1-2 CHIRPS ON/OFF: This feature controls the chirps that confirm arming and disarming of the system. A siren

or horn must be connected to the H1/10 BROWN wire.

1-3 IGNITION LOCK ON/OFF: When turned on, the doors will lock three seconds after the ignition is turned on

and unlock when the ignition is turned off.

1-4 IGNITION UNLOCK ON/OFF: When ON this feature will unlock the doors when the ignition is turned off.

1-5 ACTIVE/PASSIVE LOCKING: If passive arming is selected in Menu One, Feature 1-1, then the system can be

programmed to either lock the doors when passive arming occurs, or only lock the doors when the system is

armed with a transmitter. Active locking means the doors will not lock when the system passively arms. Passive

locking means that the doors will lock whenever the system passively arms the optional starter kill (if connected).

1-6 PANIC WITH IGNITION ON/OFF: This feature allows the user to panic the system sounding the siren while

the ignition is on.

1-7 DOOR LOCK PULSE DURATION: Some European vehicles, such as Mercedes-Benz and Audi, require longer lock

and unlock pulses to operate the vacuum pump. Programming the system to provide 3.5 second pulses, will

accommodate the door lock interface in these vehicles. The default setting is 0.8 second door lock pulses. Some

modification to the door lock harness (H2) is also necessary. (Refer to TechTip 1041 for wiring information regard-

ing (+/-) Door Lock Outputs Harness (H4)section, Type E - Mercedes-Benz and Audi -1985 and Newer" diagram.)

The 0.4 second pulse is required on some of the newer Chrysler and Ford vehicles.

1-8 UNLOCK OUTPUT—1, 2 PULSES: This will program the unlock output to one or two pulses. When the double

pulse unlock feature is turned on, the BLUE H4/1 wire will supply two negative pulses instead of a single pulse.

At the same time, the GREEN H4/3 wire will supply two positive pulses instead of a single pulse. This makes it

possible to directly interface with double pulse vehicles without any extra parts for unlock and lock outputs (see

below).

1-9 LOCK OUTPUT—1, 2 PULSES: This will program the lock output to one or two pulses. When the double pulse

lock feature is turned on, the BLUE H4/1 wire will supply two positive pulses instead of a single pulse. At the

same time, the GREEN H4/3 wire will supply two negative pulses instead of a single pulse.

1-10 CHANNEL 2 VALIDITY, LATCH, LATCH RESET, 30-SECOND TIMER:

■ In the delayed validity default setting the Channel 2 output will output a negative (-) signal after the

button is pressed for more than 1.5 seconds and will continue until the button is released.

■ The latched output selection will output a negative signal when the

tinue until the button is pressed again.

■ The latched/reset with ignition output selection operates just like the latched output but will reset or stop

when the ignition is turned on, then off.

■ The 30-second timed output selection will latch the Channel 2 output on for 30 seconds when the remote

button is pressed and will con-
