1. Getting Started
1.1 Unpacking the Printer:
The S3500THS and S3500T portable printers are full featured portable receipt
printers designed for varied job environments including field service, field sales,
hospitality and restaurants, ticketing and many others where point of service
receipts are required. The package contains:
printer:
battery cartridge,
AC input, DC output wall mounted charger (may be USA, European or UK
style plug) for charging the battery inside the printer
belt loop system and
roll of paper supply (already loaded in the printer).
Both cabled and wireless communication is possible.
1.2 Installing and Charging the Battery Cartridge:
Note: One battery cartridge is included with the printer. Similar to a
cordless phone battery, the printer's battery must be charged before using
it.
Extech batteries must be cycled several times to achieve maximum
capacity. To cycle a battery fully charge it and then allow full
!
discharge through normal use in the printer.
1
.
2
.
1
:
I
n
s
t
a
l
l
i
n
g
1
.
2
.
1
:
I
n
s
t
a
l
l
i
n
g
Note: Refer to Figure 1 below to install the battery pack in the
printer.
Unlock the battery door by sliding down the battery door locking tabs
Open the battery door
Insert the battery as shown. The end with three contact terminals is inserted
first
Close the battery door
Lock the battery door by sliding up the battery door locking tabs
To remove the battery cartridge, open the battery door and tip the battery
out of the printer.
t
h
e
b
a
t
t
e
r
y
t
h
e
b
a
t
t
e
r
y
Page 5
