Specifications

475040-SD
Range 0.10 to 176.40 oz
0.03 to 49.03N
Accuracy*
*@3000g & 5000g and 23 ± 5 °C
Display
Display Direction
Unit select
Update time
Over range Indicator
Sampling Time
Peak hold Sampling Time 10ms to 500ms. in 10ms steps.
Data error no.
Memory Card
Data output
Overload Capacity
Full Scale Deflection
Zero/tare Control
Transducer
Power Supply
Power
Operating Temperature
Operating Humidity
Dimension
Weight
All rights reserved including the right of reproduction in whole or in part in any form
Resolution
3 to 5000g
± (0.4% Rdg + 1 digit)
5 digit backlit LCD 0.63" (16 mm) digit size.
Positive or Reverse
g (grams), oz (ounces), N (Newtons)
kg (kilograms), lb (pounds), N (Newtons) (475044-SD)
Fast: Approx. 0.2 second, Slow: Approx. 0.6 second.
" - - - - "
0 sec to 8 hour 59 min. 59 sec.
0.1% of total saved data max.
SD memory card. 1 GB to 16 GB.
RS 232/USB PC computer interface. Optional software
475040: 7kg Max, 475044: 30kg Max
475040: Approx. 2mm max., 475044: Approx. 0.4mm max.,
Max. full capacity.
load cell.
6 AA 1.5V alkaline batteries (UM3 or equivalent) or optional 9V AC
adaptor
Normal operation (no SD card), Backlight off: Approx. DC 7 mA.
With SD card, backlight off: Approx. DC 38 mA
With SD card, backlight on: Approx. DC 41 mA
32°F to 122°F (0°C to 50°C).
Less than 80% RH.
8.5 x 3.5 x 1.8 inch (215 x 90 x 45 mm).
1.43 LB (650 g)/with batteries.
Copyright © 2013 FLIR Systems, Inc.
www.extech.com
1 0.02 to 20.00kg
0.02 0.07 to 44.10lb
0.01 0.3 to 196.12N
ISO‐9001 Certified
12
475044-SD
± (0.5% Rdg + 2 digit)
*@10kg & 20kg and 23 ± 5 °C
(475040-SD)
475040-044-SD-EU-EN v1.7 11/13
Resolution
0.01
0.01
0.02
