IGS-03
Hardware Identifier
45 HYPER EXTENSION
Assembly Instruction
BENCH
Parts List
Warranty
Ordering Parts
Model
IGS-03
Retain This
Manual for
Reference
02-19-02
OWNER'S
MANUAL
IMPEX FITNESS PRODUCTS
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Impex Iron Grip Sport IGS-03
Summary of Contents for Impex Iron Grip Sport IGS-03
- Page 1 45 HYPER EXTENSION Assembly Instruction BENCH Parts List Warranty Ordering Parts Model IGS-03 Retain This Manual for Reference 02-19-02 OWNER'S MANUAL IMPEX FITNESS PRODUCTS 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...
-
Page 2: Table Of Contents
WARRANTY...… 9 ORDERING PARTS... 9 BEFORE YOU BEGIN Thank you for selecting the IRON GRIP SPORT IGS-03 45 Hyper Extension Bench by IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Adjustable Wrench and Allen Wrench NOTE: It is strongly recommended this machine to be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Main Frame (#1) to the Rear Stabilizer (#5). Secure it with two M10 x 3 ½”... - Page 6 A.) Attach two Brass Bushings (#8) to the Support Frame (#9). Secure it to the rear bracket on the Main Frame (#1) with one M10 x 3 ½” Allen Bolt (#33), two Washers (#3), and one M10 Aircraft Nut (#2). Do not over tighten the bolt. B.) Insert the Hyper Adjustment Frame (#12) into the Support Frame (#9).
- Page 7 STEP 3 (See Diagram 3) A.) Attach the two Upholstery Pads (#20) to the Handle Adjustment Frame (#16). Secure each pad with two M8 x 1 ½” Allen Bolts (#18) and B.) Attach the Foot Plate (#26) to the Akimbo Frame (#14). Securely tighten it with two M10 x 1 3/4”...
-
Page 9: Parts List
PARTS LIST KEY NO. DESCRIPTION Main Frame M10 Aircraft Nut ¾” Washer 2” x 2 ¾” End Cap Rear Stabilizer M10 x 3 ½” Carriage Bolt 2” Square End Cap Brass Bushing Support Frame Lock Knob Sleeve Backrest Adjustment Frame M10 x 3 3/8”... -
Page 10: Warranty
No other warranty beyond that specifically set forth above is authorized by IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
