Instruction Manual
92x25mm AMD Ball Bearing CPU Cooler
Fan w/ TX3 Connector
FANK8AM2
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• Heatsink and Fan
• Instruction Manual
• Thermal Compound
Specifications
Fan Dimensions
Heatsink Dimensions
Bearing Type
Heatsink Base Material
Fan Material
Rated Voltage
Noise Level
Air Flow Rate
Connector Types
Best Fit Applications
For the most up-to-date information, please visit: www.startech.com
70 x 70 x 10 mm
107 x 71.8 x 25.5 mm
Dual Ball Bearing
Copper
Plastic
12 V
<36 dB
25.63 CFM
1 x TX3 Female
Designed for AMD Socket AM2 series,
typically found in Server class systems
with 1U low profile design:
AMD Opteron 1210HE - 1218 HE(to
65w)
AMD Sempron 2800+ - 3800+(to 62w)
AMD Sempron LE1100 - LE1250(to
45w)
Athlon 64 3000+ - 4000+(to 65w)
Athlon 64 LE1600 - LE1620(to 62w)
Athlon 64 x2 3600+ - 5200+(to 65w)
Athlon X2 BE2300 -BE2400(to 45w)
Installation
1. From the underside of the motherboard, position the Fastening
Plate under the CPU position such that the four screw posts are
inserted through the holes on the motherboard.
2. From the topside of the motherboard, apply Thermal Heatsink
Grease evenly to the surface of the CPU. Only apply as much
grease as will be required to cover the surface of the CPU once
the heatsink has been installed, as the pressure of the heatsink
application will spread the grease.
3. Place the heatsink and fan over the CPU, aligning the four holes
on the heatsink with the screw posts (see step #1).
4. Secure the heatsink and fan to the Fastening Plate, using the four
spring screws.
5. Connect the 3-pin (TX3) connector (on the fan) to the appropriate
connector on the motherboard.
*actual product may vary from photos
Manual Revision: 03/02/2012
