Installation Type Selection

Choosing the right installation type according to the device you install.
Corresponding installation type according to what device you are installing
Type 1 - PKE Standalone
Type 2a - PKE + Xpresskit Bypass + AutoStart or AstroStart or Viper/Python/Clifford Directed
Remote Starter (with 4-pin antenna connector)
Type 2b - PKE + Xpresskit Bypass + Viper/Python/Clifford Directed Remote Starter (with 6-pin
antenna connector)
Type 3a - PKE + Xpresskit Bypass + DIRECTED SmartStart + Autostart or Astrostart Directed Remote
Starter (with 4-pin antenna connector)
Type 3b - PKE + Xpresskit Bypass + DIRECTED SmartStart + Viper/Python/Clifford Directed Remote
Starter (with 6-pin antenna connector)
Type 3c - PKE + Xpresskit Bypass + DIRECTED SmartStart + Viper/Python/Clifford Directed Remote
Starter (with 4-pin antenna connector)
Type 4 - PKE + 4x10/5x10
Type 5 - PKE + Xpresskit Bypass
Type 6 - PKE + DIRECTED SmartStart + 4x10/5x10
Type 7 - PKE + Xpresskit Bypass - Remote Start Ready (RSR) + DIRECTED SmartStart
Type 8 - PKE + Xpresskit Bypass - Range Extender (RXT) + XL202
Type 9 - PKE + AutoStart or AstroStart or Viper/Python/Clifford Directed Remote Starter (with 4pin
antenna connector)
6
Page
page 7
page 8
page 9
page 10
page 11
page 12
page 13
page 14
page 15
page 16
page 17
page 18
