Page 1: Tea Cater
TEA CATER USER MANUAL UM_EN Part No.: 1730080-02... -
Page 2: Table Of Contents
CONTENT TEA CATER CONTENT ................................ 2 GENERAL ................................4 Introduction ................................4 Warnings ..................................4 Precautions ................................4 Intended use ................................4 Facts & weight .................................5 General functional description..........................5 OVERVIEW OF COMPONENTS ......................6 Front view ..................................6 Back view ...................................7 BUTTONS AND DISPLAY INFORMATION ................8 Button functions ...............................8... - Page 3 PROGRAMMING ............................16 Adjusting water quantity ............................. 16 MESSAGE SHOWN ON DISPLAY ....................17 Error message ................................ 17 DIMENSION SKETCH ..........................18 Tea Cater ................................18 Serving Station ............................... 19 Some important information may appear in textboxes seen below IMPORTANT! CAUTION! More INFO.
-
Page 4: General
GENERAL TEA CATER Introduction Thank you for choosing a TEA CATER brewer. We hope you enjoy it ! Read the user guide before using the machine. Always keep this guide close at hand for future This guide contains important instructions for reference. -
Page 5: Facts & Weight
GENERAL TEA CATER Facts & weight FACTS TEA CATER Hot water tap Brew options Height, Width, Depth 690, 205, 450mm Tank volume 2.5L Power supply 220-230 V 1N~ 2200 W 50-60Hz Cold water connection ½” External thread Capacity 17 cups / 6 minutes, Hot water 20 L / hour Serving station 1 x 2.5L... -
Page 6: Overview Of Components
OVERVIEW OF COMPONENTS TEA CATER Front view Hot Water Tap Filiter Holder Serving Station Lid Carry Handle Display Serving Station Level Tube Tap for Tea Drip Tray Insert Drip Tray... -
Page 7: Back View
OVERVIEW OF COMPONENTS TEA CATER Back view Water Connection Power Supply Power Switch... -
Page 8: Buttons And Display Information
BUTTONS AND DISPLAY INFORMATION TEA CATER Button functions Push button to decrease temperature or pre-infusion time Push button to increase temperature or pre-infusion time Push button to shift between temperature and pre-infusion time 1/1 Brewing Full brew = 2.5L 1/2 Brewing Half brew = 1.25L... -
Page 9: Installation And Start-Up
INSTALLATION AND START-UP TEA CATER Positioning MIN. 10cm Place the brewer unit on a flat horizontal surface that will support the weight of the machine. Make sure that air is able to circulate behind the machine Note (minimum 10cm). Water connection Connect the supplied water hose to the cold water connection using a ½’’... -
Page 10: Electrical Connection And Start-Up
INSTALLATION AND START-UP TEA CATER Electrical connection and start-up Recommended: install a line circuit breaker and a earth fault breaker to the machine. IMPORTANT! Connect the plug to a separate earthed wall socket 220-230V 50-60Hz, 10 Amp. Turn on the switch located at the rear of the machine, the machine will start filling with water. -
Page 11: Operation
OPERATION TEA CATER Brewing with tea Filter positioning Place a filter in the filter holder. Always use Coffee Queen´s recommended tea filter. Filter type 110mm filter, Part No. 110110 Add tea Recommended portion of tea; Full brew = 50 g Half brew = 25 g Make sure that the tea is evenly spread. -
Page 12: Brewing Temperature
OPERATION TEA CATER Brewing with tea Brewing temperature Push button + to increase or - button to decrease temperature. The temperature of brewing tea: GREEN TEA 85 - 88ºC BLACK TEA 95 - 96ºC WOOLONG TEA 92 - 94ºC JASMIN TEA 85 - 88ºC... -
Page 13: To Keep Temperature And Aroma
OPERATION TEA CATER Brewing with tea To keep temperature and aroma Tips for keeping tea Pre-heat the serving station, start a brewing with only water into the serving station. When brewing is complete let it stand for about 1 hour. Pour out the water. -
Page 14: Cleaning And Care
CLEANING AND CARE TEA CATER Each day Cleaning Before each Rinse serving station and filtre holder brewing. Rinse the with hot water. serving station Outside cleaning use a soft rag with liquid with fresh tap cleaning agent to prevent scratches. -
Page 15: Each Week
CLEANING AND CARE TEA CATER Each week Cleaning serving station Disassemble the level tube and clean it every week with the enclosed brush. Turn off the bigger lid, and clean the mixer tube(A). Cleaning of serving station 2.5L IMPORTANT! Fill the serving station with hot water. ( Full Rinse the serving brewing without tea and filter ). -
Page 16: Programming
PROGRAMMING TEA CATER Adjusting water quantity ADJUST SIGNAL Press buttons at the same time for 5 seconds until you hear 3 beeps. The display shows the current setting. Adjust with the buttons = (increase outlet valve activity) = (decrease outlet valve activity) -
Page 17: Message Shown On Display
MESSAGE SHOWN ON DISPLAY TEA CATER Error message Error message, Display shows: E1, E2, E3, E4. LEVEL CONTROL IMPORTANT! All maintenance and installations - Clean the level sensor. must be done - The water high level - Replace of an authorized... -
Page 18: Dimension Sketch
DIMENSION SKETCH TEA CATER Tea Cater Model Tea Cater 690mm 205mm 450mm... -
Page 19: Serving Station
DIMENSION SKETCH TEA CATER Serving Station Model Serving Station 205 mm 273 mm 436 mm 400 mm 105 mm... - Page 20 For the warranty to be valid the conditions for maintenance must have been followed according to our instructions, proper precaution has been made and warranty claim been issued without delay. The affected equipment may not be used during awaiting service if there is any risk that the damage or defect would worsen.
