Directed Passive Keyless Entry (PKE)
Model 2102T
Installation Guide
This
product
is
intended
for
installation
by
a
professional
installer only! Attempts to install this product by a person other than a
trained professional may result in severe damage to a vehicle's electrical
system and components.
© 2012 Directed, Vista, CA
N2102T 2012-07

Advertisement

Table of Contents
loading

Summary of Contents for Directed Electronics 2102T

  • Page 1 Directed Passive Keyless Entry (PKE) Model 2102T Installation Guide This product intended installation professional installer only! Attempts to install this product by a person other than a trained professional may result in severe damage to a vehicle’s electrical system and components.
  • Page 3: Table Of Contents

    Contents Antenna Mounting and Installation Points ��������������������������������������������������������������������������������������5 Vehicle Category Installation Specification �����������������������������������������������������������������������������5 Installation Type Selection �����������������������������������������������������������������������������������������������������������6 Installation diagram ��������������������������������������������������������������������������������������������������������������������7 Wiring connections ������������������������������������������������������������������������������������������������������������������19 D2D port (H2), 4-pin black connector ���������������������������������������������������������������������������������19 Feature Programming ���������������������������������������������������������������������������������������������������������������20 Entering feature programming routine ���������������������������������������������������������������������������������20 Changing feature options ��������������������������������������������������������������������������������������������������20 Accessing another feature ��������������������������������������������������������������������������������������������������20 Exiting feature programming ����������������������������������������������������������������������������������������������20 Features and Options List ���������������������������������������������������������������������������������������������������21...
  • Page 4 Warning! safety first The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer. When properly installed, this system can lock and unlock your doors and also arm and disarm your Directed security system when the key fob is in and out of range.
  • Page 5: Antenna Mounting And Installation Points

    Antenna Mounting and Installation Points In order to maximize range, the following antenna mounting options should be discussed with the customer to better suit their needs. Warning • Do not directly mount the antenna on any metallic surface, this may significally decrease the range. •...
  • Page 6: Installation Type Selection

    Installation Type Selection Choosing the right installation type according to the device you install. Corresponding installation type according to what device you are installing Page Type 1 - PKE Standalone page 7 Type 2a - PKE + Xpresskit Bypass + AutoStart or AstroStart or Viper/Python/Clifford Directed page 8 Remote Starter (with 4-pin antenna connector) Type 2b - PKE + Xpresskit Bypass + Viper/Python/Clifford Directed Remote Starter (with 6-pin...
  • Page 7: Installation Diagram

    Installation diagram Type 1 - PKE Standalone (-) Door Sense** (+) Ignition (-) Parking Light (+) Starter (+) Brake (+) Door Sense** Ground: Black (-) Horn (-) Unlock (+)12v: Red (-) Lock Starter Disable: This connection is (-) Lock Output: Green: 1 optional and ad- (-) Unlock Output: Blue: 2 ditional parts are...
  • Page 8: Type 2A - Pke + Xpresskit Bypass + Autostart Or Astrostart Or Viper/Python/Clifford Directed

    Type 2a - PKE + Xpresskit Bypass + AutoStart or AstroStart or Viper/Python/Clifford Directed Remote Starter (with 4-pin antenna connector) Note: 8210 Antenna Universal Adapter is required and sold separately. To The Vehicle (+) Ignition Output Regular Remote Start Connections (+) 12v: Red: 4 (-) Door Sense Input*** 4 wires red...
  • Page 9: Type 2B - Pke + Xpresskit Bypass + Viper/Python/Clifford Directed Remote Starter (With 6-Pin

    Type 2b - PKE + Xpresskit Bypass + Viper/Python/Clifford Directed Remote Starter (with 6-pin antenna connector) To The Vehicle (+) Ignition Output Regular Remote Start Connections (-) Door Sense Input**** (+) 12v: Red: 4 (+) Brake Input (+) Door Sense Input**** TX: Green: 3 4 wires red (-) Ground: Black: 2...
  • Page 10: Type 3A - Pke + Xpresskit Bypass + Directed Smartstart + Autostart Or Astrostart Directed Remote

    Type 3a - PKE + Xpresskit Bypass + DIRECTED SmartStart + Autostart or Astrostart Directed Remote Starter (with 4-pin antenna connector) Note: 8210 Antenna Universal Adapter is required and sold separately. The remote starter model will determine which connector to use. Refer to the DIRECTED SmartStart install guide for proper connection.
  • Page 11: Type 3B - Pke + Xpresskit Bypass + Directed Smartstart + Viper/Python/Clifford Directed Remote

    Type 3b - PKE + Xpresskit Bypass + DIRECTED SmartStart + Viper/Python/Clifford Directed Remote Starter (with 6-pin antenna connector) The remote starter model will determine which connector to use. Refer to the DIRECTED SmartStart install guide for proper connection. (-) Door Sense**** ESP Black (+) Ignition Output Connector...
  • Page 12: Type 3C - Pke + Xpresskit Bypass + Directed Smartstart + Viper/Python/Clifford Directed Remote

    Type 3c - PKE + Xpresskit Bypass + DIRECTED SmartStart + Viper/Python/Clifford Directed Remote Starter (with 4-pin antenna connector) Note: 8210 Antenna Universal Adapter is required and sold separately. The remote starter model will determine which connector to use. Refer to the DIRECTED SmartStart install guide for proper connection.
  • Page 13 Type 4 - PKE + 4x10/5x10 4 wires red connector (+) Ignition Output (-) Door Sense Input**** (+) Brake Input (+) Door Sense Input**** (+) Starter Wire Connect these wires to the vehicle. Starter Disable: This connection is optional and ad- (-) Horn Output: Red/White: 3 ditional parts are (+) Door Sense Input: White/Purple: 4****...
  • Page 14: Type 5 - Pke + Xpresskit Bypass

    Type 5 - PKE + Xpresskit Bypass Not Used 3 wires red connector (+) Ignition Output (+) 12v: Red: 4 (-) Door Sense Output** TX: Green: 3 (-) Ground: Black: 2 (+) Brake Output (+) Door Sense Output** RX: Blue: 1 4 wires white (-) Unlock Input connector...
  • Page 15: Type 6 - Pke + Directed Smartstart + 4X10/5X10

    Type 6 - PKE + DIRECTED SmartStart + 4x10/5x10 10-feet Antenna Cable**** (+) 12v: Red: 4 RX: Green: 3 (-) Ground: Black: 2 TX: Blue: 1 (+) Ignition Output (-) Door Sense Input (See note) (+) Brake Input (+) Door Sense Input (See note) (+) Starter Wire Connect these wires to the vehicle.
  • Page 16: Type 7 - Pke + Xpresskit Bypass - Remote Start Ready (Rsr) + Directed Smartstart

    Type 7 - PKE + Xpresskit Bypass - Remote Start Ready (RSR) + DIRECTED SmartStart See Remote Start Ready (RSR) install guide according to your vehicle for RSR connections details. Connect these wires to the vehicle. (+) 12v: Red: 4 RX: Green: 3 (-) Ground: Black: 2 TX: Blue: 1...
  • Page 17: Type 8 - Pke + Xpresskit Bypass - Range Extender (Rxt) + Xl202

    Type 8 - PKE + Xpresskit Bypass - Range Extender (RXT) + XL202 Note: 8210 Antenna Universal Adapter is required and sold separately. See Remote Start Ready (RSR) install guide according to your vehicle for RSR connections details. Connect these wires to the vehicle.
  • Page 18: Type 9 - Pke + Autostart Or Astrostart Or Viper/Python/Clifford Directed Remote Starter (With 4Pin

    Type 9 - PKE + AutoStart or AstroStart or Viper/Python/Clifford Directed Remote Start- er (with 4pin antenna connector) Note: 8210 Antenna Universal Adapter is required and sold separately. To The Vehicle (+) Ignition Output Regular Remote Start Connections (+) Door Sense Input*** (-) Door Sense Input*** (+) Brake Input 8210*...
  • Page 19: Wiring Connections

    Wiring connections 6 Green 6 Black Antenna Port Remote Start Antenna Port Analog Port 10 Black 2 Red 4 Red 2 Black 2 White Analog Port (H1), 10-pin white connector H1/1 GREEN (-) LOCK OUTPUT H1/2 BLUE (-) UNLOCK OUTPUT H1/3 RED/WHITE (-) HORN OUTPUT...
  • Page 20: Feature Programming

    Feature Programming The feature programming can be done by following the instructions below. Entering feature programming routine To select a Feature, press and release the programming button the corresponding number of times according to the table below, and then press and hold, the LED will flash to indicate the selected feature number. To select this Fea- Press the program- And the LED...
  • Page 21: Features And Options List

    Features and Options List Features Options 1: Viper, Python, Clifford Supercode* Directed new generation receiver technology 2: Viper, Python, Clifford Keeloq Directed older generation receiver technology 3: AstroStart receiver technology 1- RF Protocol Selection 4: AS HDR - FM AutoStart HDR (new style FM based) receiver technology 5: AS HDR - AM AutoStart HDR (AM based) receiver technology 6: AS LDR - FM...
  • Page 22: Smartlock Feature

    SmartLock feature The purpose of the SmartLock feature is to prevent the doors from unwanted unlocking/locking when entering/exiting the active zone multiple times for a pre-programmed delay (No delay*,1, 3 or 5 minutes). This is practical in situations such as loading/unloading packages.
  • Page 23: Remote Pairing

    Remote pairing Important: The antennas must be connected to the PKE module before proceeding to pairing mode. RF Protocole Selection need to be done prior to pair the PKE to the remote starter. See "Feature Programming" section on page 20. Pairing the FOB to the PKE module: Press and release, then press and hold the programming button on the PKE module.
  • Page 24 The company behind this system is Directed Since its inception, Directed has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories avail- able. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology.
