  • Page 1 CIOT-1020M User Manual https://smartel.ua...

  • Page 2: Table Of Contents

    Contents ..........................Safety Warning & Caution Main funciton ............................4 Basic Screen Configuration ......................6 Home Screen ............................10 Home Area ............................. 10 2.1. Editing a space list ......................11 2.2. Registering a device ..................... 12 2.3. Placing device (move / delete) .................

  • Page 3: Main Funciton

    Start 1 Main function Function Description Display of widget type such as today's weather, indoor COMMAX temperature and humidity, smart plug electricity amount, Widget absence information Login User subscription and login to use UC and Cloud Membership To view and set the integrated value information provided...
  • Page 4 Automatic User can register interlock device (IP Door, CCTV, IoT device device, etc.) registration COMMAX IP and various environce setting for lobby call and system Setting operation Mobile call Calls to mobile phones login ID same as wallpad...
  • Page 5 Android 1920x1080 Nexus5x 2048x1536 Nexus9 2560x1440 Galaxy Note 2560x1440 GalaxyS5 edge 1920x1080 GalaxyS4 2560 x 1440 LG G3 cat6 Total 11ea https://smartel.ua...

  • Page 6: Basic Screen Configuration

    CONTENTS CONTENTS Touch screen SPEAKER HOME CMOS POWER S/W POWER LED SENSOR(OPTION) EMERGENCY GUARD CALL RS-485(OPTION) Door Release Door Release(OPTION) DIAL Basic Screen Configuration https://smartel.ua...
  • Page 7 The moving of screen for using scrolling The screen change The navigation bar of home screen bottom Go to home screen Go back Volume control Go to Setting Home screen bottom setting bar Go to system wireless Wifi setting Wifi setting Go to wired network IP setting IPsetting...
  • Page 8 Check the status of external Internet connection Internet status Go to IP Door Camera registration Door registration Go to user registration User registration Go to IoTt device registration Device registration Go to wall pad setting Wall pad settings Go to OS setting OS setting https://smartel.ua...

  • Page 9: Home Screen

    2 Home Screen Home Area View the door camera View the door camera Dial key for call dial Door, network, membership status display Device Icons is displayed during abnormal operation status All App list all Apps Scene and Reservation control Scene contorl User Emergency button Emergency button...

  • Page 10: Editing A Space List

    2.1. Editing a space list ‘Press an empty space on background screen for one second. Drag the space you want to move and move it to the desired location Press the "X" button to delete the space. Press "+" button to add space Press the Cancel button to cancel editing Press the 'complete ' button to save the space list.

  • Page 11: Registering A Device

    Press "Enter" on the keyboard. Select a space image ‘Press 'OK' button to add space. ‘Previous' button will move to previous screen [공간 추가 화면] 2.2. Registering a device Method 1. Press an empty space on background screen for one second.
  • Page 12 Connect the device according to the device pairing method The device can be paired for up to 60 seconds. Press Cancel 'button to cancel the device pairing method. When a device is registered, the device is automatically placed on the screen https://smartel.ua...
  • Page 13 Method 2. Drag or click IoT Device ICON leftside on screen Click IoT Pairing ICON on upside and drag center on screen. Connect the device by using device pairing method. https://smartel.ua...

  • Page 14: Placing Device (Move / Delete)

    2.3. Placing device (move / delete) Method1. Press an empty space on background screen for one second Press ‘Device icon placement’. You can move to the desired location by pressing the device you want to move. Drag the device, move it to the desired location, and release the device To delete a device, press the corresponding icon longer to move to the desired location https://smartel.ua...
  • Page 15 To delete a device, press the icon longer and move it to the upper trash [Device delet screen] Method 2. Drag or click IoT Device ICON leftside on screen https://smartel.ua...
  • Page 16 You can move to the desired location by pressing the device you want to move. To delete a device, press the icon longer and move it to the upper trash https://smartel.ua...

  • Page 17: Controlling Devices

    2.4. Controlling devices Move to the space to control. You can turn the device on / off by pressing the device you want to control [The device control sreen] 2.5. Widget Area Provide a summary of our home environment and external environment information at present Press empty space on background screen for one second.
  • Page 18 To delete a widget, press the widge tlonger and move it to the upper trash. https://smartel.ua...

  • Page 19: House Reporter

    House Reporter We provide value information on the screen that allows us to understand our home environment and external conditions [The house reporter screen] 3.1. Edit house reporter Press edit "buttonu Press the "(On / Off)" button and you can select the value information item to be displayed..
  • Page 20 Press the "Search" button Select one of areas from search list [The weather area setting screen] https://smartel.ua...

  • Page 21: Control

    4 Control 4.1. Control lighting Go to the Lighting tab. When you press power button of whole lightings, all lightings are turned When you press power button of whole lightings, all lightings are turned off. Press the power button of the lighting you want to control to turn the light on off.

  • Page 22: Multi-Sensor

    4.2. Multi-sensor Checking multi-sensor Go to the Indoor Environment tab. Displays information collected in indoor environment by multi-sensor. [Multi sensor Screen] 4.3. Magnetic sensor Go to the Safety tab. 'Detected' is displayed when door open is detected. If no door open is detected, "No detected" is displayed.

  • Page 23: Adding Devices

    4.4. Adding devices Control standby power ① Press the + button to enter the Add Device mode. ② Pairing mode is for 1 minute [Standby power Screen] [Standby power Screen] https://smartel.ua...

  • Page 24: Edit Device

    4.5. Edit device Change the device nickname Select the device and change the nickname. ① Press button and finish changing the nickname of the devices. ① [Device edit Screen] Remove device Select the device you want to delete. Press the ①...

  • Page 25: Application

    5 Application 5.1. Interphone 5.1.1. Screen Layout Call connection screen ① ② [Monitoring Screen] https://smartel.ua...

  • Page 26: Door Entrance

    Press ① button to end the door monitoring. Press ② button to save video. Call connection screen ① ② ③ [Call connection Screen] ① call. ② Start Call / Open Door ③ Save video ④ Adjust call volume 5.2. Door entrance Monitor and call from door camera Click on the door entrance icon in the Quick Menu.
  • Page 27 Open the door When the call comes in and the call button is pressed, the door open button appears. Press the door open button to open the door. Saving the image of our house / common entrance visitor When you press the save video button during a call, the icon changes to and video recording starts Once you click the save button again, the image will be saved.

  • Page 28: Call Log

    Call house Press dial on background . You can call by entering the number of builidng and household or pressing the button of guard station and office 5.3. Call Log [Display for Call log] https://smartel.ua...
  • Page 29 Using Call Log When you click icon at the top of screen, you can delete the call log. https://smartel.ua...

  • Page 30: Security

    5.4. Security CCTV monitoring and save the image CCTV monitoring Occur emergency on urgent situation Occur emergency Security 5.4.1. Occur emergency Detect emergency The emergency has been activated by users or sensors automatically. Emergenc y situation will be operated with 3 steps(Occur → Stop → Restore). Occur emergency 5.4.2.
  • Page 31 Stop emergency 5.4.3. Click the “Stop” button. Click the password and “OK” button. (Password from factory : 1234) [Enter password] Return emergency 5.4.4. Click the “Restore” button. When you click it, the emergency will be disarmed. [Window for restoring emergency] CCTV 5.4.5.
  • Page 32 ⑤ ④ ① ⑥ ③ ⑦ ② [CCTV menu display] ① CCTV Display ⑤ Favorites ② Move to the next display ⑥ Seleted lists ③ Move to the previous display ⑦ List of favoirtes ④ Channal list ⑧ Check the saved image CCTV monitoring &...

  • Page 33: Checking Visitor

    5.5. Checking visitor Check the saved image of enterence or lobby Checking visitor 5.5.1. Visitor Check the saved image of enterence or lobby [Display for saved image] Delete the saved image Delete With icons, you can check the location of saved movie clip. Movie clip from enterence Enterence Movie clip from lobby...
  • Page 34 Check the saved movie clip You can check the time and date of saved movie clip from the enterence or lobby. Delete the saved movie clip Click the ‘Delete’ button. Click the individual movie clip or “All movie clip’ for the selection. To un-select the movie clip, click that icon again.

  • Page 35: Etc App

    5.6. Etc App Calculation Calculator Set the alarm and time Clock Sign up / Edit / Initialization Sign up Setting for wallpad Wallpad setting Android setting OS setting Internet brower Brower https://smartel.ua...
  • Page 36 5.6.1. Calculator You can use it for calculation. [Display for calculation] 5.6.2. Brower This is the web brower for internet. https://smartel.ua...
  • Page 37 5.6.3. Sign up Sign up / Edit / Initialization Enter ‘ID’ and clikc ‘Duplication check’. Select the living country. Enter ‘Passward’, ‘Retype Passward’ and click ‘Registration’. [Display for Sign-up] Edit & Initialization If you have already siged up, you can see the current ID on the display. You can change the passward to click ‘P/W change’...
  • Page 38 5.7. Wallpad setting You can set the user information, wallpad, controlling devices, Door camera and other devices. Click “Wallpad setting” icon, display. [Display for Wallpad setting] 5.7.1. Wallpad setting You can set the SIP server, call number of guard station and passwords for wallpad. https://smartel.ua...
  • Page 39 - If wallpad sets Slave, input IP of Master wallpad and select Slave number (501 ~ 510) ※ If you are a member of COMMAX, you need to initialize the member information before setting it as Slave. ※ After the setting of the month pad type is completed, it is automatically rebooted.

  • Page 40: Emergency

    You can change the password for disarming emergency and Away mode. Enter the new password.  Re-enter the same password.  If passwords are same, it has been changed.  ※ Initial password is 1234. You can change the building & household number. ※...
  • Page 41 After initialization, you can not restore the data. [List for initialization] - Call log - Saved image - Saved movie clip - Emergency log 5.7.4. Door camera setting You can register IP door camera. 1) Click “Door Camera Setting”, push the button of door camera for 5 seconds, the camera image will be displayed automatically.
  • Page 42 Click “Camera Preview”, you can check the image of door camera. Click ‘Registeration’ button, the door camera will be registered to wallpad automatically. You can change the name of door camera to click “Edit” button. 5.7.5. CCTV Registeration You can register IP type CCTV camera. Click “CCTV camera register’...
  • Page 43 Click “Preview” button and enter the ID & Passward, you can check the image of CCTV camera. https://smartel.ua...
  • Page 44 Clikc “Register” button, that CCTV camera will be registered. Click “Edit” button, you can change the name of CCTV camera. https://smartel.ua...
  • Page 45 5.7.6. Call setting You can adjust the calling functions. The menu is as below. Continuous call time : You can select the call time between 30 sec ~ 3 min. Video recording time : You can select the recording time between 10 sec ~ 60 sec.
  • Page 46 Video auto save: When you select it, video clip will be saved automatically Video clip will be saved on your app. Allow smartphone incoming call : When you select it, you can receive tha call from the visitors to your smart phone. 5.7.7.
  • Page 47 Select the place and select the ringtone. (Preview for ringtone) Click the ‘Confirm’ button, the ringtone has been selected. 5.7.9. Wallpad information You can check the information of systems such as versions of S/W. https://smartel.ua...
  • Page 48 5.7.10. Check the version of application Click “Application” button. The version of app will be displayed. 5.7.11. Touch keypad sensitivity You can control sensitivity of keypad, if product has touch keypad. https://smartel.ua...

  • Page 49: Scene / Booking Control

    6 Scene / Booking control ④ ① ② ③ [Main display of Scene / Scenario menu] ① Move to Home display ③ Detail of Scene ② Add Scene ④ Quick move to scenario control 6.1.1. Add Scene In the menu, click the ‘Add scene‘ button. Click ‘Create the scene with selected device’...
  • Page 50 [Display for name & icon] [Display for device setting] 6.1.2. Away mode Activate & Deactivate the away mode Display for away mode status You can set the sensors, saving visitor image, turn-off the light or bypass the call in the away mode.. Activate the away mode Click the away mode icon.
  • Page 51 ① Lead time for Away mode ② Start the away mode ③ List for activiation with away mode ※ Away mode will not be activated during the setting of security. ※ Lead time for away mode can be set in the menu of ‘Away mode setting → Option →...
  • Page 52 ※ This function will be activated when the sensors are installed in the house. ※ You can choose the usage of sensors in the menu of [Setting → Signal → Usage of sensor]. Set the security Check the security sensor in ‘Security area (②)’ button. Activate the selected area to click ‘Confirm(①)’...
  • Page 53 6.1.4. Scene control Click the scene among the list. devices will operated belongs to its scene. Click ‘Details’ in the main menu. devices will operated to click ‘Run’ button. 6.1.5. Edit Scene Click ‘Security: Applying>’ button, you can arm / disarm the security while you activate the curtain scene.
  • Page 54 6.1.6. Setting the scenario(Mode) You can control the devices under the setting of scenario.. Ex.) Turn-on the Lighging when disarming the away mode ※ It may take 1 to 5 min due to server condition. 6.1.7. Adding scenario control Click “Control the scenario” button at the right-top of display.
  • Page 55 Select the options of device. Click ‘ ’ button for the saving. ‘Activiation’ will be set as same as ‘Condition’. When the setting of “Codition” and “Activiation” is completed, click the ‘ ’ button for saving. You can see the created scenario. 7.2.1.
  • Page 56 PRODUCT MODLE CIOT-1020M SPEC LINE UTP (CAT.5e) VOLTAGE INPUT : PoE DC 36V ~ 54V / DC5V POWER STANDBY :5W , MAX : 10W TELECOMUNNICATION AUDIO : VoIP, VIDEO : H.264, H.265 STANDARD UTP (CAT.5e) 70m LINE & DISTANCE (FROM THE PSE) TEMPERATURE 0℃...
  • Page 57 INSTALLATION PACKAGE CONTENTS. Bracket for wall mount Manual CIOT-1020M T4 X 18(4EA) M3 x 6(1EA) Screw for wall mount Screw for body ООО Компания "Строймир" г. Киев, ул. Борщаговская 154А, оф. 435 +38 (044) 331-15-43 info@smartel.ua https://smartel.ua https://smartel.ua...
