This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot work-
ing surfaces while in use or until the appliance has thoroughly cooled.
INSTALLATION AND OPERATION INSTRUCTIONS
To ensure safety, satisfaction and reliable service this stove should be installed by a suitably qualified
OISIN MK II
GAS STOVE
and competent person.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stanley OISIN MK II
Summary of Contents for Stanley OISIN MK II
- Page 1 OISIN MK II GAS STOVE This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot work- ing surfaces while in use or until the appliance has thoroughly cooled.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE NO. Operation Instructions ........... 2 Precautions . -
Page 3: Operation Instructions
OPERATION INSTRUCTIONS Fig. 1 WARNING: Do not operate the stove with the appliance door open, or if the glass panel in the front door has been broken or removed. Ensure that the door latch is fully locked. Keep the door spin valve closed at all times when stove is in operation. -
Page 4: What To Do If You Smell Gas
If stove fails to light repeat the above procedures. If stove fails to light after three attempts contact your local Stanley Dealer. NOTE: During the first light-up period an odour will arise from the stove, this is due to the materi- als in the stove drying and curing. -
Page 5: Technical Data
Appliance Category BIIBS Country of Designation: IE, GB, FR & BE Thank you for buying a Stanley Oisin Mk II Gas Gas Types: Stove. The room heater and flue system should L.P.G.: Propane I , G31, 37 mbar/14.8”wg or be inspected before use and at least annually. -
Page 6: Pre-Installation Assembly
There are many conditions to be considered outlet configuration factory fitted. It may be when selecting the location for you Oisin MK II changed to a top flue outlet by simply switching Gas Stove. the blanking cap and flue collar as shown in MINIMUM CLEARANCES TO COMBUSTIBLE Fig. -
Page 7: Hearth Fitting
Fig.14 MATERIALS (see figs 11, 12, 13, 14) Back wall 6” (150mm) Left side wall looking from front 5” (125mm) Right side wall looking from front 5” (125mm) Alcove or mantle from top of unit 18” (459mm) From Corner 5” (125mm) Fig.11 Fig.15 When installing the stove against a... -
Page 8: Chimney's/Flues
CHIMNEY’S / FLUES Clay flue linings conforming to I.S. 51 & B.S. EN 1457 1999. If connecting to a rear exit configuration the hori- Pre-cast concrete chimney blocks, incor- zontal run should not exceed 300mm (12”) from porated into the building structure. It is the stove outlet. -
Page 9: Factory-Made Insulated Chimneys
Fig.18 FACTORY-MADE INSULATED CHIMNEY’S Factory-made insulated chimneys must be con- structed and tested to meet the relevant standards and recommendations given in: B.S. 7566: Installation of factory made chimney’s conforming to B.S. : 4543 for domestic appliances. Part 1: Method of specifying installation design information. -
Page 10: Meters
Fig.22 B.S. 669 - flexible hoses, fittings & sock- ets. B.S. 759 - valves, gauges and other safe- ty equipment. B.S. 1387 - Steel tubes. B.S. 6362 - stainless steel tubes. B.S. 1740 - Wrought steel pipes. B.S. 4089 - L.P.G. hoses and assemblies. Fig.23 METERS A suitable gas meter must be connected to the... - Page 11 Before positioning the coals in the com- Place 4 large coals on the rear of the bustion chamber, check for dust particles matrix with their corners touching. The and grime, vacuum if necessary. Position front corner should over hang the back the coals as per instructions as incorrect section of the matrix by approximately placement will effect the performance of...
-
Page 12: Lighting
Fig.29 During the first light up period an odour will rise from the stove, this is due to the materials in the stove drying and curing. It is advisable to open a window or door to give extra ventilation to the room until the odour has gone. -
Page 13: Maintenance
IMPORTANT: Please ensure that the pilot injec- Fig.35 tor is clear at all times, as a partially blocked injec- tor will result in a reduced flame which may be insufficient for ignition purposes. MAINTENANCE CAUTION: Maintenance of this stove should only be carried out by a qualified/competent Gas Engineer. -
Page 14: Enamel Cleaning
ENAMEL CLEANING General cleaning must be carried out when the stove is cool. If this stove is finished in a high gloss vitreous enamel, to keep the enamel in the best condition observe the following tips: Wipe over daily with a soapy damp cloth, followed by a polish with a clean dry duster. -
Page 15: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Pilot will not light No gas Check gas is turned on. Safety interlock preventing Wait 5 minutes & attempt to relight. Operation. Control knob not fully pressed. Ensure control knob is being fully pressed. -
Page 16: Installation Checklist
A shut off valve must be used to connect the gas supply as close as possible to the stove and should be accessible at all times. A soundness test must be conducted to check all joints for gas tightness. Manufactured by Waterford Stanley Ltd., Unit 210, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315...
