Impex IGS-8860 Owner's Manual

Impex IGS-8860 Owner's Manual

Iron grip strength olympic bench
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
IGS-8860
Retain This
Manual for
Reference
07-10-06
OWNER'S
MANUAL
IRON GRIP STRENGTH
OLYMPIC BENCH
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
IGS-8860
®
IMPEX
INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IGS-8860 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Impex IGS-8860

Summary of Contents for Impex IGS-8860

  • Page 1 NOTE: Please read all instructions carefully before using this product IRON GRIP STRENGTH Table of Contents OLYMPIC BENCH Safety Notice Hardware Identifier IGS-8860 Assembly Instruction Parts List Warranty Ordering Parts Model IGS-8860 Retain This Manual for Reference ® IMPEX INC.

  • Page 2: Table Of Contents

    WARRANTY....................…………. 13 ORDERING PARTS..................………… 13 BEFORE YOU BEGIN Thank you for selecting the IRON GRIP STRENGTH IGS-8860 Olympic Bench by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notice

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.
  • Page 4 WARNING LABEL REPLACEMENT The Warning Label shown here has been placed on the Rear Stabilizer. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown...

  • Page 5: Hardware Pack

    HARDWARE PACK...
  • Page 6 HARDWARE PACK...

  • Page 7: Assembly Instruction

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Note: Do not tighten all nuts and bolts until instructed to do so. B.) Attach the Right Upright Beam (#1) to a Rear Stabilizer (#3).
  • Page 8 STEP 2 (See Diagram 2) A.) Slide the Sliding Block (#10) onto the Main Seat Support (#6). Thread a M18 x 3/8” Lock Knob (#39) into the selected hole to hold the Sliding Block in position. B.) Attach the Leg Developer Holder (#9) to the Front Stabilizer (#7). Secure it with three M10 x 5/8”...
  • Page 9 STEP 3 (See Diagram 3) A.) Attach the holes on the end of the Backrest Supports (#15) to the pivot on the Sliding Block (#10). Attach the two ends of Seat Support (#16) to the two holes on end of Backrest Supports.
  • Page 10 STEP 4 (See Diagram 4) A.) Attach the Leg Developer (#8) to the Leg Developer Holder (#9). Secure it with an Axle (#42), two M10 x 5/8” Allen Bolts (#56) and ¾” Washers (#62). B.) Insert two Foam Tubes (#28) halfway through the holes on the Leg Developer. Push four Foam Rolls (#31) onto the Tubes from both ends.
  • Page 11 STEP 5 (See Diagram 5) A.) Attach the Arm Curl Pad (#24) to the Arm Curl Bracket (#23). Secure it with two M8 x 5/8” Allen Bolts (#59) and Ø 5/8” Washers (#63). Attach the Arm Curl Bracket to the bracket on the Arm Curl Stand (#12).

  • Page 13: Parts List

    PARTS LIST KEY NO. DESCRIPTION Q’ty Right Upright Beam Ø 2 3/8” Bushing Left Upright Beam Arm Curl Handle Grip Rear Stabilizer M10 x 4 ¾” Carriage Bolt Rear Diagonal Support M10 x 2 ¾” Carriage Bolt Cross Brace M10 x 2 ½” Carriage Bolt Main Seat Support M10 x 5/8”...

  • Page 14: Limited Warranty

    ® IMPEX INC. LIMITED WARRANTY ®" IMPEX Inc. ("IMPEX ) warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing or repairing, at IMPEX's option.
