ASSEMBLY

To hire an authorized service technician to assemble the elliptical exerciser, call toll-free 1-800-445-2480.
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires a phillips screwdriver
mallet .
See the drawings below to identify the small parts needed for assembly. The number in parenthesis below
each drawing is the key number of the part, from the PART LIST on page 18. The number following the key
number is the quantity needed for assembly. Note: Some small parts may have been pre-assembled. If a
part is not found in the parts bag, check to see if it has been pre-assembled.
M8 Split
Washer (74)–7 Washer (17)–4
M10 Nylon M4 x 16mm
Screw (66)–4
Locknut (29)–2
M10 x 22mm Button
Screw (21)–4
Bolt Set (27)–2
M8 Large M10 Split
Washer (67)–8
M4 x 19mm
Screw (39)–2
M8 x 42mm Button
Bolt (50)–4
M10 x 105mm Carriage Bolt (34)–2
, two adjustable wrenches
Small Wave Wave Washer
Washer (90)–2
M5 x 15mm M8 x 19mm Button
Screw (89)–1 Screw (22)–4
M10 x 58mm Button Screw (19)–4
5
, and a rubber
M8 Nylon
(85)–2
Locknut (46)–4
M8 x 25mm Button
Screw (57)–3
M8 x 46mm Button
Screw (20)–4
