Summary of Contents for Manhattan 709026
-
Page 1: User Manual
USB SATA 3.5” drive encloSUre USer mAnUAl Model 709026 MAN-709026-UM-0308-07... -
Page 2: Hardware Installation
Thank you for purchasing the MANHATTAN Hi-Speed USB SATA 3.5” ® Drive Enclosure, Model 709026. Supporting large-capacity 3.5” SATA drives up to 2 TB and Hi-Speed USB data transfer rates of up to 480 MBps, this Drive Enclosure offers a versatile and portable data solution. - Page 3 3. Carefully place your hard drive in the base of the enclosure so a solid connection is made with the 22-pin SATA connector. 4. Use the included screws and screwdriver to secure the hard drive in place (see the image above), then slide the cover of the enclosure back in place. Place the device in the stand, if desired.
-
Page 4: Driver Installation
Removing the Drive Enclosure Before you disconnect the device from your computer, follow these steps. 1. Click the Clone Me icon on your desktop. (See Driver Installation below.) 2. When the Safely Remove Hardware screen displays, click “Stop.” 3. When the “It is now safe to remove the USB device” message displays, disconnect the USB cable (and the power adapter, if connected). driver inSTAllATion Once the enclosure is connected to your computer, your system will automatically detect the new hardware and complete the setup, confirmed when the representative Clone Me icon appears in your systems tray. - Page 5 4. When the InstallShield Wizard Completed screen displays, click “Finish.” one-ToUch BAckUp fUncTion These steps show how to use the convenient One-Touch Backup feature. 1. Once the software install is complete, a Clone Me icon will display on the desktop. Double- click the icon to display the initial function screen. 2.
- Page 6 3. When the Backup prompt asks “Save the change?” click “Yes.” 4. Click “OK” in the subsequent prompt window, then click “Backup” or press the Backup button on the device once. 5. The Backing Up screen will display with a status bar to indicate that the process has begun. 6. When the Back Up screen displays the “Completed without Error”...
-
Page 7: Specifications
SpecificATionS Standards and Certifications • USB 2.0 to SATA interface • CE • FCC General • MA6116 chipset • SATA L-type internal data and power connections • DC single-post power input (power adapter included) • Power adapter: input, 100 – 240 V, 50 – 60 Hz, 0.8 A; output, 12 V / 2 A; cable, 1.5 m (4.9 ft.) • USB mini-B to type-A cable, 70 cm (2.3 ft.) • Working temperature: 0 – 45ºC • ABS construction • Power/activity LED indicator • Enclosure stand • 19.5 x 12.5 x 3.5 cm (7.75 x 4.75 x 1.25 in.) • 184 g (6.5 oz.) without hard drive System Requirements • Available USB type-A port • Windows XP/Vista/7 and Mac support Package Contents • Drive Enclosure • USB cable, power adapter, stand, installation hardware, screwdriver,... - Page 8 MANHATTAN offers a complete line ® of PC Components, Peripherals, Cables and Accessories. Ask your local computer dealer for more information or visit us online at www.manhattan-products.com Copyright © MANHATTAN All products mentioned are trademarks or registered trademarks of their respective owners.
