Part Identification ChartÑModel No. IMBE12500

M10 Washer (6)

M6 Washer (30)

M8 Nylon Locknut (42)

M10 Nylon Locknut (11)

M6 x 16mm Screw (3)

M6 x 35mm Bolt (34)

M6 x 55mm Screw (4)

M10 x 60mm Button Head Bolt (12)

M8 x 70mm Bolt (41)

M10 x 70mm Bolt (21)

M10 x 80mm Bolt (31)
