Criterion CFRR310WD Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Guide Manual
CFRR310WD#*#
Criterion®
Code: F86MW-01-V1

Advertisement

Table of Contents
loading

Related Manuals for Criterion CFRR310WD Series

Summary of Contents for Criterion CFRR310WD Series

  • Page 1 User Guide Manual CFRR310WD#*# Criterion® Code: F86MW-01-V1...

  • Page 2: Table Of Contents

    Important Safety Instructions ......3-6 Connecting the Water Line ........Water Filter ............. Parts and Features ........... 7 Care and Cleaning ..........29-30 Refrigerator Installation ........8-16 Troubleshooting Guide ........31-38 Unpacking Your Refrigerator ........8 Service ............. Back Cover Prior to Use ..............

  • Page 3: Important Safety Instructions

    BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word DANGER, WARNING or CAUTION.
  • Page 4 • • Before replacing a burned-out or broken light bulb, unplug Never pour or spray water into the refrigerator (both interior the refrigerator or turn off power at the circuit breaker or exterior). - Electric insulation gets weakened, resulting fuse box in order to avoid contact with a live wire filament. in a risk of electric shock hazards.
  • Page 5 • Be sure to turn up the wheel first before moving the ... Thawed ground meats, poultry or fish that have any off-odor refrigerator - Be sure to turn up the wheel first before or off-color should not be refrozen and should not be eaten.
  • Page 6 Your old refrigerator may have a cooling system that used CFCs the refrigerant is removed for proper disposal by a qualified or HCFCs (chlorofluorocarbons or hydrochlorofluorocarbons). technician. If you intentionally release CFCs and HCFCs are believed to harm stratospheric ozone if refrigerant, you may be subject to fines and imprisonment released to the atmosphere.

  • Page 7: Parts And Features

    ❼ OPEN CLOS ❶ ❻ ❺ ❸ SLIM ICE MAKER ❽ ❾ ❷ ❾ ❷ ❹ ❹ ❹ TEMPERATURE C O N T R O L L E D PANTRY DRAWER Covered Dairy Bin or Covered Storage Bin 10. Slide-in Shelf for storing butter and cheese.

  • Page 8: Refrigerator Installation

    Excessive Weight Hazard: Excessive Weight Hazard: Your refrigerator is heavy. When moving the refrigerator for Use two or more people to move and install the refrigerator. cleaning or service, be sure to protect the floor. Always pull Failure to do so can result in back or other injury. the refrigerator straight out when moving it.

  • Page 9: Prior To Use

    INSTALLATION (continued) PRIOR TO USE 1. Clean your refrigerator thoroughly and wipe off all dust that 1. To avoid noise and vibration, the unit must be leveled and accumulated during shipping. installed on a solidly constructed floor. If required, adjust the leveling legs to compensate for unevenness of the 2.

  • Page 10: Removing/Replacing Your Refrigerator And Freezer Handles, Doors And Drawers

    NOTE: Removing the doors is always recommended when it is necessary to move the refrigerator through a narrow opening. If it is necessary to remove the handles, follow the directions below. HOW TO REMOVE REFRIGERATOR DOOR HANDLE NOTE: Handle appearance may vary from the illustrations on this page.
  • Page 11 NOTE: Removing the doors is always recommended when it is necessary to move the refrigerator through a narrow opening. If it is necessary to remove the handles, follow the directions below. HOW TO REMOVE FREEZER DRAWER HANDLES NOTE: Handle appearance may vary from the illustrations on this page.
  • Page 12 REMOVING AND REPLACING Lift the door from the middle hinge pin and remove the door. Place the door, inside facing on a non-scratch REFRIGERATOR DOORS surface. Risk of electric shock! Before removing top hinge cover • Shut off the water supply to the appliance. •...
  • Page 13 Reinstalling the Left Refrigerator Door Reinstalling the Right Refrigerator Door Lower the door onto the middle hinge. Lower the door onto the middle hinge. Fit the top hinge over the mounting holes and align to Fit the top hinge over the mounting holes and align to proper position before tightening.
  • Page 14 HOW TO REMOVE THE FREEZER DRAWER WARNING: Use two or more people to remove and install Pull exterior freezer drawer to fully disengage the rail the freezer drawer. Failure to do so can result in personal assembly from the unit. Use 2 people for this task as the injury, product or property damage.
  • Page 15 HOW TO INSTALL THE FREEZER DRAWER 1. Retract the inner rail track fully into the outer rail track 3. Replace the lower freezer drawer basket. before installing freezer drawer. With the aid of an assistant, align the rail ends with the rail guides located on 4.

  • Page 16: Refrigerator Leveling & Door Adjustment

    Adjusting the freezer drawer REFRIGERATOR LEVELING & DOOR ADJUSTMENT If the freezer drawer is lower on one side than the other, perform the steps listed below to raise that side. To access The refrigerator must be level in order to maintain optimal the adjustment components, first pull the drawer out to full performance and desirable front appearance.

  • Page 17: Using Your Refrigerator

    To activate refrigerator QUICK CHILL, press and hold the FRIDGE TEMP button for 3 seconds. QUICK CHILL LED will turn on. Press the button again to cancel. The QUICK CHILL function is useful to help quickly cool the refrigerator compartment when needed. For example: If a large quantity of warm food is placed inside the refrigerator, or if loading the refrigerator with new groceries wich may not be as cold as normal refrigerator...
  • Page 18 When the WATER FILTER CHANGE icon turns on, you need to change the water filter. alarm will always be functional. Presing the DOOR ALARM After changing the water filter, press and hold the WATER FILTER button for three seconds to turn the indicator light off. You need to change the water filter approximately every six months for more than 60 seconds, the DOOR ALARM button LED Pressing the DOOR ALARM button or closing the door or...

  • Page 19: Pantry Control Panel

    Touch the WATER, CUBED ICE or CRUSHED ICE text according to your needs. See page 24 for additional Dispenser user information Press the SELECT button and the Temperature setting changes Press and hold the LOCK button for 3 seconds to turn the The LOCK icon turns on Press and hold the LOCK button for 3 seconds to turn the See page 26 for additional Pantry use information.

  • Page 20: Control Panel

    icemaking is automatically set to on. To turn icemaking off or on, see the instructions in shutting icemaking off As long as icemaking is turned on in the control panel To turn icemaker ON or OFF: Press the control panel ICE MAKER button.
  • Page 21 If ice or water dispenses unexpectedly, turn off the water supply and contact Customer Service (toll free) at 1-877-393-7823...
  • Page 22 How to use the Automatic lcemaker The dispenser icemaker will produce 12 cubes per cycle. • The dispenser icemaker will produce approximately 216 - 288 cubes (20 - 24 cycles a day) in a 24 hour period, depending on freezer compartment temperature, room temperature, number of door opening and other user conditions.

  • Page 23: Food Storage Guide

    FOOD STORAGE GUIDE STORING FROZEN FOOD Wrap or store food in the refrigerator in airtight and moisture- NOTE: Check a freezer guide or a reliable cookbook for proof material unless otherwise noted. This prevents food further information about preparing food for freezing or food odor and taste transfer throughout the refrigerator.

  • Page 24: Refrigerator Section

    REFRIGERATOR SECTION WATER OR ICE DISPENSER Foldaway door bar (mullion bar) To dispense water or ice, press the Water, Cube Ice or When closing the left refrigerator door, the mullion bar folds Crushed Ice icon on the Dispenser Control panel. Push on behind the right refrigerator door, forming a seal between the dispenser lever with the side of your glass.
  • Page 25 FRUITS - Slide the Humidity Control toward “Vegetables” to keep moist air in crisper for best storage of fresh, leafy vegetables. - Slide the Humidity Control toward “Fruits” to release moist air from crisper for best storage of fruit.
  • Page 26 Press SELECT button to choose between MEAT, PRODUCE or DELI. the LOCK button for 3 seconds. To unlock,...

  • Page 27: Connecting The Water Line

    BEFORE YOU BEGIN WATER SUPPLY KIT Connecting the water line to the refrigerator. This water line installation is not covered by the refrigerator warranty. Follow these instructions carefully to minimize the risk of expensive water damage. Water hammer (water banging in the pipes) in house plumbing can cause damage to refrigerator parts and can lead to water leakage or flooding.

  • Page 28: Water Filter

    A replacement filter can be purchased by contacting your local dealer.

  • Page 29: Care And Cleaning

    WATER OPEN CLOSE FILTER DAIRY BIN SLIM ICE MAKER TEMPERATURE CONTROLLED PANTRY DRAWER 1. Water Dispenser 4. Refrigerator Shelves • Clean the water collecting tray with a sponge or To remove a shelf: Lift up absorbent cloth. on front of shelf with one hand and with other hand 2.
  • Page 30 LIGHT BULB REPLACEMENT WHEN YOU MOVE When you are moving your refrigerator to a new home, follow these steps to prepare it for the move. Electrical Shock Hazard 1. Remove all food from the refrigerator and pack all frozen food in dry ice. Before replacing a Compartment Lamp, either unplug 2.

  • Page 31: Troubleshooting Guide

    COOLING Problem Possible Causes Solutions Power cord unplugged. Plug into a known properly grounded 3-prong outlet. Refrigerator and Freezer section are Refrigerator is set to demo mode. Demo Mode allows the lights and control display to work not cooling. normally while disabling cooling to save energy while on the showroom floor.
  • Page 32 COOLING Problem Solutions Possible Causes Refrigerator or Refrigerator was recently installed. It may take up to 24 hours for each compartment to reach the Freezer section is too desired temperature. warm. Doors are opened often or for long When the doors are opened often or for long periods of time, periods of time.
  • Page 33 COOLING/ICE & WATER Problem Possible Causes Solutions Food is freezing Food with high water content was Rearrange items with high water content away from air vents. in the refrigerator placed near an air vent. compartment. Refrigerator temperature control is set If the temperature is too cold, adjust the control one increment incorrectly.
  • Page 34 ICE & WATER Problem Possible Causes Solutions lcemaker is not Tubing connecting refrigerator to house The tubing can kink when the refrigerator is moved during making enough ice supply valve is kinked. installation or cleaning resulting in reduced water flow. (continued).
  • Page 35 ICE & WATER Problem Possible Causes Solutions lcemaker is not Refrigerator was recently installed or It may take up to 24 hours for each compartment to reach the making ice. icemaker recently connected. desired temperature and for the icemaker to begin making ice.
  • Page 36 ICE & WATER Problem Possible Causes Solutions Ice has bad taste or Water supply contains minerals such A water filter may need to be installed to eliminate taste and odor. as sulfur. odor problems. NOTE: In some cases, a filter may not help.
  • Page 37 NOISE Problem Possible Causes Solutions Clicking The defrost control will click when Normal Operation the automatic defrost cycle begins and ends. The thermostat control (or refrigerator control on some models) will also click when cycling on and off. Rattling Rattling noises may come from the Normal Operation flow of refrigerant, the water line on the back of the unit, or items stored...
  • Page 38 PARTS & FEATURES Problem Possible Causes Solutions Doors will not close Food packages are blocking the door Rearrange food containers to clear the door and door correctly or pop open. shelves. open. Ice bin, crisper cover, pans, shelves, Push bins all the way in and put crisper cover, pans, shelves door bins, or baskets are out of...

  • Page 39: Service

    Criterion warrants to replace or repair parts to correct defects in materials or workmanship that existed when the appliance was purchased. In-home service will be provided during the warranty labor period subject to availability within the United States.
