Dynamix DW 2 FXO User Manual

Fxo sip gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D
y
n
a
m
D
y
n
a
m
D
y
n
a
m
D
y
n
a
m
i
x
D
W
i
x
D
i
x
D
W
i
x
D
F
X
O
S
I
P
F
X
O
S
I
P
User Manual
2
F
W
2
F
4
F
W
4
F
G
a
t
e
w
a
G
a
t
e
w
a
X
O
X
O
X
O
X
O
y
y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW 2 FXO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dynamix DW 2 FXO

Summary of Contents for Dynamix DW 2 FXO

  • Page 1 User Manual...

  • Page 2: Table Of Contents

    Dynamix DW-2/4 FXO SIP Gateway User Manual STEPS IN CONFIGURATION..................3 1. START UP ........................4 1.1 I ......................4 NTRODUCTION 1.2 F ..................5 EATURES AND SPECIFICATION 1.3 A ................... 7 CCESSORIES AND EQUIPMENT 1.4 A ......................8 PPEARANCE 1.4.1 2 FXO Gateway ....................8 1.4.2 4 FXO Gateway ....................
  • Page 3 Dynamix DW-2/4 FXO SIP Gateway User Manual 3.14 ROM U ....................45 PGRADE 3.14.1 \Upgrade using the FTP................45 3.14.2 Upgrade using the TFT ................46 3.15 F ....................49 LASH LEAN 3.16 C ....................... 50 OMMIT 3.17 R ....................... 51 EBOOT 4.

  • Page 4: Steps In Configuration

    Dynamix DW-2/4 FXO SIP Gateway User Manual Steps in configuration To check out the peripheral equipments and STEP 1 understand the feature of this gateway. Please read Start Up this step very carefully before starting the configuring. Connecting the gateway and computer to start configuring by WEB GUI.

  • Page 5: Start Up

    1. Start Up 1.1 Introduction Dynamix DW-2 FXO gateway provides voice/fax service over IP network with H.323 v3 protocol. By connecting to your existing ADSL or cable modem service, which allows the use of a single, network for voice and fax services with consequent saving in network infrastructure and greatly reduced telephone charges.

  • Page 6: Features And Specification

    Dynamix DW-2/4 FXO SIP Gateway User Manual 1.2 Features and specification Features ITU-T H.323 v3 compliance Automatically Gatekeeper Discovery Peer-to-Peer mode (non-Gatekeeper) Support auto-attendant (2nddial Tone / Voice greeting) Dimensions : 221mm(W)*42mm(H)*217mm(L) Line hunting 2(2FXO gateway)/4(4FXO gateway)/6(6FXO gateway) RJ-11 FXO ports E.164 (Telephone Number Plan)
  • Page 7 Dynamix DW-2/4 FXO SIP Gateway User Manual Bad Frame Interpolation Gain Settings Provide Call Progress Tone: Dial tone, busy tone, call-holding tone and ring-back tone Management Features: Two easy ways for system configuration Console port: RS-232C port TELNET HTTP Brower (e.g. Internet Explorer)

  • Page 8: Accessories And Equipment

    Dynamix DW-2/4 FXO SIP Gateway User Manual 1.3 Accessories and equipment ♦ The voice gateway in 2, 4 or 6 FXO ports and with one RJ-45 connector. ♦ The AC adapter. ♦ The CD of user manual. ♦ The connection cable in RS-232 interface.

  • Page 9: Appearance

    Dynamix DW-2/4 FXO SIP Gateway User Manual 1.4 Appearance 1.4.1 2 FXO Gateway Front panel: The LED light provides system message of 2FXO gateway. Power : Light on means 2FXO gateway is power on. L1-L2 : Light on means the line is in use.

  • Page 10: Fxo Gateway

    Dynamix DW-2/4 FXO SIP Gateway User Manual 1.4.2 4 FXO Gateway Front panel: The LED light provides system message of FXO Gateway. Power : Light on means FXO gateway is power on. L1-L4 : Light on means the line is in use.

  • Page 11: Fxo Gateway

    Dynamix DW-2/4 FXO SIP Gateway User Manual 1.4.3 6 FXO Gateway Front panel: The LED light provides system message of 6FXO gateway. Power : Light on means 6FXO gateway is power on. L1-L6 : Light on means the line is in use.
  • Page 12 Dynamix DW-2/4 FXO SIP Gateway User Manual PIN 1, 2: Transmit PIN 3, 6: Receive 2. COM: RS232 console port (DB-9pin male connector) Note: use straightforward cable to connect to your computer. Ш PINOUTS Name Dir Description «- Receive Data -►...

  • Page 13: How To Setup And Connect Basically

    Dynamix DW-2/4 FXO SIP Gateway User Manual 2. How to Setup and connect basically 2.1 System Requirement 1. One PC (a) Pentium 100 or above, 64 RAM, Windows 98 or above. (b) Ethernet card or COM port 2. One standard straightforward RS-232 cable (female connector to Gateway side).

  • Page 14: Ip Environment Setting

    Dynamix DW-2/4 FXO SIP Gateway User Manual 2.2 IP Environment Setting User must prepare a valid IP address, complied with IP Network, for Gateway’s proper operation. For testing the validation of chosen IP address, using the same IP configuration in other PC or Notebook, and then try to connect to Public Internet (go to well- known website, receive Internet mail, or ping a specific public IP address).
  • Page 15 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 2.1: Network Configuration Select the Property of the LAN card. Setup the ip address, subnet mask and default gateway as below: Figure 2.2: Configure the network 5Click OK after you finished the network setup.

  • Page 16: Network Configurations In Your Gateway

    Dynamix DW-2/4 FXO SIP Gateway User Manual 2.3 Network configurations in your gateway Key in the ip address of the gateway (http://10.1.1.3) with the browser. (see figure 2.3) Figure 2.3: WEB Browser After key in the ip address, you have to enter the user name and password to enter the WEB configuration.
  • Page 17 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 2.4: Login the username and password You will enter the main page of the configuration after key in the login name and password correctly: (see figure 2.5) Figure 2.5: The main WEB configuration...

  • Page 18: Static Ip Address

    Dynamix DW-2/4 FXO SIP Gateway User Manual Press the Network Interface to configure the networking of your gateway. (see figure 2.6) Figure 2.6: The Network Interface 2.3.1 Static ip address Please get the correct ip address, netmask and default gateway address from your ISP first.
  • Page 19 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 2.7: Configure the static ip address Press the commit if you finish the configuration. (see figure 2.8) Figure 2.8: Commit the data Press the reboot if you want the configuration executed. (see figure...

  • Page 20: Dhcp Mode

    Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 2.9: Reboot the system 2.3.2 DHCP mode Enable the DHCP if you are using the cable modem or DHCP server. (see figure 2.10) Figure 2.10: Enable the DHCP function...

  • Page 21: Pppoe Mode

    Dynamix DW-2/4 FXO SIP Gateway User Manual Please commit the data and reboot the machine after you enable the DHCP function. 2.3.3 PPPoE mode Switch to the PPPoE mode and press the “OK” button. Press the Network Interface button after the “OK” button. (see figure 2.11)

  • Page 22: Making A Voip Call

    Dynamix DW-2/4 FXO SIP Gateway User Manual Enter the Login account and password. Press the “OK” button if the configuration is finished. (see figure 2.12) Figure 2.12: Enter the Account and password Please commit the data and reboot the machine after you finished the configuration about the PPPoE function.
  • Page 23 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 2.13: Configure the Peer-to-Peer mode Enter the Phone Book configuration table and configure the name, ip address and phone number of the destination. (see figure 2.14) Figure 2.14: Phone Book...
  • Page 24 Dynamix DW-2/4 FXO SIP Gateway User Manual Example Figure 2.15: The example of Phone Book configuration The name of the destination: test The E164 number (phone number) of the destination: 123 The ip address of the destination: 10.1.1.100 (The port will be 1720 if you don’ t define it) Drop prefix: Enable –...
  • Page 25 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 2.16: To show the Phone Book record Phone Book is only for the Peer-to-Peer mode. Fifty index support. The application in the drop and insert function Input (E164) Drop Insert Output Disable...

  • Page 26: Configure The Gateway Into The Proxy Mode

    Dynamix DW-2/4 FXO SIP Gateway User Manual 2.4.2 Configure the gateway into the Proxy mode Enter the SIP configuration table and change the mode from Peer-to-Peer to Proxy mode. To change the Proxy information from your service provider (Ex. The Proxy IP, Outbound Proxy IP and Registered Number) Figure 2.17: Configure the Proxy info...

  • Page 27: Advanced

    Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 2.20: Configure the Security info Press the Commit Data and Reboot System buttons when you finished the configuration. 3. Advanced There are too many advanced commands for the advanced users. The following chapters are based on the application layer. Please get the info what you need.

  • Page 28: Network Configuration

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.1 Network Configuration The Network configuration will help users to configure the info about the network. Please get more detail info from the following. (see figure 3.1) Figure 3.1: Network Configuration ♦ IP Address - Define the ip address for your networking if it is the fixed ip.
  • Page 29 Dynamix DW-2/4 FXO SIP Gateway User Manual ♦ GMT - Configuring the time area for the time display in the Command Line Interface. The following is for the PPPoE configuration. (see figure 3.2) Figure 3.2: PPPoE Configuration ♦ PPPoE User Name - Put the PPPoE connection account in this table.

  • Page 30: Sip Configuration

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.2 SIP Configuration For the Proxy mode, users have to put the info about the Proxy in to this configuration table and configure the phone number. (see figure 3.3) Figure 3.3: SIP Configuration ♦...

  • Page 31: Security

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.3 Security Users could define the account and password for the port for the registration. (see figure 3.4) Figure 3.4: Security Configuration ♦ Account - The account name for this port. ♦ Password - The password for this account.

  • Page 32: Line

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.4 Line The Line configuration will show the status of the registrations and the ports. It includes the hunt group, hotline, and no answer forward configuration. Press the Line configuration button to enter configuration table (see figure 3.5) Figure 3.5: Line Configuration...

  • Page 33: System Configuration

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.5 System Configuration There are some parameters in the system configurations, please get more detail as following. (see figure 3.6) Figure 3.6: System Configuration ♦ Keypad type - There are two types for the Keypad. One is the In-Band type, another is the RFC2833 type.

  • Page 34: Voice Setting

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.6 Voice Setting User could define some parameters about the voice in this voice-setting page. (see figure 3.7) Figure 3.7: Voice Setting ♦ Codec Priority It’s for the codec setting. User could use the codec, which they want by the setting.

  • Page 35: Tone Setting

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.7 Tone Setting The Tone Setting is for the Tone detecting. The call will be dropped if the pattern of the tone from PSTN side is as same as the pattern in the disconnect tone table.

  • Page 36: Phone Book Configuration

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.8 Phone Book Configuration The Phone Book could only support the Peer-to-Peer mode. Users have to put the complete info in this table and follow up the E164 number from this table. Please get the detail info from the following. (see figure 3.9) Figure 3.9: Phone Book Configuration...

  • Page 37: Prefix

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.9 Prefix The Prefix function is using the drop and insert function (see figure 3.10). Figure 3.10: Prefix Configuration There is a rule between Prefix and Routing command, the Prefix command have the higher priority over the Routing command. If there is an incoming call from any sides, the Routing will check this calling number after the Prefix checked (see figure 3.)
  • Page 38 Dynamix DW-2/4 FXO SIP Gateway User Manual There is an example about the configuration, please follow up these steps. Press the Prefix Configuration button to enter the configuration table (see figure 3.6) Enter the index number. Put the prefix numbers you will dial in the prefix table, enable (disable) the drop function and enter the numbers you want to insert.
  • Page 39 Dynamix DW-2/4 FXO SIP Gateway User Manual Press the Prefix Configuration button to reload the configuration table (see figure 3.13) Figure 3.13: Show the added table Please Commit it and Reboot the system if the configuration is finished.

  • Page 40: Routing Table

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.10 Routing Table Routing Table is a rule to define the destination of the calls you make. You could define the rules by the number you dial or by the ports. The Routing Table button will show you the configuration table (see figure 3.14).

  • Page 41: Add A New Routing Table

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.10.1 Add a new Routing Table The default setting is changed after you press the Change Default button. Please press the Routing Table button again to show the new setting. (see figure 3.15) 3.15: E...
  • Page 42 Dynamix DW-2/4 FXO SIP Gateway User Manual ♦ Hunt - Define the hunt group function. None – Disable this function Group – The call will search other ports to be the destination with the same group the origin destination is busy.

  • Page 43: Fxo Password

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.11 FXO Password You will get the IVR if you make calls from PSTN side. The IVR will ask you the password you set, and you could make other calls to IP side if the password you type is correct.

  • Page 44: Ip Packet Tos

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.12 IP Packet ToS The Type of Service should be worked with the network router. The router will check all the packets if it support the TOS function. There is a field in the packet for the TOS value.

  • Page 45: Password

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.13 Password There are two accounts for login to access or change the configurations. One is “root”, another is “administrator”. Users could define the password for these two login account. The account “root” could make all the configurations back to the default setting, but the account “administrator”...

  • Page 46: Rom Upgrade

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.14 ROM Upgrade User could update the firmware just by the web configuration interface. There are two type for the upgrading procedure. One is using the TFTP server, another is using the FTP server. Please follow the step to update the gateway firmware version.

  • Page 47: Upgrade Using The Tft

    Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 3.21: FTP information Please pay more attentions about the blue blank. The Target File Type has to be matched with the Target File name. Please put the correct info about the Target file in this table.
  • Page 48 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 3.22: ROM Upgrade for TFTP Key in the IP address of your TFTP server, pick up the file type for your upgrade file and the correct file name for upgrading. (see figure 3.23) Figure 3.23 : TFTP information...
  • Page 49 Dynamix DW-2/4 FXO SIP Gateway User Manual Please press the “Flash Clean” button when the procedure is finished. After pressing the “Flash Clean” button, please press the “Reboot System” button to make it reboot.

  • Page 50: Flash Clean

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.15 Flash Clean Users could make all the configurations back to the default setting by this button. The password of the account and the networking configuration couldn’t be back to the default setting by this command. (see figure 3.24)

  • Page 51: Commit

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.16 Commit This web page could save the configurations if users change some configurations. This is necessary for users change the configurations. (see figure 3.25) Figure 3.25: Flash Clean...

  • Page 52: Reboot

    Dynamix DW-2/4 FXO SIP Gateway User Manual 3.17 Reboot This web page will restart the whole system. This is the necessary step for the changing the configurations and makes it executed. (see figure 3.26) Figure 3.26: Flash Clean...

  • Page 53: Command List

    Dynamix DW-2/4 FXO SIP Gateway User Manual 4. Command List 4.1 Hyper Terminal Setting A terminal emulator is needed when using RS-232 port to configure Gateway. There are kinds of terminal emulator software. Here, we use Microsoft HyperTerminal to depict how to set up terminal emulator: 1.
  • Page 54 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 4.2: Edit the name of the connection After pressing OK button, the next window appear, and then choose COM1/2 Port, which you are going to use. Figure 4.3: Pick up the right interface to use Configure the COM Port Properties as following: ♦...
  • Page 55 Dynamix DW-2/4 FXO SIP Gateway User Manual Figure 4.4: Configure the right Bps and control Press ‘OK’ button, and then start to configure Gateway.

  • Page 56: Command List

    Dynamix DW-2/4 FXO SIP Gateway User Manual 4.2 Command List 4.2.1 [help] Type help or man or ? to list all the available command. usr/config$ help help help/man/? [command] quit quit/exit/close debug show debug message reboot reboot local machine flash...

  • Page 57: Debug]

    Dynamix DW-2/4 FXO SIP Gateway User Manual Disconnecting... login: Note: It is recommended that type the “quit” command before you leave the console. If so, Gateway will ask password again when next user connects to console port. 4.2.3 [debug] Open debug message will show up specific information while Gateway is in operation.

  • Page 58: Flash]

    Dynamix DW-2/4 FXO SIP Gateway User Manual VoicePacketizermain comming WorkMode : PROXY_MODE incoming InitCallArray..REAL_MAXCALL=2 SIP stack was constructed successfully. Version - 2.2.1.8 Start registering to Proxy server AC4804[0] is ok successful 1 2 Initialize OSS libraries...OK! VP v1.44 stack open sucessfully.

  • Page 59: Ifaddr]

    Dynamix DW-2/4 FXO SIP Gateway User Manual 4.2.7 [ifaddr] Configure and display Gateway network information. usr/config$ ifaddr LAN information and configuration Usage: ifaddr [-print]|[-mode used]|[-sntp mode [server][-cmcenter ipaddress]] ifaddr [-ip ipaddress] [-mask subnetmask] [-gate defaultgateway] ifaddr [-id username][-pwd password][-http http port] -print Display LAN information and configuration.

  • Page 60: Time]

    Dynamix DW-2/4 FXO SIP Gateway User Manual -sntp Simple Network Time Protocol (1 = ON; 0 = OFF) When SNTP function is activated, users have to specify a SNTP server as network time source. An example is demonstrated below: -timezone set local time zone according to GMT ---------------------------------------------------------------------------------------------- usr/config$ ifaddr -sntp 1 10.1.1.1...

  • Page 61: Sysconf]

    Dynamix DW-2/4 FXO SIP Gateway User Manual 64 bytes from 192.168.1.254: icmp_seq=2. time=0. ms 64 bytes from 192.168.1.254: icmp_seq=3. time=0. ms ----192.168.1.254 PING Statistics---- 4 packets transmitted, 4 packets received, 0% packet loss round-trip (ms) min/avg/max = 0/1/5 usr/config$ 4.2.10 [sysconf] This command displays system information and configurations.

  • Page 62: Sip]

    Dynamix DW-2/4 FXO SIP Gateway User Manual will dial out all number pressed. (1-10 seconds) -keypad DTMF replay type. When value is “0”, Gateway will transfer DTMF signal via In-Band type, “1” via RFC2833 type. Users can adjust the value according to various applications. -ring ring time for ring detection(in ms).
  • Page 63 Dynamix DW-2/4 FXO SIP Gateway User Manual -rtp RTP port number (2326~65532). Default : 16384 Example: sip -px 210.59.163.171 -line1 70 -line2 71 -line3 72 -line4 73 usr/config$ Parameters Usage: -print print current h323 related settings -mode alternatives for proxy or peer-to-peer mode (1=proxy mode;...

  • Page 64: Security]

    Dynamix DW-2/4 FXO SIP Gateway User Manual 4.2.12 [security] This is the authentication for the SIP account. --------------------------------------------------------------------------------------------- usr/config$ line Secuirty information and configuration Usage: security [-name username] [-password password] security -print -print Display system account information and configuration. -line Specify which line number you want to set the account.
  • Page 65 Dynamix DW-2/4 FXO SIP Gateway User Manual hotline Hot line configuration. Example: line -config 1 hunt 1 hotline 1003 usr/config$ Parameter Usages: -print print out all current settings of line -config determine which line to configure -hunt set hunting group flag of each line. For example, if user assigns the Line1 as hunt group 1, and the Line2 as hunt group 2, they will be determined as 2 different groups.

  • Page 66: Route]

    Dynamix DW-2/4 FXO SIP Gateway User Manual ------------------------------------------------------------------------------ In this example means: if there is a incoming call from PSTN into the port 1, gateway will automatically dial out the number “1001”. 4.2.14 [route] This command is to set routing table for Gateway.

  • Page 67: Prefix]

    Dynamix DW-2/4 FXO SIP Gateway User Manual “maximum digits can’t be exceeded”) -delete delete a routing rule in routing table (route –delete “index of routing rule”) -modify modify a routing rule in routing table. (route –modify “index of routing rule” prefix “prefix number” dst “destination port type”...

  • Page 68: Pbook]

    Dynamix DW-2/4 FXO SIP Gateway User Manual Prefix drop/insert information and configuration Usage: prefix -add [prefix number][drop number][insert digits] prefix -delete index prefix -modify index [prefix number][drop number][insert number] prefix -print Prefix drop/insert information. prefix The prefix of dialed number.
  • Page 69 Dynamix DW-2/4 FXO SIP Gateway User Manual ---------------------------------------------------------------------------------------------- usr/config$ pbook Phone book information and configuration Usage: pbook [-add [name string][e164 number][ip address] [port number][drop digit][insert number]] [-modify number [name string][e164 number][ip address] [port number][drop digit][insert number]] [-delete number] pbook -print -print - Display phone book information and configuration.

  • Page 70: Voice]

    Dynamix DW-2/4 FXO SIP Gateway User Manual -add add a new record to phone book. When adding a record, users have to specify name, ip, and e164 number to complete the command. name name to represent callee. e164 The SIP number for mapping with IP address of called...
  • Page 71 Dynamix DW-2/4 FXO SIP Gateway User Manual voice -priority [G723] [G711A] [G711U] [G729] [G729A] [G729B] [G729AB] -print Display voice codec information and configuration. -send Specify sending packet size. G.723 (30/60 ms) G.711A (20/40/60 ms) G.711U (20/40/60 ms) G.729 (20/40/60 ms) G.729A (20/40/60 ms)
  • Page 72 Dynamix DW-2/4 FXO SIP Gateway User Manual -send define packet size for each codec. 20/40/60ms means to send a voice packet per 20/40/60 milliseconds. The smaller the packet size, the shorter the delay time. If network is in good condition, smaller sending packet size is recommended.

  • Page 73: Tone]

    Dynamix DW-2/4 FXO SIP Gateway User Manual Note: be sure to know well the application before you change voice parameters because this might cause incompatibility. 4.2.18 [tone] This command is basically for FXO ports. -------------------------------------------------------------------------------------------- usr/config$ tone Disconnect tone and remote ring back tone configuration...

  • Page 74: Fxopwd]

    Dynamix DW-2/4 FXO SIP Gateway User Manual For each tone may has 1 set or 2 sets (high and low) of frequencies. If user wants to set 0 in on/off time, please set “1023” represent “0”. (ex. tone 1 620 480 8 8 50 50 1023 1023) (tone “index of tone”...
  • Page 75 Dynamix DW-2/4 FXO SIP Gateway User Manual usr/config$ record Recoed greeting voice and ask pin code voice, tone analize. Usage: record -greeting filename - askpin filename -tone Example: record -greeting greeting.100 record -askpin askpin.100 record -tone usr/config$ Parameter Usages: -greeting record greeting file. User must assign a file name for greeting, once record is finished, file recorded will be display in rom -print.
  • Page 76 Dynamix DW-2/4 FXO SIP Gateway User Manual Please wait a moment... Write flash ok... Boot Rom : sdboot.200 Application Rom : 4sipfxo.103 DSP App : 48302ce3.300 DSP Kernel : 48302ck.300 DSP Test Code : 483cbit.bin Greetings : test.100 Ask Pin askpin.100 q...
  • Page 77 Dynamix DW-2/4 FXO SIP Gateway User Manual ......s ..........Press (P) to play the voice or (W) to write to flash or (Q) to quit... Please wait a moment... Write flash ok... Boot Rom : sdboot.200 Application Rom : 4sipfxo.100 DSP App : 48302ce3.300 DSP...
  • Page 78 Dynamix DW-2/4 FXO SIP Gateway User Manual Analyzing!! Please wait a moment…….. Frequency 1 : 480 Frequency 2 : 620 Frequency 3 (2623) is more than 1000, please ignore it. 0.25sec on 0.25sec off usr/config$ Note: 1. About the tone detection or tone recording for FXO unit, two extension or PSTN line is necessary.
  • Page 79 Dynamix DW-2/4 FXO SIP Gateway User Manual There are three values you will get after analyzing. Please leave the value which is over 1000 Hz, this is not the frequency of disconnect tone. 10. Please put the frequency in the tone table just follow the command...
  • Page 80 Dynamix DW-2/4 FXO SIP Gateway User Manual Tone1 off : 25 Tone2 on : 1023 Tone2 off : 1023 connect tone 2 paramter Frequency high : 450 frequency low frequency high level frequency low level Tone1 on : 35 Tone1 off...
  • Page 81 Dynamix DW-2/4 FXO SIP Gateway User Manual tone –print Disconnect tone 1 paramter Frequency high : 620 frequency low : 480 frequency high level frequency low level Tone1 on : 25 Tone1 off : 25 Tone2 on : 1023 Tone2 off...

  • Page 82: Tos]

    Dynamix DW-2/4 FXO SIP Gateway User Manual Tone1 on : 35 Tone1 off : 35 Tone2 on : 1023 Tone2 off : 1023 connect tone 3 paramter Frequency high : 620 frequency low : 480 frequency high level frequency low level...

  • Page 83: Pt]

    Dynamix DW-2/4 FXO SIP Gateway User Manual [-rtpreliab mode] tos -print Example: tos -rtptype 7 -sigtype 0 Parameter Usages: -rtptype the packages of voice -sigtype the package of call signal Note: The value of rtptype and sigtype is from 0 to 63.

  • Page 84: Rom]

    Dynamix DW-2/4 FXO SIP Gateway User Manual 4.2.23 [rom] ROM file information and firmware upgrade function. ---------------------------------------------------------------------------------------------- usr/config$ rom ROM files updating commands Usage: rom [-print][-app][-boot][-dsptest][-dspcore][-dspapp][-greet][-askpin] -s TFTP/FTP server ip -f filename rom -print -print show versions of rom files. (optional)

  • Page 85: Passwd]

    Dynamix DW-2/4 FXO SIP Gateway User Manual application code, greeting file, askpin file. to specify TFTP server’s IP address when upgrading ROM files. to specify the target file name, which will replace the old one. -method to decide using TFTP or FTP as file transfer server. “0” stands for TFTP, while “1”...
