- Page 1 Assembly Instruction Parts List Warranty Ordering Parts Model IGS-07 Retain This Manual for Reference 04-22-02 OWNER'S MANUAL IGS-07 MULTI LAT/MID/LOW Machine IMPEX FITNESS PRODUCTS 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...
-
Page 2: Table Of Contents
WARRANTY...… 13 ORDERING PARTS... 13 BEFORE YOU BEGIN Thank you for selecting the IRON GRIP SPORT IGS-07 Multi Lat/Mid/Low Machine by IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Adjustable Wrench and Allen Wrench NOTE: It is strongly recommended this machine to be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Rear Stabilizer (#33) and the Base Frame (#45) to the Main Stabilizer (#35). Secure them with two M12 x 4”... - Page 6 A.) Align the rear of Upper Frame (#8) to the Rear Vertical Beam (#19). Attach the Top Socket Assembly (#14) to the joint. Secure it with four M12 x 3 1/8” Carriage Bolts (#11), 1” Washers (#12), and M12 Aircraft Nuts (#13). Do not tighten the bolts yet. B.) Place the Upper Frame onto the open bracket on the Front Vertical Beam (#22).
- Page 7 STEP 3 (See Diagram 3) A.) Insert the two Guide Rods (#18) into the holes on the Main Stabilizer (#35). Slide two Rubber Washers (#26) onto the Guide Rods from the top. NOTE: WD-40 or similar lubricant might be needed to reduce friction. B.) Slide two Guide Rod Sleeves (#28) and two Rubber Bumpers (#27) onto the Guide Rods (#18).
- Page 8 DIAGRAM 3...
- Page 9 A.) Attach the 119” Upper Cable (#10) to the front opening on the Upper Frame (#8). Make sure the ball stopper on the Cable is under the opening. B.) Attach a Pulley (#9) to the opening. Secure it with one M10 x 2 ½” Allen Bolt (#7), two Bushings (#6), and one M10 Aircraft Nut (#5).
-
Page 10: Cable Loop Diagram
CABLE LOOP DIAGRAM... - Page 11 DIAGRAM 4...
-
Page 13: Parts List
PARTS LIST KEY NO. DESCRIPTION Lat Bar C-clip Chain 2” x 2 ¾” End Cap M10 Aircraft Nut Bushing M10 x 2 ½” Allen Bolt Upper Frame Pulley 119 “ Upper Cable M12 x 3 1/8” Carriage Bolt M12 Aircraft Nut Top socket Assembly Guide Rod Ring M8 x ½”... -
Page 14: Warranty
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
