- Page 1 User’s Manual 4.4 Cu.Ft. Compact Refrigerator MODEL: CCR44CE1W BEFORE USING YOUR PRODUCT: Please read this manual carefully all safety rules & operating instructions. Keep this manual for future refrence.
-
Page 2: Safety Warnings
Safety Warnings • For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. •... -
Page 3: Installation
Installation When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 60.8°F and 90°F. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. - Page 4 Remove the top right hinge cover. Undo the screws. Then remove the hinge bracket. Remove the top left screw cover. Move the core cover from left side to right side. And then lift the door and place it on a padded surface to prevent it from scratching.
- Page 5 Remove the screws and bottom hinge. Then remove the adjustable feet from both side. Unscrew Unscrew and remove the bottom hinge pin, turn the bracket over and replace it. Unscrew Screw Refit the bracket fitting the bottom hinge pin. Replace both adjustable feet.
- Page 6 Place the door back on. Ensure the door is aligned horizontally and vertically so that the seals are closed on all sides before finally tightening the top hinge. 10. Insert the hinge bracket and screw it to the top of the unit. 11.
-
Page 7: Leveling The Unit
Installation Leveling the Unit To do this adjust the two leveling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly. Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a ‘wrung-out’... -
Page 8: Product Overview
Product Overview... -
Page 9: Operation
Operation Operation Switching On Your Unit Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by a thermostat. There are six settings, of which position 5 is the coldest and position 0 turns the unit off. Adjust the thermostat control dial to the desired position, bear in mind that the higher the number, the lower the temperature. -
Page 10: Tips For Keeping Food In The Unit
Shopping for Chilled Foods • Take a quick look at the chilled food package and make sure it is in perfect condition. • Try to keep chilled food together while shopping and on the journey home as this will help to keep the food cold. •... -
Page 11: Cleaning The Interior And The Exterior Of The Unit
Cleaning Defrosting Frost may accumulate on the inner rear surface of the appliance which will automatically defrost during the off cycle of the compressor. Water is channelled via the drain hole to the collection tray above the compressor where it will evaporate. Please ensure the drain hole is checked and cleaned on a regular basis so water can exit the storage compartment. -
Page 12: Maintenance
Maintenance Maintenance Changing the Internal Light 1. Before carrying out the bulb replacement always adjust the thermostat control dial to Position 0, then disconnect the mains supply. 2. Use a flat bladed screwdriver and gently pry off the light bulb cover. 3.
