Image 8.0 User Manual
  1. Manuals
  2. Brands
  3. Image Manuals
  4. Home Gym
  5. 8.0 Elliptical
  6. User manual
Image 8.0 User Manual

Image 8.0 User Manual

Weight system
Hide thumbs Also See for 8.0:

Advertisement

Table of Contents

Model No. IMSY59300
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are
committed to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT
LINE. The technicians
on our customer hot line
will provide immediate
assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Image 8.0

Summary of Contents for Image 8.0

  • Page 1 Model No. IMSY59300 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through assistance from our factory.

  • Page 2: Table Of Contents

    Remove the PART IDENTIFICATION CHART and the PART LIST/EXPLODED DRAWING before beginning assembly. IMAGE is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight system. 1. Read all instructions in this manual and in the accompanying literature before using the weight system. Use the weight system only as described in this manual.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the versatile IMAGE weight system. The IMAGE ® 8.0 offers a selection of weight stations designed to develop every major mus- cle group of the body. Whether your goal is to tone your body, build dramatic muscle size and strength, or improve your cardiovascular system, the IMAGE will help you to achieve the specific results you want.

  • Page 5: Assembly

    ASSEMBLY Make Assembly Easier Everything in this manual is designed to ensure that the weight system can be assem- bled successfully by anyone. Before begin- ning assembly, make sure to read the information on this page. This brief intro- duction will save you much more time than it takes to read it! Assembly Requires Two Persons For your convenience and safety, assemble the...

  • Page 6: Frame Assembly

    FRAME ASSEMBLY Before you begin this step, make sure that you have read all of the information on page 5. This brief introduction will save you much more time than it takes to read it. Locate and open the parts bags labeled “FRAME ASSEMBLY.”...
  • Page 7 4. Attach the Butterfly Seat Frame (14) to the Butterfly Upright (1) with two 3/8” x 3 1/4” Bolts (62), two 3/8” Flat Washers (48), and two 3/8” Nylon Locknuts (50). Attach the Butterfly Seat Frame (14) to the Butterfly Front Leg (3) with two 3/8”...
  • Page 8 8. See the inset drawing. Insert two Weight Inserts (56) into each Weight (21). Set the two Weight Bumpers (51) over the holes in the corner bar of the Press Base (6). Slide the Weight Guides (15) through the Weight Bumpers (51) and the holes in the Press Base (6).

  • Page 9: Arm Assembly

    11. Secure the Press Top Frame (9) to the Butterfly Top Frame (33) with two 3/8” x 3 1/4” Bolts (62), two 3/8” Flat Washers (48), and two 3/8” Nylon Locknuts (50). Do not tighten the Nylon Locknuts yet. 12. Secure the Weight Guides (15) to the Press Top Frame (9) with two 3/8”...
  • Page 10 14. Insert a 2” Square Inner Cap (28) into the end of a Butterfly Arm (10). Attach a Butterfly Handle (53) to the Butterfly Arm (10) with two 3/8” x 1” Bolts (84) and two 3/8” Flat Washers (48). Repeat this step with the other Butterfly Arm (10). 15.

  • Page 11: Cable Assembly

    18. Attach a Bumper (40) to the Press Front Leg (20) with a 1” Tap Screw (80). Press a 2” x 3” Inner Cap (78) into the top of the Press Leg Lever (90). Lubricate a 1/2” x 4” Bolt (68). Attach the Press Leg Lever (90) to the Press Base (6) with the Bolt and a 1/2”...
  • Page 12 22. Remove the preassembled 3/8” x 2” Bolts (54) from one set of Adjustable Pulley Plates (23). Wrap the Butterfly Cable (73) around a 3 1/2” Pulley (24). Attach the Pulley and a Cable Trap (25) between the top holes of the Adjustable Pulley Plates (23) with a 3/8”...
  • Page 13 26. Wrap the Ab Cable (47) around a 3 1/2” Pulley (24). Insert the Ab Cable down through the Press Top Frame (9). Attach a 3/8” Flat Washer (48) and a 5/8” x 3/4” Bushing (66) to a 3/8” x 3 1/4” Bolt (62). Slide the Bolt through the Press Top Frame and the Pulley.
  • Page 14 30. Locate the Weight Cable (72). Note that one end of the Weight Cable has a bolt, and the other end has a ball on it. Lay the Weight Cable (72) inside the bracket on the Butterfly Base (4) in the manner shown. Attach a 3 1/2”...
  • Page 15 34. Wrap the Weight Cable (72) around a 3 1/2” Pulley (24). Attach the Pulley and a Cable Trap (25) to the Butterfly Upright (1) with a 3/8” x 4” Bolt (59), a 3/8” Flat Washer (48), and a 3/8” Nylon Jamnut (63). Be sure that the Cable Trap is turned to hold the Cable in place.
  • Page 16 38. Wrap the Weight Cable (72) around a 3 1/2” Pulley (24). Attach the Pulley and a Cable Trap (25) between the lowest holes in the Adjustable Pulley Plates (23) hanging from the Ab Cable (47) with a 3/8” x 2” Bolt (54) and a 3/8” Nylon Locknut (50). Be sure that the Cable Trap is turned to hold the Cable in place.
  • Page 17 42. Locate the Leg Press Cable (75). Attach the Leg Press Cable to the indicated side of the Press Upright (2) with a 3/8” x 3 1/4” Bolt (62) and a 3/8” Nylon Locknut (50). Do not tighten the Nylon Locknut yet.
  • Page 18 46. Remove the 3/8” Nylon Locknut (50) from the indi- cated 3/8” x 5 1/2” Bolt (55). Wrap the Leg Press Cable (75) around a 3 1/2” Pulley (24). Secure the Pulley and a Cable Trap (25) to the 3/8” x 5 1/2” Bolt (55) on the indicated side of the Press Base (6) with the 3/8”...

  • Page 19: Seat Assembly

    SEAT ASSEMBLY 50. Locate and open the parts bag labeled “SEAT ASSEMBLY.” Attach a Seat (13) to the brackets on the Butterfly Seat Frame (14) using four 1/4” x 3/4” Bolts (49). Repeat this step with the other Seat (not shown) and the Press Seat Frame (not shown).
  • Page 20 54. Lubricate a 1/2” x 4” Bolt (68). Attach the Foot Press Plate (29) to the Press Leg Lever (90) with the Bolt and a 1/2” Nylon Jamnut (36). 55. Press two 3/4” Round Inner Caps (43) into each of the two Pad Tubes (42).

  • Page 21: Adjustments

    ADJUSTMENTS The instructions below describe how each part of the weight system can be adjusted. Refer to the exercise guide accompanying this manual to see how the weight system should be set up for each exercise. IMPOR- TANT: When attaching the lat bar, ab strap, or nylon strap, make sure that the attachments are in the cor- rect starting position for the exercise to be performed.
  • Page 22 ATTACHING THE AB STRAP TO THE AB PULLEY STATION Attach the Ab Strap (81) to the Ab Cable (47) at the ab pulley station with a Cable Clip (69). ADJUSTING THE BACKREST To adjust a Backrest (12), loosen the Adjustment Knob (5) on the Press Upright (2) or the Butterfly Upright (not shown) by turning it counterclockwise and pulling it out as far as possible.

  • Page 23: Weight Resistance Chart

    WEIGHT RESISTANCE CHART This chart shows the approximate weight resistance at each weight station. “Top” refers to the 10 lb. top weight. The other numbers refer to the 10 lb. weight plates. The butterfly arm resistance listed is the resistance for each butterfly arm.

  • Page 24: Trouble-Shooting And Maintenance

    TROUBLE-SHOOTING AND MAINTENANCE Make sure that all parts have been properly tightened each time you use the weight system. Replace any worn parts immediately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used.

  • Page 25: Cable Diagrams

    CABLE DIAGRAMS The cable diagrams on this page and the next page show the proper routing of the Leg Press Cable (75), the Ab Cable (47), the Butterfly Cable (73), and the Weight Cable (72). Use the diagrams to be sure that the cables have been assembled correctly.
  • Page 26 Weight Cable (72) Cable ID 12—Weight Stack 1—Low Pulley...
  • Page 27 PART IDENTIFICATION CHART—Model No. IMSY59300 1/2" Flat Washer (11) 1/2" Plain Nut (100) 3/8" Nylon Locknut (50) 5/16" Nylon Locknut (64) 5/8” x 3/4” Bushing (66) 3/4" Round Inner Cap (43) 3/8" Flat Washer (48) 1/2" Nylon Jamnut (36) 3/8" Nylon Jamnut (63) 1/2"...
  • Page 28 3/8" x 2" Carriage Bolt (92) 3/8" x 2" Bolt (54) 3/8" x 1 3/4" Bolt (57) 3/8" x 1 1/4" Button Head Bolt (98) 3/8" x 1" Bolt (84) 1" Tap Screw (80) 1/4" x 3/4" Bolt (49) #8 x 1/2" Screw (45) 3/8"...
  • Page 29 1 1/2" Square Inner Cap (35) 2" x 3” Inner Cap (78) 1 1/2" x 2 1/2” Inner Cap (83) 2 1/2" Square Inner Cap (76) 2" Square Inner Cap (28)
  • Page 30 PART LIST—Model No. IMSY59300 No. Qty. Description Butterfly Upright Press Upright Butterfly Front Leg Butterfly Base Adjustment Knob Press Base Press Seat Frame Press Frame Press Top Frame Butterfly Arm 1/2” Flat Washer Backrest Seat Butterfly Seat Frame Weight Guide Top Weight Weight Tube Weight Tube Bumper...
  • Page 31 EXPLODED DRAWING—Model No. IMSY59300 R0801A...

  • Page 32: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: 1. The MODEL NUMBER of the product (IMSY59300) 2. The NAME of the product (IMAGE ® 8.0 weight system) 3.
