Each of the two 20-pin connectors is assigned a group of 8 input and output channels. The table below
shows the relation of input and output channels in the STATUS modes.
Input/Output STATUS Mode
Mode
Inputs
Outputs
The NXP-CPI16 may be configured to default to STATUS-ON mode using the following method. The
commands can force a change to the mode no matter what default mode is configured for the device.
STATUS-ON Mode:
Remove R7 (1K ohm) resistor OR short across R8 for STATUS-ON mode. Firmware remains the same
for standard and STATUS-ON mode NXP-CPI16 units.
NXP-CPI16 NetLinx Custom Panel Interface
Connector
STATUS-OFF (default)
J3
Chan 1-8
J4
Chan 9-16
J3
Chan 1-8
J4
Chan 9-16
STATUS-ON
Chan 1-8
Chan 17-24
Chan 9-16
Chan 25-32
9
