace Main Seat Support Leg Developer Holder Seat Bracket Crutch Backrest Adjustment Bar Leg Developer Arm Curl Stand Backrest Support Foam Tube Backrest Board Seat Pad Arm Curl Pad 4 3/8”... -
Page 13: Warranty
IMPEX Customer Service Department at 1-800-999-8899. All freights on products returned to IMPEX must be prepaid by the customer. This warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse, misuse, improper or abnormal usage or repairs not provided by an IMPEX authorized service center or for products used for commercial or rental purposes.
