Summary of Contents for Manhattan 709033
- Page 1 2.0 esATA, 3.5” drive enclosure user MAnuAl MODEL 709033 MAN-709033-UM-0308-02...
- Page 2 Thank you for purchasing the MANHATTAN eSATA, 3.5” Drive Enclosure, Model 709033. ® Fully SATA-capable and equipped with SATA L-type internal and eSATA I-type external data ports, it quickly transfers data without conversion between SATA-enabled systems. Hi-Speed USB 2.0 connections offer convenient and versatile data storage, transfer and recovery solutions. Plus: •...
-
Page 3: Hardware Installation
hArdwAre insTAllATion NOTE: Images are for example only. Actual positions of switches or connectors may vary slightly. 1. Open the enclosure. 3. Tighten the sides screws 2. Connect the power and to secure the HDD. SATA cables to the HDD. 12 V DC in On/Off port... -
Page 4: Software Installation
sofTwAre insTAllATion Windows 2000/XP 1. Click on the My Computer icon; click "Manage" to initialize the hard disk drive. - Page 5 2. Click "Disk Management," then click "Removable Disk," then click "Format."...
- Page 6 3. Confirm that "Removable" and "FAT32" are entered/selected in the "Volume label" and "File system" fields, respectively. Click "OK." 4. When the warning prompt appears, click "OK."...
-
Page 7: Specifications
5. Click "My Computer" and confirm that the new "Removable" icon appears. The Drive Enclosure with hard disk drive is now ready for use. specificATions • JMICRON 20316 chipset • SATA L-type internal data and power connections • Hi-Speed USB 2.0 B-type and eSATA I-type external connections •... - Page 8 PC Components, ® Peripherals, Cables and Accessories. Ask your local computer dealer for more information or visit us online at www.manhattan-products.com Copyright © MANHATTAN All products mentioned are trademarks or registered trademarks of their respective owners.
