  • Page 1 RENLIG FWM7D5...
  • Page 3 ENGLISH...
  • Page 4: Table Of Contents

    Daily Use - Drying Electrical connection Daily Use - Washing & Drying Environment concerns Helpful hints and tips IKEA GUARANTEE Drying Hints Subject to change without notice. Safety information For your safety and correct operation of the appliance, read this manual carefully before installation and use.
  • Page 5 ENGLISH • Always unplug the appliance and turn off • Only an authorised service engineer can the water supply after use, cleaning and repair this appliance. Use only original maintenance. spare parts. • Only wash and dry fabrics which are de- Installation signed to be machine washed or dried.
  • Page 6 ENGLISH • Do not put flammable products or items Water inlet that are wet with flammable products in, • This appliance must be connected to a near or on the appliance. cold water supply. • The users should always check that they •...
  • Page 7: Product Description

    ENGLISH • The washing powder and additive dis- • Never remove the pump cover during a penser drawer should be cleaned regu- wash cycle. Always wait until the appli- larly. ance has drained out the water. If you • Inspected the pump regularly and partic- have selected an high temperature wash- ularly if: ing programme please wait until the wa-...
  • Page 8: Control Panel

    ENGLISH Detergent dispenser drawer must be poured into the compartment be- fore starting the wash programme. Compartment for detergent used for prewash and soak phase or for stain re- mover used during the stain action phase (if available). The prewash and soak de- tergent is added at the beginning of the wash programme.
  • Page 9 ENGLISH Table of symbols = On/Off - Reset = Rapid 14’ = Cottons = Rinse Hold = Synthetics = Drying = Easy Iron = Cupboard dry = Delicates = Iron dry = Handwash = Drying time = Prewash = Wool = Rinses = Extra Rinse = Drain...
  • Page 10 ENGLISH Display The display shows the following information: • – Child safety lock. This device permits you to leave the appliance un- attended during it's functioning. • – Duration of the selected programme. After selecting a programme, the duration is dis- played in hours and minutes (for example The duration is calculated automatically on the ba- sis of the maximum recommended load for each...
  • Page 11 ENGLISH Door Locked indicator light The indicator light 4 illuminates when the programme starts and indicates if the door can be opened: • light on: the door cannot be opened. The machine is working or has stopped with water left in the tub. •...
  • Page 12: First Use

    ENGLISH First use • Ensure that the electrical and water • Before the first wash, run a cotton connections comply with the installa- cycle at the highest temperature tion instructions. without any laundry in the machine, • Remove the polystyrene block and to remove any manufacturing resi- any material from the drum.
  • Page 13 ENGLISH Select the available options by pressing details in "Degrees buttons 6 and 7 of water hardness". Depending on the programme, different Pour fabric softener functions can be combined. These must be into the compart- selected after choosing the desired pro- ment marked gramme and before starting the pro- (must not exceed...
  • Page 14 ENGLISH 3. Press button 5 again to start the pro- Press the button again to restart the pro- gramme. gramme. Cancelling a programme • The selected delay can be changed only after selecting the washing pro- Turn the selector dial to O to cancel a pro- gramme again.
  • Page 15: Daily Use - Drying

    ENGLISH At the end of the programme, the door is Stand by : once the programme has finish- released and can be opened. Turn the pro- ed after a few minutes the energy saving system will be enabled. The brightness of gramme selector dial to to switch the the display is reduced.
  • Page 16: Daily Use - Washing & Drying

    ENGLISH If you set only 10 minutes of drying the appliance performs only a cooling phase with the drying time button (8), phase. Daily Use - Washing & Drying NON-STOP programme - Washing and 6. At the end of the programme turn the Timed Drying selector dial to the position to switch...
  • Page 17: Helpful Hints And Tips

    ENGLISH The released fluff could stick to the fabrics • To air-dry this type of fabrics when they during the next cycle. are washed the first time. This drawback increases with technical fab- • To clean the filter. rics. • Perform one or more rinse cycles to wash To prevent the lint in your clothes, it is rec- the drum between the washing and dry- ommended:...
  • Page 18: Drying Hints

    ENGLISH Degrees of water hardness Characteristic German °dH French °T.H. Medium 8-14 16-25 Hard 15-21 26-37 Very hard > 21 > 37 A water softener must be added when water has a medium-high degree of hardness. Follow the manufacturer’s instructions. The quantity of detergent can then always be adjusted (reduced) to degree of hardness soft.
  • Page 19: Washing Programmes

    ENGLISH Follow the product manufacturer’s recom- The average drying time for a timed drying mendations on quantities to use and do not are indicated in the «Drying programmes» exceed the «MAX» mark in the detergent chapter. The experience will help you to dry dispenser drawer.
  • Page 20 ENGLISH Selecting this pro- Main wash 1.5 kg Spin gramme the laundry Rinses Rinse Hold Synthetics is gently washed and Max. final spin at Prewash Easy Iron spun to avoid any 900 rpm Extra Rinse 40° creasing. In this way ironing is easier.
  • Page 21: Drying Programmes

    ENGLISH Separate spin for Max. final spin at 7 kg Spin hand washed gar- 1600 rpm Spin ments and after pro- grammes with the Rinse Hold option se- lected. You can choose the spin speed by pressing the relevant button to adapt it to the fabrics to be spun.
  • Page 22: Consumption Values

    ENGLISH Timed Spin Suggested Drying Degree of Drying Type of Fabric Speed drying time Load (rpm) (minutes) Cupboard dry Cotton and linen 5 kg 165-185 Suitable for items to put (bathrobes, bath 3.5 kg 1600 85-95 away without ironing towels, etc) 2 kg 35-45 Cupboard dry...
  • Page 23: Care And Cleaning

    ENGLISH Care and cleaning Warning! Switch the appliance off Use a stiff brush to before you carry out any cleaning or clean and remove maintenance work. all washing powder residue. Maintenance Wash With the use of low temperature washes it is possible to get a build up of residues inside the drum.
  • Page 24 ENGLISH Open the pump door. Pull back the drainage duct. Put a container below the recess of the Unscrew the filter and remove it. drain pump to collect the water that flows out. Remove fluff and objects from the pump. Press the two levers and pull forward the drainage duct to let the water flow out.
  • Page 25 ENGLISH Clean the filter under the water tap and • Unscrew the hose from the appliance. put it back in the pump into the special Keep a rag nearby because some wa- guides. ter may flow. Make sure that you tighten correctly the •...
  • Page 26: What To Do If

    ENGLISH 4. open the pump door; 8. if necessary clean the pump (refer to 5. place a container on the floor below the section ‘Cleaning the pump’ ); the recess of the drain pump; 9. close the drain pump door. 6.
  • Page 27 ENGLISH Problem Possible cause Solution An option or a programme that Select the draining or spinning ends with the water still in the tub programme. or a that eliminates all the spinning phases has been selected. The appliance Close the door firmly. door is open or not closed cor- rectly.
  • Page 28 ENGLISH Problem Possible cause Solution Check whether there are any leaks Check the water inlet hose connec- from one of the inlet hose fittings. It tion. is not always easy to see this as the water runs down the hose; check to see if it is damp.
  • Page 29: Technical Data

    If the malfunction shows again, contact your After Sales Service. Model description (MOD): ..... Product number (PNC): ......Serial number (S.N.): ....... Made In Italy © Inter IKEA Systems B.V. 1999 000.000.00 21552 Technical data Dimensions Width (cm) 59,6 Height (cm)
  • Page 30: Electrical Connection

    ENGLISH Cotton max. load (kg) Max. spin speed (rpm) 1600 Energy class Washing class Spinning class Washing noise (dB(A)) Spinning noise (db(A)) Average annual energy consumption (kWh) Average annual water con- 19400 sumption (litres) 1) If the pressure in your area is lower or higher, please contact your After Sales Service. 2) The data is based on the washing programme for test institutes assuming 200 cycles per a year.
  • Page 31: Ikea Guarantee

    1st of August 2007 placed parts become the property of IKEA. Who will execute the service? What will IKEA do to correct the problem? IKEA service provider will provide the serv- IKEA appointed service provider will exam- ice through its own service operations or ine the product and decide, at its sole dis- authorized service partner network.
  • Page 32 • The use of the appliance in a non-domes- IKEA appliances: tic environment i.e. professional use. Please do not hesitate to contact IKEA After • Transportation damages. If a customer Sales Service to: transports the product to their home or 1.
  • Page 33 To ensure that we provide you with the best Before calling us, assure that You have to assistance, please read carefully the As- hand the IKEA article number (8 digit code) sembly Instructions and/or the User Manual for the appliance of which you need our section of this booklet before contacting us.
  • Page 34 Hétköznap 8 és 10 óra között 0900 235 45 32 ma-vr 9.00-21.00 Nederland and/or 0, 1 0 EUR/min (niet lokaal)Incl. BTW zat 9.00-20.00 0900 BEL IKEA zon 9.00-18.00 Norge 815 22052 Takst innland 8 til 20 ukedager Österreich 0810 300486...
  • Page 36 © Inter IKEA Systems B.V. 2008 AA-596971-1...
