SPS.ADVANCE RT series
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPS.Advance RT series and is the answer not in the manual?

Questions and answers

Related Manuals for Thiele SPS.Advance RT series

Summary of Contents for Thiele SPS.Advance RT series

  • Page 1 Tel.:+49 (0)7191 3560-0 (Fax.:-19) UNINTERRUPTIBLE POWER SUPPLY (UPS) + LIGHTING FLOW DIMMER STABILIZERS (ILUEST) + SWITCH MODE POWER SUPPLY + STATIC INVERTERS + PHOTOVOLTAIC INVERTERS + VOLTAGE STABILIZERS AND POWER LINE CONDITIONERS UNINTERRUPTIBLE POWER SUPPLY SPS.ADVANCE RT series USER'S MANUAL...
  • Page 2 Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19)

  • Page 3: Table Of Contents

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) General index Introduction. Operating. 1.1. Acknowledgement letter. 5.1. Start up. 1.2. Using this manual. 5.1.1. Controls before commissioning. 5.2. UPS start up and shutdown. 1.2.1. Conventions and used symbols. 1.2.2.

  • Page 4: Introduction

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Introduction. instructions can cause serious incidents. Those indications with “CAUTION ” symbol content features and basic instructions for safety of the things. To not respect such instructions can damage the goods.

  • Page 5: General Safety Warnings

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) and those equipments with power blocks there is an exclusive If the instructions are not in total or partial and in terminal for the load earth connection. When an outgoing dis- special referred to the safety, do not carry on with tribution is done, i.e power strips, it is essential that they have the installation or commissioning tasks, because there...

  • Page 6: To Keep In Mind

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) So, to do it, the input and static bypass switches will have to Do not store, install or expose the equipment in corrosive, be turned «Off». wets, dusty inflammable or explosive environments and never outdoors.
  • Page 7 Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) When faulty batteries are replaced, the complete battery set Do not dispose the batteries in a fire and high temperatures. has to be replaced, less exceptional cases in new equip- The batteries may explode.

  • Page 8: Declaration Of The Management

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Quality and standard 2.3. Environment. guarantee. This product has been designed to respect the environment and has been manufactured in accordance with the standard ISO 14001. 2.1. Declaration of the management. Equipment recycling at the end of its useful life: Our company commits to use the services of authorised socie- Our target is the client’s satisfaction, therefore this Management...

  • Page 9: Presentation

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Presentation. 3.1.2. Legend corresponding to the equipment views. Symbol and their meaning Symbol Meaning Symbol Meaning 3.1. Views. Warning Earth Electrical shock Alarm silenced 3.1.1. Equipment views. Figures 1 to 3 shows the illustrations of the equipment according UPS ON / Overload Battery test...
  • Page 10 Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Output connector, with Módem USB COM / ADSL / Fax / ... protection port Standard 750 and IEC inlet for AC power supply 1000 VA models IEC outlets Input connector, for modem RS232 COM Earth connection / ADSL / Fax / ...

  • Page 11: Definition Of The Product

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Toma tierra para conexión con equipo Battery module y con otro módulo de baterías The connection of the battery module with the equipment and/or with other module is done through the front. To do it, it will be needed to remove the front plastic trim of all the racks, to have access to the connection connectors ready for this purpose.

  • Page 12: Description And Operating Principle

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) 3.3. Description and operating 3.3.1. Main features. principle. Control by microprocessor with high reliability. Design of high frequency. This user's manual describes the installation and operating of Stabilizer with «Boost» and «Buck» technology. the Uninterruptible Power Supply (UPS) from SPS.ADVANCE Selectable output range and line sensitivity.

  • Page 13: Isolation Transformer

    The isolation transformer can be installed at the input or output of the UPS from SPS.ADVANCE RT series and it will always be located out from the equipment enclosure. 3.4.2. External maintenance manual bypass.

  • Page 14: Installation

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Installation. because due to its specification of isolation it will prevent the triggering of the protections fitted in the primary of the trans- former in case of electrical shock in the secondary (output of the isolation transformer).

  • Page 15: Storage

    4.2.4. Vertical assembling -tower type- or rack. All the UPSs from SPS.ADVANCE RT series are designed to assemble the equipment as tower format -vertical position of the equipment- or rack -horizontal position- for its installa- tion in 19"...

  • Page 16: Rotation Of Control Panel With Lcd Panel

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) To take out the beautiful front cover, proceed as follows (see figure 4): Remove the two fixing screws "C" from beautiful plastic front cover. Move the front cover to "D" direction, by applying a hard and moderated knock on its side (side without screws), to free the trim entered into the metallic frame.

  • Page 17: Rack Cabinet Assembling

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Remove the beautiful front cover of the equipment and battery module, as it is described in section 4.2.4.1. Take the extensible cable with connector "H" of the bat- tery module and connect it with the "G" connector of the equipment.

  • Page 18: Rack Cabinet Assembling, With Extended Back Up Time (Battery

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) installed by the end user. Make the assembling at the required height, assuring the correct torque of the fixing screws. Face the equipment over the rails and enter it to the bottom. Depending on the model of the equipment and as a result of the weight, it is recommended to make the installation works by two persons, and even more when they are...

  • Page 19: Connection Of Input

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Depending on the weight of model of the equipment and 4.3.2. Connection of the IEC outlets. battery module, it is recommended to make the installa- tion works by two persons. As this is a device with class I protection against elec- tric shocks, it is essential to install a protective earth Fix the equipment to the frame of the cabinet by means...

  • Page 20: Epo Terminals In Upss > 1Kva (Emergency Power Off

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Through the control panel, it can be selected the reverse Each battery module is independent for each equip- functionality, normally closed (NC). ment. It is completely forbidden to connect to equip- ments to the same battery module.

  • Page 21: As400 Interface With Db9 Output (Option

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) 4.3.6.3. AS400 Interface with DB9 output 4.3.7. Software. (option). Free software download - WinPower. Communication line (COM) is a very low voltage circuit WinPower is a UPS monitoring software, which makes a of safety.
  • Page 22 Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Nevertheless, when it is done, it will be done gradually to avoid any problem, as minimum in the first commissioning. If inductive loads with big inrush current apart from sensi- tive ones are required to be connected like laser printers or CRT monitors, keep in mind the start inrush currents of these peripherals in order to avoid that the equipment becomes...

  • Page 23: Operating

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Operating. to battery mode "BATT", with no break in the power supply to the outlets. Start up the load/s, without overloading the equipment. 5.2.3. Start up of the UPS, with no mains 5.1.

  • Page 24: Control Panel

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Control panel. The following critical alarms do not allow deactivating the own acoustic alarm: Low battery, Fan fault, internal Over temperature in the equip- ment and battery fault or damaged. The acoustic alarm can be deactivated when beeping, 6.1.

  • Page 25: Graphics Displayed In The Lcd Panel

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Code Condition Description LCD colour Code Description Values BATL Warning Battery voltage is too low. (220)=220V Output voltage selection. (230)=230V Fault due to internal temperature too (240)=240V OVTP Fault high.

  • Page 26: Setting The Ups To Connect It With "N" Battery Modules

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) 2.- Select the configuration elements. 3.- Validate the configuration element. Press the key to select the configurable elements When the LCD panel displays "GF", press the key stated in table 10 and go forward or backward till reaching more than one second to enter into the element to set.

  • Page 27: Maintenance, Warranty And Service

    1.2.3.3 side. The equipment from SPS.ADVANCE RT series only requires Therefore, before doing any reparation or maintenance task, a minimum maintenance. The used battery in the standard the internal battery fuses and/or the interlink connections be- models is lead acid, sealed, VRLA and maintenance free.

  • Page 28: Faq. General Indications

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) 7.2.2. FAQ. General indications. Problem Possible cause Solution The equipment doesn't start up when pressing Internal fuse blown. Consult with the S.T.S.. over the corresponding key. Jumpers at the output are not connected Connect the output jumpers.

  • Page 29: Technical Service Network

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) The needed visits for its correct resolution are unlimited and they are included inside the maintenance modalities. It means that in case of failure, we will check the equipments as many time as it were needed.

  • Page 30: Annexes

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Annexes. 8.1. Main general specifications. Models: SPS.ADV RT Available powers (kVA / kW) 0.750 / 0.675 1 / 0.9 1.5 / 1.35 1.5 / 1.35 (B1) 2 / 1.8 2 / 1.8 (B1) 3 / 2.7 3 / 2.7 (B1)

  • Page 31: Glossary

    Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) Models: SPS.ADV RT Available powers (kVA / kW) 0.750 / 0.675 1 / 0.9 1.5 / 1.35 1.5 / 1.35 (B1) 2 / 1.8 2 / 1.8 (B1) 3 / 2.7 3 / 2.7 (B1) Generals Cold start...
  • Page 32 Vorderer Weinberg 26 • D-71522 Backnang • Tel.:+49 (0)7191 3560-0 (Fax.:-19) LCD.- LCD acronym of Liquid Crystal Display, device in- vented by Jack Janning, who was employee of NCR. It is an electric system of data presentation based on 2 transparent conductor layers and in the middle a special crystal liquid that have the capacity to orientate the light when trespassing.
